Test Instruments & Gauges

TECLOCK  Dial Depth Gauge IM-882 As to internal caliper gauge IM-880 series, the distance between contact points facing outside is firstly set at standard dimension with ring gaugeor micrometer. Then, it is measured by inserting contact point into internal dimension part to be measured after its outer dial of which movestogether with rotated bezel is set at “0”. The displacement of indicator from “0” point of outer dial is to be measured at that time. The value addingto the read displacement to standard dimension or deducting it from standard dimension is the dimension of internal diameter. This seriesattaches spare contact point which cam set accurate dimension corresponding to size of internal dimension. External caliper gauge is opposite,namely reading the value by holding work piece with 2 contact points facing outside Internal caliper gauge to measure internal diameter of cylindrical workpiece and recessed groove diameter. It can measure groove diameter of "O" ring by modifying spare contact point. Set dimension within ±1mm (indication range 2mm) can be comparatively measured (880 series) by alternatively using auxiliary spare contact point in accordance with measured dimension. Please set standard dimension within measuring range with micrometer or ring gauge. Specifications Graduation (mm) Measuring Range (mm) Indicating Range (mm) Indication Error Measuring Force (N) Weight (g) Spare Contact Point Maximum Measuring Depth A (mm) Entrance Diameter Φd (mm)* Groove Depth H (mm) Minimum Groove Width B (mm) Code No. Measuring Range (mm) 0.01 55~153 2 ±20 3 or less 240 ZS-413 55~73 90 45~63 5 3.5 ZS-414 71~89 54~72 8.5 ZS-415 87~105 70~88 8.5 ZS-416 103~121 86~104 8.5 ZS-417 119~137 102~120 8.5 ZS-418 135~153 118~136 8.5

Read more less

Niigata Seiki (SK) SUS Feeler Gauge 0.01x1m SFG-01-1   Feature Used for assembling and adjusting automobile engines and other internal combustion engines. Cut to the required dimensions and use. Essentials for assembly and adjustment! You can cut and use only the required size. specification Size (mm): 0.01 x 1m Leaf width 12.7mm Material: Stainless steel Instrumental error: (mm): ± 0.004 Case size (mm): 77 x 77 x 22 Gap measurement Body mass: 40g Package size: 77 x 77 x 22 mm 　30 g

Read more less

TECLOCK  Dial Depth Gauge IM-881 As to internal caliper gauge IM-880 series, the distance between contact points facing outside is firstly set at standard dimension with ring gaugeor micrometer. Then, it is measured by inserting contact point into internal dimension part to be measured after its outer dial of which movestogether with rotated bezel is set at “0”. The displacement of indicator from “0” point of outer dial is to be measured at that time. The value addingto the read displacement to standard dimension or deducting it from standard dimension is the dimension of internal diameter. This seriesattaches spare contact point which cam set accurate dimension corresponding to size of internal dimension. External caliper gauge is opposite,namely reading the value by holding work piece with 2 contact points facing outside Internal caliper gauge to measure internal diameter of cylindrical workpiece and recessed groove diameter. It can measure groove diameter of "O" ring by modifying spare contact point. Set dimension within ±1mm (indication range 2mm) can be comparatively measured (880 series) by alternatively using auxiliary spare contact point in accordance with measured dimension. Please set standard dimension within measuring range with micrometer or ring gauge. Specifications Graduation (mm) Measuring Range (mm) Indicating Range (mm) Indication Error Measuring Force (N) Weight (g) Spare Contact Point Maximum Measuring Depth A (mm) Entrance Diameter Φd (mm)* Groove Depth H (mm) Minimum Groove Width B (mm) Code No. Measuring Range (mm) 0.01 30~62 2 ±20 3 or less 218 ZS-408 30~38 75 24~32 3 2.5 ZS-409 36~44 27.4~35.4 4.3 ZS-410 42~50 33.4~41.4 4.3 ZS-411 48~56 39.4~47.4 4.3 ZS-412 54~62 45.4~53.4 4.3

Read more less

Niigata Seiki (SK) SUS Feeler Gauge 0.05mmx1m SFG-05-1   Feature Used for assembling and adjusting automobile engines and other internal combustion engines. Cut to the required dimensions and use. specification Size (mm): 0.05 x 1m Leaf width 12.7mm Material: Stainless steel Instrumental error: (mm): ± 0.005 Case size (mm): 77 x 77 x 22 Gap measurement Body mass: 40g Package size: 77 x 77 x 22 mm 　40 g

Read more less

Niigata Seiki (SK) SUS Feeler Gauge 0.04mmx1m SFG-04-1   Feature Used for assembling and adjusting automobile engines and other internal combustion engines. Cut to the required dimensions and use. specification Size (mm): 0.04 x 1m Leaf width 12.7mm Material: Stainless steel Instrumental error: (mm): ± 0.005 Case size (mm): 77 x 77 x 22 Gap measurement Body mass: 40g Package size: 77 x 77 x 22 mm 　40 g

Read more less

Niigata Seiki (SK) SUS Feeler Gauge 0.02x1m SFG-02-1   Feature Used for assembling and adjusting automobile engines and other internal combustion engines. Cut to the required dimensions and use. Essentials for assembly and adjustment! You can cut and use only the required size. specification Size (mm): 0.02 x 1m Leaf width 12.7mm Material: Stainless steel Instrumental error: (mm): ± 0.004 Case size (mm): 77 x 77 x 22 Gap measurement Body mass: 40g Package size: 77 x 77 x 22 mm 　40 g

Read more less

Niigata Seiki (SK) Taper gauge TPG-700S Feature A taper gauge (# 700 1-15) and a straightedge 130 mm are set, with a clip that is convenient to carry. Silver finish A set of straightedge and feeler gauge! It is a clip type that can be stored in a pocket. specification Measurement of grooves, gaps, hole diameters, etc., length measurement Material: Stainless hardened steel (SUS420J2) Body mass: 40g Standard: 700S   [Taper gauge] Measuring range (mm): 1 to 15 Instrumental error: (mm): ± 0.05 Scale (mm): 0.1 Taper angle: 7 ° 9′10 ″ Body length: 148.5mm   【Straight scale】 Measuring range (mm): 0 to 130 Instrumental error: (mm): ± 0.13 Scale (mm): 0.5 Body length: 155mm Package size: 55 x 9 x 205 mm 　30 g

Read more less

Peacock Long Travel Dial Gauges; 0.01mm, 207, Range 20mm Model 207  Graduation 0.01mm  Range 20mm  Lug back Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 207 0.01 20 ±0 -50-100 10 ±15 ±20 7 5 2.0   Dimensions (mm) Model A B C D E F G H I 207 90 41 25 66.5 14.5 20 5 7.5 62.5

Read more less

Shinwa Taper gauge 1 to 15 mm with straightedge   Features ● Convenient for measuring inner diameter and gap dimensions. ● Convenient for measuring length and depth. ● A convenient tool that includes a taper gauge and a straightedge. ● The clip is convenient when you insert it in your pocket or measure the depth. ● When measuring circular holes, there will be an error due to the thickness of the gauge body. An inner diameter correction table that is convenient for accurate measurement is attached to the back of the main unit. specification ● Body size 160 x 26 x 5 mm ● Measurement range Taper gauge: 1 to 15 mm Straightedge: 0 to 150 mm ● Product mass 21g ● External dimensions 160 x 26 x 5 mm (when stored) ● Accuracy Tapered gauge: ± 0.05mm Straightedge: ± 0.15mm ● Material: Stainless steel ● Hardness: Hv400 or higher

Read more less

Shinwa Taper gauge No. 700B 15-30 mm Features ● Convenient for measuring inner diameter and gap dimensions. specification ● Body size 154 x 31 x 1.2 mm ● Measurement range 15 to 30 mm ● Product mass 29g ● Thickness 1.2mm ● Accuracy ± 0.05mm ● Material: Stainless steel ● Hardness: Hv400 or higher

Read more less

Shinwa Taper gauge No. 700A 1 to 15 mm Features ● Convenient for measuring inner diameter and gap dimensions. ● When measuring circular holes, there will be an error due to the thickness of the gauge body. An inner diameter correction table that is convenient for accurate measurement is attached to the back of the main unit. specification ● Body size 148 x 17 x 1.2 mm ● Measurement range 1 to 15 mm ● Product mass 11g ● Thickness 1.2mm ● Accuracy ± 0.05mm ● Material: Stainless steel ● Hardness: Hv400 or higher

Read more less

Shinwa 150 mm Rigid   Product size / length: 175 mm, width: 15 mm, height: .5 mm Product weight: 10 g. Package size / length: 180 mm, width: 21 mm, height: 1 mm. Package weight: 10 g. Shinwa Rules Co., Ltd. (Shinwa Sokutei) is the leading manufacturer of measuring instruments having the largest share in Japan in the field of metallic scales. Specifications for this item Brand Name Shinwa Sokutei Ean 4960910130050 Item Weight 0.353 ounces Measurement System Metric Model Number 13005 Part Number 13005

Read more less

Peacock LA-24 Outside Dial Caliper Gauge (Throat depth: 600mm) The dial caliper gauge show its great power in measurement of inside and outside sizes, wall  thickness, groove width and hole diameters and any other shapes and sections that is not apparently accessible. Model LA-24 Graduation 0.1mm Range 0 - 100mm Throat depth 600mm  Max. opening frame 500mm Specifications Model Graduation (mm) Range (mm) Indication error (mm) Throat depth (mm) Dimensions (mm) H 1 H 2 H 3 H 4 LA-24 0.1 0~100 ±0.4 600 300 300 100 100

Read more less

Peacock LA-23 Outside Dial Caliper Gauge (Throat depth: 300mm) The dial caliper gauge show its great power in measurement of inside and outside sizes, wall  thickness, groove width and hole diameters and any other shapes and sections that is not apparently accessible. Model LA-23 Graduation 0.1mm Range 0 - 80mm Throat depth 300mm   Specifications Model Graduation (mm) Range (mm) Indication error (mm) Throat depth (mm) Dimensions (mm) H 1 H 2 H 3 H 4 LA-23 0.1 0~80 ±0.2 300 45 50 48 43

Read more less

Peacock LA-11 Outside Dial Caliper Gauge (Throat depth: 125mm) The dial caliper gauge show its great power in measurement of inside and outside sizes, wall  thickness, groove width and hole diameters and any other shapes and sections that is not apparently accessible. Model LA-11 Graduation 0.1mm Range 0 - 50mm Throat depth 125mm   Specifications Model Graduation (mm) Range (mm) Indication error (mm) Throat depth (mm) Dimensions (mm) H 1 H 2 H 3 H 4 LA-11 0.1 0 - 50 ±0.2 125 2 5.5 2 5.5

Read more less

Peacock Dial Lens Gauge GL The dial lens gauge can measure convex, concave, convexo-concave and any other lenses in the same gauge by replacing the two contact points and the anvil. Model GL Graduation 0.01mm Range 10mm   Specifications Model Graduation (mm) Range (mm) Throat depth (mm) Accuracy (µm) maximum lens diameter measurable (mm) maximum lens thickness measurable (mm) Measuring force less than (N) GL 0.01 10 30 ±20 ø 59 20 1.8

Read more less

Peacock Dial Sheet Gauges K-4 The sheet gauges can measure wide sheets since the throat depth of this gauges having 300, 500 and 690mm. Model K-4 Graduation 0.05mm Range 0~50mm Throat depth 500mm  Ø25mm flat contact point and anvil      Specifications Model Graduation(mm) Range (mm) Throat depth (mm) Accuracy (µm) Contact Point Anvil Dia (mm) Measuring force less than (N) Dia (mm) Parallelism (µm) K-4 0.05 0 - 50 500 ±100 25 25 25 3.0

Read more less

Peacock Lever Type Dial Indicators PIC TEST ; Change lever type, PC-2 Model PC-2 Graduation 0.002mm Range 0.28mm   Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning section of the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.002 0.28 0 - 140 - 0 3 2 2 0.4 12.0

Read more less

Peacock Lever Type Dial Indicators PIC TEST ; Change lever type, PC-1A Model PC-1A Graduation 0.01mm Range 0.5mm   Miniature Bearing Used The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability without any effect by rod play. O-ring used Oil resistance is enhanced by seating the O-ring in the turning section of the outer frame.   Graduation (mm) Range (mm) Reading Accuracy (µm) Measuring force less than (N) L (mm) Wide-range forward accuracy Adjacent error Backward error 0.01 0.5 0 - 25 - 0 5 5 3 0.4 21.4

Read more less

Peacock Replaceable contact points ,XS-3 series     Part No. L (mm) Material  XS-3 25 SKS 3  XS-310 10 SKS 3  XS-320 20 SKS 3  XS-330 30 SKS 3

Read more less

Peacock Back Plunger Type Dial Gauges; 0.01mm , 196B Model 196B  Graduation 0.01mm  Range 5mm  Stem Ø8mm Contact point ( X-112 )   The back plunger dial gauge is characterized with easy handling since the spindle having the contact point moves in the direction perpendicular to the dial face and the gauge is more compact.  The dial gauge of this type is convenient for use in achieving a parallelism of the table of the machine tool, with measuring jigs, in restricted areas and on locations where scale reading is difficult. Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 0.01 5 0-50-100 10 ±12 ±15 ±20 ±20 6 5 1.4   Dimensions (mm) A B C D E F G H I 58.5 38 12.5 4.5 - - - 5.5 16.5

Read more less

Peacock One Revolution Dial Gauges; 0.01mm, 47Z, Range 0.8mm Model 47Z  Graduation 0.01mm  Range 0.8mm  Long stem Flat back These are high-accuracy dial gauges with the pointer giving less than a full turn that can resist rigorous rigorous continuous measurement. The long stem is made of stainless steel, is high in strenght and is malfunction-freedue to fastening. The dial faces except No. 18 and 17B are easy to read with green and orange(dead zone) Model Graduation  (mm) Range (mm) (Free stroke) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 47Z 0.01 0.8(4.0) 40-0-40 9 - ±13 -   6 5 1.4   Dimensions (mm) Model A B C D E F G H I K 47Z (47ZL) 58.9 20 30 36 13 -15 4 5.8 32 40.9

Read more less

Peacock Miniature Dial Gauges; 0.01mm, 47F , Range 4mm Model 47  Graduation 0.01mm  Range 4mm  Contact point ( X-107 ) Flat back Dial dia. Ø36mm These compact size dial gauges are equipped with small dial faces. They are especially useful for measuring jigs, in restricted areas. Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 47F 0.01 4 0-50-0 9 - ±13 - ±15 6 5 1.4   Dimensions (mm) Model A B C D E F G H I 47 39.6 20 9.7 36 13 - 3.5 6.5 32

Read more less

Peacock Long Travel Dial Gauges; 0.01mm, 207,Range 20mm Model 207  Graduation 0.01mm  Range 20mm  Lug back Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 207 0.01 20 ±0-50-100 10 - ±15 - ±20 7 5 2.0   Dimensions (mm) Model A B C D E F G H I 207 90 41 25 66.5 14.5 20 5 7.5 62.5

Read more less

Niigata Seiki (SK) SUS Feeler Gauge 0.08mmx1m SFG-08-1 Feature Used for assembling and adjusting automobile engines and other internal combustion engines. Cut to the required dimensions and use. specification Size (mm): 0.08 x 1m Leaf width 12.7mm Material: Stainless steel Instrumental error: (mm): ± 0.005 Case size (mm): 77 x 77 x 22 Gap measurement Body mass: 40g Package size: 77 x 77 x 22 mm 　40 g

Read more less

Niigata Seiki (SK) SUS Feeler Gauge 0.03mmx1m SFG-03-1   Feature Used for assembling and adjusting automobile engines and other internal combustion engines. Cut to the required dimensions and use. Essentials for assembly and adjustment! You can cut and use only the required size. specification Size (mm): 0.03 x 1m Leaf width 12.7mm Material: Stainless steel Instrumental error: (mm): ± 0.005 Case size (mm): 77 x 77 x 22 Gap measurement Body mass: 40g Package size: 77 x 77 x 22 mm 　40 g

Read more less

Niigata Seiki (SK) Protractor No.19 Stainless PRT-19 Feature Stainless steel finish Stainless finish. With a rod scale. specification Scale: 1 ° Maximum measurement angle: 180 ° Accuracy: ± 20' Body: Diameter 90mm x Thickness 1.2mm Rod: Length 204mm x Thickness 1.2mm Material: Stainless steel (SUS420J2) Angle measurement Body mass: 81g Package size: 70 x 17 x 260 mm 　80 g

Read more less

Niigata Seiki (SK) Taper gauge 0.3-4mm TPG-270A Feature It is mainly used when measuring by inserting it into a gap. Silver finish With a PC storage case that is convenient to carry You can easily measure the dimensions of grooves and gaps just by inserting them into the gaps! specification Material: Measurement of grooves, gaps, etc. Measuring range (mm): 0.3-4 Instrumental error: (mm): ± 0.04 Scale (mm): 0.05 Taper, angle: 1 ° 54′33 ″ Measurement of grooves, gaps, etc. Body mass: 95g Body length: 160mm Body width: 11mm Package size: 23 x 188 x 15 mm 　70 g

Read more less

Niigata Seiki (SK) Taper gauge # 700 15-30mm TPG-700B Feature Silver finish You can easily measure the dimensions of grooves and gaps just by inserting them into the gaps! specification Material: Stainless hardened steel (SUS420J2) Hardness: HV480 Standard: # 7001-15 Measuring range (mm): 15 to 30 Instrumental error: (mm): ± 0.05 Scale (mm): 0.1 Taper, angle: 7 ° 9′10 ″ Measurement of grooves, gaps, hole diameters, etc. Body mass: 40g Body length: 153mm Body thickness: 1.2mm Package size: 55 x 12 x 205 mm 　40 g

Read more less

Niigata Seiki (SK) Taper gauge # 700 1-15mm TPG-700A Feature Silver finish You can easily measure the dimensions of grooves and gaps just by inserting them into the gaps! specification Material: Stainless hardened steel (SUS420J2) Hardness: HV480 Standard: # 7001-15 Measuring range (mm): 1 to 15 Instrumental error: (mm): ± 0.05 Scale (mm): 0.1 Taper, angle: 7 ° 9′10 ″ Measurement of grooves, gaps, hole diameters, etc. Body mass: 10g Body length: 148.5mm Body thickness: 1.2mm Package size: 56 x 5 x 205 mm 　20 g

Read more less

Niigata Seiki (SK) Plastic taper gauge Smooth scale TPG-800KD Feature The newly designed stepped scale prevents misreading. 0.2 mm dot scale that is easy to see even if hidden in a pipe. Suitable for measuring objects that you do not want to scratch. Made of plastic that does not easily damage the object. Comes with a clip-shaped slit that is convenient to carry. specification Measuring range (mm): 1-15 Minimum scale (mm): 0.1 Instrumental error (mm): ± 0.2 Package size: 55 x 8 x 205 mm

Read more less

Niigata Seiki (SK) level meter smooth scale ,LM-90KD   Features Analog type, easier to see than bubble level Step-like scale that makes it easy to see the scale in 1 ° units Light and easy to use With magnet on the measurement surface Use Tilt angle measurement Product specifications Specifications / standards Measuring range: 0 to 90 ° Minimum reading: 1 ° Reading accuracy: ± 0.5 ° Measuring range (°): 0-90 Size (mm): 95 x 95 x 30 Minimum display (°): 1 Reading accuracy (°): ± 0.5 Material Body: ABS resin Cover: Acrylic Mass / mass unit 120g

Read more less

Peacock Standard Dial Gauges; 0.01mm, JIS B 7503 , 107 Dial Gauges are widely used manufacturing plants. ○ The stem, made of SK quench hardened with strength, is malfunction-free due to fastening. ○ The shock-proof mechanism prevents gears from damage due to shocks arisen by abruptly pushing up the spindle. ○ The turning section of the outer frame sealed by the O-ring and the back inside sealed by the packing are waterproof and dust-proof in construction. ○ The back is increased in strength by four screws, and the lug can be turned 90 degrees in the installation way.  Model 107 Graduation 0.01mm Range 10mm Lug back   Model Graduation  (mm) Range (mm) Reading Indication error (µm) Backward error (µm) Repeatability (µm) Measuring force less than (N) Revolution Whole measuring range 1/10 1/2 One Two 107 0.01 10 ±0 -50- 100 8 ±9 ±10 ±15 ±15 5 5 1.4   Dimensions (mm) Model A B C D E F G H I 107 65 41.5 18.5 53 14.5 20 4 6.5 49

Read more less

Mitutoyo 3058S-19 Dial Indicator, Lug Back Plate Large-diameter dial face for easy reading Supplied with limit markers and a bezel clamp as standard Graduation: 0,01 mm Make sure to buy an original Mitutoyo product. This instrument is supplied by Mitutoyo UK. Buying from us means buying original Mitutoyo instruments directly from the JPese premium manufacturer with the outstanding quality, durability and accuracy that you legitimately expect. Specifications for this item Brand Name Mitutoyo Ean 4946368524719 Item Volume 0.002 cubic_metres Item Weight 300 grams Measurement System Metric Model Number 3058S-19 Part Number 3058S-19 Range 50 millimeters

Read more less

Mitutoyo 511-722 Dial Bore Gage, 35-60 mm   Specifications for this item Brand Name Mitutoyo Ean 4946368612577 Item Weight 14.1 ounces Measurement Accuracy 2μm Measurement System Metric Model Number 511-722 Number of Items 1 Part Number 511-722 Range 35 - 60mm Resolution 0.01mm or 0.001mm, UNSPSC Code 41111630

Read more less

Mitutoyo 511-715 Standard Type Bore Gauge , 160 mm-250 mm Range   Boxed with interchangeable anvil and washers Allows you to inner diameter measurement with high accuracy More effective stroke (compared with the regular product) Carbide Contact Points ensure high durability and anti-slip properties Sponge like structure on the operator's grip reduces heat transfer from the hand of 50% Specifications for this item Brand Name Mitutoyo Ean 4946368612546 Item Weight 520grams Model Number 511-715 Number of Items 1 Part Number 511-715 Range ,,,

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M5-0.8 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 5 Pitch: 0.8 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M4-0.7 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 4.0 Pitch: 0.7 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M3-0.6 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 3 Pitch: 0.6 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M3.5-0.6 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 3.5 Pitch: 0.6 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M4-0.5 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 4.0 Pitch: 0.5 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M24-3.0 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 24 Pitch: 3.0 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M18-1.5 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 18 Pitch: 1.5 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M20-2.5 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 20 Pitch: 2.5 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M22-2.5 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 22 Pitch: 2.5 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M2-0.4 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 2 Pitch: 0.4 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M14-1.5 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 14 Pitch: 1.5 Mountain angle: 60 °

Read more less

SHS Metric Thread plug gauge coarse GP2XIP2 series M16-2.0 Feature Conventional JIS method JISB0205 (old standard) / 0207 (old standard) specification Type: Stop (for inspection) Grade: Level 2 Screw diameter: 16 Pitch: 2.0 Mountain angle: 60 °

Read more less
