BESSEY

Products Details Connect any two K Body parallel clamps to increase the clamping capacity. The connector is made of robust aluminum. On carded hang pack Reference no. Suitable for Weight approx. KBX20 KRE / KREV / KR / KRV 0.75kg

Read more less

Products Details   For quick one‐handed operation Widths up to 80 mm   Reference no. Opening Min/Max (mm) Throat depth b (mm) Weight approx. (kg) KF2 10~40 80 0.76 KF4 10~80 110 1.48

Read more less

Products Details   Clamping force up to 8,000 N Very large parallel clamping surfaces with 3 removable pressure caps Metal-reinforced plastic housing and optimised sliding arm with double slide protection for more power and safety: The set clamping force is maintained and the sliding arm cannot unintentionally slip in the unclamped condition Can be converted without tools for spreading tasks High-quality 2-component symmetrical plastic handle with hexagon socket for the comfortable application of the clamping force (max. torque 17 Nm) KREV with continuously adjustable and fixable upper section for optimum positioning on the workpiece    Reference no. Opening a (mm) Throat depth b (mm) Spreading width e min/max (mm) Rail (mm) Weight approx. (kg) KRE30-2K 300 95 255-390 29 x 9 2.15 KRE60-2K 600 95 255-730 29 x 9 2.76 KRE80-2K 800 95 255-930 29 x 9 3.1 KRE100-2K 1000 95 255-1130 29 x 9 3.45 KRE125-2K 1250 95 255-1355 29 x 9 3.87 KRE150-2K 1500 95 255-1610 29 x 9 4.28 KRE200-2K 2000 95 255-2080 29 x 9 5.09 KRE250-2K 2500 95 255-2580 29 x 9 6.05

Read more less

Products Details Especially for DIY applications and domestic appliances Special accessory for angle clamps WS 3/WS 6, screw clamp S 10 and K Body REVO parallel clamps KRE/KREV and KR/KRV to hold them to a work surface edge Reference no. Bolt Ø Opening a Throat depth b Weight approx. TK6 8mm 60mm 22mm 0.1kg

Read more less

Products Details  Suitable for steel pipes DN 20/R3/4" or DN 15/R1/2“ Outer diameter 26.9 mm or 21.3 mm Infinitely-adjustable clamping width With stand On carded hang pack   Reference no. For pipes Ø (mm) For pipes Ø (") Throat depth b (mm) Weight approx. (kg) BPC-H12 21.3 1/2 40 0.88 BPC-H34 26.9 3/4 42 1.3

Read more less

Products Details   20 % more clamping force per spindle rotation with optimised rail profile Maximum security with linear transfer of force at the sliding arm Clamping force up to 6,000 N Fixed jaw and sliding arm are constructed of tempered steel for resilient clamping Ergonomically shaped wood handle Pressure plates can be replaced by hand – no need for tools (from 80 mm width) Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) GZ10 100 60 15 x 6 0.3 GZ12 120 60 15 x 6 0.31 GZ16 160 80 17.5 x 6.8 0.52 GZ20 200 100 22 x 8.5 0.95 GZ25 250 120 24.5 x 9.5 1.34 GZ30 300 140 28 x 11 1.96

Read more less

Products Details   Clamping force of up to 3,500 N Clamp and fix in place quickly and simply with just one hand With protection caps on the clamping surfaces On carded hang pack   Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) EHZ30-2K 300 100 19.5 x 9.5 1.25 EHZ60-2K 600 100 19.5 x 9.5 1.67

Read more less

Products Details   Clamping force up to 1,500 N Parallel jaw faces with extra-large contact surfaces Clamping of various shapes, along the whole length of the rail Universally applicable Light and easy-to-handle No need for tools for switching between clamping and spreading On carded hang pack   Reference no. Opening a (mm) Throat depth b (mm) Spreading width e min/max (mm) Rail (mm) Weight approx. (kg) UK16 160 80 172-270 20 x 5 0.62 UK30 300 80 172-415 20 x 5 0.72 UK60 600 80 172-720 20 x 5 0.93

Read more less

Products Details   Clamping force up to 1,500 N Step‐over clamping Comes with two protective caps Small and easy to handle Light weight   Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) LMU10/5 100 50 15 x 5 0.23 LMU15/5 150 50 15 x 5 0.27 LMU20/5 200 50 15 x 5 0.31

Read more less

Products Details   Upper and lower arms and lever made from high‐quality hardwood Cork pads for gentle clamping   Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) HKL20 200 110 20 x 5 0.32 HKL30 300 110 20 x 5 0.46 HKL40 400 110 20 x 5 0.54 HKL60 600 110 20 x 5 0.7 HKL80 800 110 20 x 5 0.86 HKL100 1000 110 20 x 5 1

Read more less

Products Details Clamping aid for clamping components of different thicknesses at any chosen angle Sturdy body and base plate made from high-quality cast iron The copper-plated spindle prevents welding splatter from sticking Angle range: 5°‐180°   Reference no. Angle range Opening a (mm) Jaw height (mm) Weight approx. (kg) SM10-SET 5°-180° 100 35 10.66

Read more less

Products Details Automatic adjustment to workpieces of various thicknesses Sturdy jaws and base plate made from high-quality cast iron The copper-plated spindle prevents welding splatter from sticking Precise 90°-angles   Reference no. Opening min/max (mm) Current passage max. (mm) Jaw height (mm) Jaw length (mm) Weight approx. (kg) WSM9 2 x 90 60 35 110 3.8 WSM12 2 x 120 100 61 120 7.8

Read more less

Products Details Lever is in vertical clamping position Automatic, seamless adjustment of the clamping height up to 35 mm with almost constant clamping force – without manual changing of the pressing screw position Adjustable clamping force up to 2,500 N, based on the adjusting screw in the joint Sturdy, tempered sheet steel for longer service life Base plate hole pattern suitable for millimetres and inches High-quality, oil-resistant two-component plastic handle  Reference no. Opening a (mm) Automatic adjustment (mm) Clamping pressure (appr.N) Weight approx. (kg) STC-VH20 35 20 1100 0.22 STC-VH50 40 35 2500 0.43

Read more less

Products Details Adapter with tilting clamping jaws with a tilt range of -15° to +15° Clamping on sloping and parallel surfaces On carded hang pack   Reference no. Suitable for Jaw width Jaw height Weight approx. KR-AS KRE / KREV / KR / KRV 170mm 25mm 0.18kg

Read more less

Products Details   Variable opening of up to 170 mm, yet can be operated with one hand Lightweight, functional and easy to handle Extremely sturdy On carded hang pack Reference no. Opening a (mm) Throat depth b (mm) Weight approx. (kg) XV5-170 170 50 0.19

Read more less

Products Details   Variable opening of up to 100 mm, yet can be operated with one hand Lightweight, functional and easy to handle Extremely sturdy On carded hang pack   Reference no. Opening a (mm) Throat depth b (mm) Weight approx. (kg) XV3-50 55 37 0.07 XV5-100 100 50 0.17

Read more less

Products Details   Lightweight, functional and easy to handle Extremely sturdy On carded hang pack Reference no. Opening a (mm) Throat depth b (mm) Weight approx. (kg) XC2 25 30 0.02 XC3 35 37 0.05 XC5 50 50 0.12 XC7 75 70 0.18

Read more less

Products Details Moving the handle moves the push-pull rod Automatic and infinitely variable adjustment of the clamping height up to 13 mm while clamping force remains unchanged – without having to make manual changes to the position of the pressure screws Adjustable clamping force up to 2,500 N, based on the adjusting screw in the joint Sturdy, tempered metal sheets for a long service life Base plate hole pattern suitable for millimetres and inches High-quality oil resistant two-component plastic handle   Reference no. Opening a (mm) Automatic adjustment (mm) Clamping pressure (appr.N) Weight approx. (kg) STC-IHH15 25 8 1100 0.19 STC-IHH25 35 13 2500 0.45

Read more less

Products Details   Parallel jaw faces Prism recess for small round parts Includes pressure caps for gentle clamping of sensitive surfaces   Reference no. Opening a (mm) Throat depth b (mm) Weight approx. (kg) GRZ10 100 65 1 GRZ20 200 65 1.2

Read more less

Products Details Load‐bearing capacity 75 kg For the safe lifting and carrying of panels such as wood sheets, chipboard panels, glass and plexiglass  High‐friction rubber coating on the moving clamping jaws Reference no. Opening min/max Weight approx. KFP 10~65mm 1.01kg

Read more less

Products Details   Clamping force up to 6,000 N High‐quality 2‐component plastic handle Pressure plates can be replace by hand – no tools required (from 80 mm throat depth) With protective caps on the clamping surfaces Stable profiled rail with serration BESSEY anti‐slip system (from 80 mm throat depth)   Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) TG10-2K 100 50 15 x 5 0.26 TG16-2K 160 80 25 x 6 0.66 TG20-2K 200 100 27 x 7 1.06 TG25-2K 250 120 29 x 9 1.54 TG30-2K 300 140 32 x 10 2.2 TG25S10-2K 250 100 27 x 7 1.15 TG30S10-2K 300 100 27 x 7 1.18 TG40S10-2K 400 100 27 x 7 1.33 TG40S12-2K 400 120 29 x 9 1.78 TG60S12-2K 600 120 29 x 9 2.13 TG100S12-2K 1000 120 29 x 9 2.83 TG50S17-2K 500 175 32 x 10 2.9

Read more less

Products Details   20 % more clamping force per spindle rotation with optimised rail profile Maximum security with linear transfer of force at the sliding arm Clamping force up to 6,000 N Fixed jaw and sliding arm are constructed of tempered steel for resilient clamping Tommy bar with rounded ends for simple transfer of force when clamping Pressure plates can be replaced by hand – no need for tools    Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) GZ16K 160 80 17.5 x 6.8 0.5 GZ20K 200 100 22 x 8.5 0.93 GZ25K 250 120 24.5 x 9.5 1.31 GZ30K 300 140 28 x 11 1.89 GZ40K 400 120 28 x 11 2 GZ50K 500 120 28 x 11 2.2 GZ60K 600 120 28 x 11 2.42 GZ80K 800 120 28 x 11 2.76

Read more less

Products Details   EZS: Clamping force up to 2,000 N No tools required for spreading thanks to intelligent release mechanism in upper section Ergonomically shaped 2-component plastic handle behind the rail One-handed operation with little effort required On carded hang pack   Reference no. Opening a (mm) Throat depth b (mm) Spreading width e min/max(mm) Rail (mm) Weight approx. (kg) EZS15-8 150 80 170-360 19 x 6 0.72 EZS30-8 300 80 170-510 19 x 6 0.83 EZS45-8 450 80 170-660 19 x 6 0.93 EZS60-8 600 80 170-810 19 x 6 1.04 EZS90-8 900 80 170-1110 19 x 6 1.26

Read more less

Products Details   Clamping force up to 1,200 N Change from clamping to spreading by switching, not converting Handle with pump lever parallel to the rail Convenient one-handed operation, with little effort required All-round clamping – in front of, behind and at the side of the rail On carded hang pack   Reference no. Opening a (mm) Throat depth b (mm) Spreading width e min/max(mm) Spreading width f min/max (mm) Rail (mm) Weight approx. (kg) DUO16-8 160 85 75-235 9-170 20 x 5 0.66 DUO30-8 300 85 75-380 9-315 20 x 5 0.72 DUO45-8 450 85 75-535 9-470 20 x 5 0.83 DUO65-8 650 85 75-685 9-660 20 x 5 1.02

Read more less

Products Details Low weight Parallel clamping with guide rods Clamping at an angle without guide rods (max. 25°) Easy to attach, with 2 table clips supplied On carded hang pack Reference no. Opening a Jaw width Weight approx. S10-ST 100mm 90mm 0.83kg

Read more less

Products Details   Greater reserves of power, thanks to optimized rail profile, even clamping force build-up, especially under maximum utilization of the clamping range Non-slip trigger release Sintered steel cams - particularly hard-wearing, due to low friction surface hardness Quick - up to 5 x faster than regular clamps Secure - vibration resistant Strong - clamping force up to 8,500 N   Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) GH16 160 80 17.5 x 6.8 0.64 GH20 200 100 22 x 8.5 1.11 GH25 250 120 24.5 x 9.5 1.44 GH30 300 140 28 x 11 2.27 GH40 400 120 28 x 11 2.41 GH60 600 120 28 x 11 2.84 GH80 800 120 28 x 11 3.2 GH100 1000 120 28 x 11 3.59

Read more less

Products Details In the clamped position, the lever is horizontal Automatic and infinitely variable adjustment of the clamping height up to 35 mm while clamping force remains unchanged – without having to make manual changes to the position of the pressure screws Clamping force is variable up to 2,500 N depending on the adjustment of the set screw in the cantilevered joint Sturdy, tempered metal sheets for a long service life Hole pattern on the base plate designed to facilitate fast and secure clamping set-up for metric and imperial High-quality oil resistant two-component plastic handle Reference no. Opening a (mm) Automatic adjustment (mm) Clamping pressure (appr.N) Weight approx. (kg) STC-HH20 35 20 1100 0.20 STC-HH50 40 35 2500 0.38 STC-HH70 60 35 2500 0.42

Read more less

Products Details   Clamping force up to 1,200 N Feather light yet ultra strong Sturdy fixed and sliding arms made from lightweight magnesium Quick and vibration free clamping On carded hang pack   Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) KLI12 120 80 20 x 5 0.26 KLI16 160 80 20 x 5 0.29 KLI20 200 80 20 x 5 0.32 KLI25 250 80 20 x 5 0.35 KLI30 300 80 20 x 5 0.38 KLI40 400 80 20 x 5 0.45

Read more less

Products Details   Clamping force up to 35,000 N at tightening torque of 100 Nm Long life due to heat‐resistant pressure plate with sintered steel insert, which can be tilted up to 35° With 36 mm hexagonal bolt on the end of the spindle With wedge for fixing the sliding arm     Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) STBS100 1000 200 50 x 25 17.3

Read more less

Products Details   Clamping force up to 22,000 N at tightening torque of 70 Nm. Long life due to heat‐resistant pressure plate with sintered steel insert, which can be tilted up to 35°. With 19 mm hexagonal bolt on the end of the spindle.      Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) STB30M 300 175 40 x 20 5.61 STB40M 400 175 40 x 20 6.1 STB50M 500 175 40 x 20 6.67 STB60M 600 175 40 x 20 7.23 STB125M 1250 175 40 x 20 10.77

Read more less

Products Details   Greater reserves of power, thanks to optimized rail profile, even clamping force build-up, especially under maximum utilization of the clamping range Non-slip trigger release Sintered steel cams - particularly hard-wearing, due to low friction surface hardness Quick - up to 5 x faster than regular clamps Secure - vibration resistant Strong - clamping force up to 8,500 N  BESSEY Prod# Clamping Capacity Throat Depth Load Limit Approx. Weight Reference no. Inch Inch Pounds Pounds GSCC2.506 6 2 ½ 600 1.34 GSCC2.512 12 2 ½ 600 1.72 GSCC2.524 24 2 ½ 600 2.27 GSCC2.536 36 2 ½ 600 2.82

Read more less

Products Details   High-quality two-component plastic handle positioned around the rail, so clamp can be used in tight spaces Clamping force up to 2,000 N Easy-to-move trapezoidal thread spindle with swivelling pressure plate Quick-release shift button to quickly adjust sliding bar On carded hang-pack   Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) GK15 150 60 25 x 12 0.61 GK30 300 60 25 x 12 0.71 GK45 450 60 25 x 12 0.82 GK60 600 60 25 x 12 0.94

Read more less

Products Details   Clamping force up to 8,500 N at tightening torque of 25 Nm. 20 % more clamping force per spindle rotation with optimised rail profile. Maximum safety due to the better linear transfer of force of the sliding arm. Long life due to heat-resistant pressure plate with sintered steel insert, which can be tilted up to 35°.      Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) SL20M 200 120 28 x 11 1.88 SL25M 250 120 28 x 11 2 SL30M 300 120 28 x 11 2.11 SL40M 400 120 28 x 11 2.34 SL60M 600 120 28 x 11 2.82

Read more less

Products Details   Clamping force up to 2,000 N Clamping arms manufactured in toughened die cast zinc black powder coated to prevent chemical corrosion  Comes with protective cap Small and easy to handle Light weight Reference no. Opening a (mm) Throat depth b (mm) Rail (mm) Weight approx. (kg) LM10/5 100 50 15 x 5 0.26 LM15/5 150 50 15 x 5 0.27 LM15/8 150 80 20 x 5 0.51 LM20/10 200 100 25 x 6 0.9 LM20/5 200 50 15 x 5 0.31 LM20/8 200 80 20 x 5 0.55 LM25/5 250 50 15 x 5 0.35 LM25/8 250 80 20 x 5 0.6 LM30/10 300 100 25 x 6 1.02 LM30/5 300 50 15 x 5 0.37 LM30/8 300 80 20 x 5 0.64 LM40/10 400 100 25 x 6 1.1 LM50/10 500 100 25 x 6 1.24 LM60/10 600 100 25 x 6 1.3 LM80/10 800 100 25 x 6 1.58

Read more less

Products Details   Even pressure on mitre joints Crank handle can be relocated for right and left-handed users Contains: 1 band clamp, 4 Vario corners On carded hang pack Reference no. Clamping Range (mm) Band W × D (mm) Angle Range Weight approx. (kg) BAN700 Up to 7m 25 × 1 60 ° -180 ° 0.56

Read more less

Products Details Automatic adjustment to variously-sized workpieces Quick – clamp with a spindle Stable body For attaching with table clamp – available as an accessory WS 3 – on carded hang pack   Reference no. Opening min/max (mm) Jaw height (mm) Current passage max. (mm) Weight approx. (kg) WS3 2 x 55 30 30 1 WS6 2 x 100 36 60 2.3

Read more less
