Schneider Electric Schneider Electric circuit breaker Easypact EZC100F - TMD - 100 A - 3 poles 3d EZC100F3100
Description EasyPact EZC100F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 10kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 100A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100F is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100F Circuit breaker name Easypact EZC100F Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 100 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code F Breaking capacity 25 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-25 kA Icu at 125 V DC 1P conforming to IEC 60947-25 kA Icu at 250 V DC 2P conforming to IEC 60947-25 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-27.5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 12.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 125 V DC conforming to IEC 60947-22.5 kA at 250 V DC conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-23.75 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 100 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards EN/IEC 60947-1JIS C8201-2-2GB/T 14048.2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.5 cm Package 1 Length 14 cm Package 1 Weight 808 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 9.887 kg Unit Type of Package 3 P12 Number of Units in Package 3 384 Package 3 Height 75 cm Package 3 Width 80 cm Package 3 Length 120 cm Package 3 Weight 328 kg
$27.50
Schneider Electric Schneider Electric Miniature circuit breaker , Acti9 iC60N, 1P, 2 A, C curve, 6000 A (IEC 60898-1), 50 kA (IEC 60947-2) A9F74102
Description This Acti9 iC60N is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected pole, 2A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 50kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 6000A at 230VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. The product can be clipped on a DIN rail. Its width is 2 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 18mm x (H) 85mm x (D) 78.5mm. The weight is 0.215kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 85°C. Specifications Main Device application Distribution Range Acti9 Product name Acti9 iC60 Product or component type Miniature circuit-breaker Device short name IC60N Poles description 1P Number of protected poles 1 [In] rated current 2 A Network type DCAC Trip unit technology Thermal-magnetic Curve code C Breaking capacity 6000 A Icn at 230 V AC 50/60 Hz conforming to EN/IEC 60898-150 kA Icu at 12...60 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 100...133 V AC 50/60 Hz conforming to EN/IEC 60947-210 kA Icu at 60...72 V DC conforming to EN/IEC 60947-215 kA Icu at 12...60 V DC conforming to EN/IEC 60947-2 Utilisation category Category A conforming to EN 60947-2Category A conforming to IEC 60947-2 Suitability for isolation Yes conforming to EN 60898-1Yes conforming to EN 60947-2Yes conforming to IEC 60898-1Yes conforming to IEC 60947-2 Standards EN 60898-1IEC 60898-1EN 60947-2IEC 60947-2 Quality labels NF Complementary Network frequency 50/60 Hz Magnetic tripping limit 8 x In +/- 20 % [Ics] rated service breaking capacity 50 kA 100 % conforming to EN 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 100...133 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 100...133 V AC 50/60 Hz6000 A 100 % conforming to EN 60898-1 - 230 V AC 50/60 Hz6000 A 100 % conforming to IEC 60898-1 - 230 V AC 50/60 Hz10 kA 100 % conforming to EN 60947-2 - 72 V DC10 kA 100 % conforming to IEC 60947-2 - 72 V DC15 kA 100 % conforming to EN 60947-2 - 12...60 V DC15 kA 100 % conforming to IEC 60947-2 - 12...60 V DC Limitation class 3 conforming to EN 60898-13 conforming to IEC 60898-1 [Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to EN 60947-2500 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to EN 60947-26 kV conforming to IEC 60947-2 Contact position indicator Yes Control type Toggle local signalling Trip indicator Mounting mode Fixed mounting support DIN rail Comb busbar and distribution block compatibility Top or bottom: YES 9 mm pitches 2 height 85 mm Width 18 mm Depth 78.5 mm Net weight 0.215 kg Colour White Mechanical durability 20000 cycles Electrical durability 10000 cycles Connections - terminals Single terminal (top or bottom) 1…25 mm² rigidSingle terminal (top or bottom) 1…16 mm² flexible Wire stripping length 14 mm for top or bottom connection Tightening torque 2 N.m top or bottom earth-leakage protection Without Environment IP degree of protection IP20 conforming to IEC 60529IP20 conforming to EN 60529 Pollution degree 3 conforming to EN 60947-23 conforming to IEC 60947-2 Overvoltage category IV Tropicalisation 2 conforming to IEC 60068-1 Relative humidity 95 % at 55 °C Operating altitude 0...2000 m Ambient air temperature for operation -35…70 °C Ambient air temperature for storage -40…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 1.7 cm Package 1 Width 7.5 cm Package 1 Length 9.4 cm Package 1 Weight 110.0 g Unit Type of Package 2 BB1 Number of Units in Package 2 12 Package 2 Height 7.7 cm Package 2 Width 9.6 cm Package 2 Length 22.0 cm Package 2 Weight 1.398 kg Unit Type of Package 3 S03 Number of Units in Package 3 132 Package 3 Height 30.0 cm Package 3 Width 30.0 cm Package 3 Length 40.0 cm Package 3 Weight 15.888 kg
$9.91
Schneider Electric Schneider Electric Miniature circuit breaker (MCB), Acti9 iC60N, 1P, 4A, C curve, 6000A (IEC/EN 60898-1), 50kA (IEC/EN 60947-2) A9F74104
Description This Acti9 iC60N is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected pole, 4A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 50kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 6000A at 230VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. The product can be clipped on a DIN rail. Its width is 2 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 18mm x (H) 85mm x (D) 78.5mm. The weight is 0.215kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 85°C. Specifications Main Device application Distribution Range Acti9 Product name Acti9 iC60 Product or component type Miniature circuit-breaker Device short name IC60N Poles description 1P Number of protected poles 1 [In] rated current 4 A Network type DCAC Trip unit technology Thermal-magnetic Curve code C Breaking capacity 6000 A Icn at 230 V AC 50/60 Hz conforming to EN/IEC 60898-150 kA Icu at 12...60 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 100...133 V AC 50/60 Hz conforming to EN/IEC 60947-210 kA Icu at 60...72 V DC conforming to EN/IEC 60947-215 kA Icu at 12...60 V DC conforming to EN/IEC 60947-2 Utilisation category Category A conforming to EN 60947-2Category A conforming to IEC 60947-2 Suitability for isolation Yes conforming to EN 60898-1Yes conforming to EN 60947-2Yes conforming to IEC 60898-1Yes conforming to IEC 60947-2 Standards EN 60898-1IEC 60947-2IEC 60898-1EN 60947-2 Quality labels NF Complementary Network frequency 50/60 Hz Magnetic tripping limit 8 x In +/- 20 % [Ics] rated service breaking capacity 50 kA 100 % conforming to EN 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 100...133 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 100...133 V AC 50/60 Hz6000 A 100 % conforming to EN 60898-1 - 230 V AC 50/60 Hz6000 A 100 % conforming to IEC 60898-1 - 230 V AC 50/60 Hz10 kA 100 % conforming to EN 60947-2 - 72 V DC10 kA 100 % conforming to IEC 60947-2 - 72 V DC15 kA 100 % conforming to EN 60947-2 - 12...60 V DC15 kA 100 % conforming to IEC 60947-2 - 12...60 V DC Limitation class 3 conforming to EN 60898-13 conforming to IEC 60898-1 [Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to EN 60947-2500 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to EN 60947-26 kV conforming to IEC 60947-2 Contact position indicator Yes Control type Toggle local signalling Trip indicator Mounting mode Fixed mounting support DIN rail Comb busbar and distribution block compatibility Top or bottom: YES 9 mm pitches 2 height 85 mm Width 18 mm Depth 78.5 mm Net weight 0.215 kg Colour White Mechanical durability 20000 cycles Electrical durability 10000 cycles Connections - terminals Single terminal (top or bottom) 1…25 mm² rigidSingle terminal (top or bottom) 1…16 mm² flexible Wire stripping length 14 mm for top or bottom connection Tightening torque 2 N.m top or bottom earth-leakage protection Without Environment IP degree of protection IP20 conforming to IEC 60529IP20 conforming to EN 60529 Pollution degree 3 conforming to EN 60947-23 conforming to IEC 60947-2 Overvoltage category IV Tropicalisation 2 conforming to IEC 60068-1 Relative humidity 95 % at 55 °C Operating altitude 0...2000 m Ambient air temperature for operation -35…70 °C Ambient air temperature for storage -40…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 1.7 cm Package 1 Width 7.2 cm Package 1 Length 9.5 cm Package 1 Weight 110.0 g Unit Type of Package 2 BB1 Number of Units in Package 2 12 Package 2 Height 7.8 cm Package 2 Width 9.7 cm Package 2 Length 22.3 cm Package 2 Weight 1.386 kg Unit Type of Package 3 S03 Number of Units in Package 3 132 Package 3 Height 30.0 cm Package 3 Width 30.0 cm Package 3 Length 40.0 cm Package 3 Weight 15.742 kg
$9.74
Schneider Electric Schneider Electric Miniature circuit breaker , Acti9 iC60N, 2P, 2 A, C curve, 6000 A (IEC 60898-1), 50 kA (IEC 60947-2) A9F74202
Description This Acti9 iC60N is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles, 2A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 50kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 6000A at 400VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. It is DIN rail mountable. Its width is 4 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 36mm x (H) 85mm x (D) 78.5mm. The weight is 0.25kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 85°C. Specifications Main Device application Distribution Range Acti9 Product name Acti9 iC60 Product or component type Miniature circuit-breaker Device short name IC60N Poles description 2P Number of protected poles 2 [In] rated current 2 A Network type ACDC Trip unit technology Thermal-magnetic Curve code C Breaking capacity 6000 A Icn at 400 V AC 50/60 Hz conforming to EN/IEC 60898-150 kA Icu at 12...60 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 100...133 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-225 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-210 kA Icu at <= 125 V DC conforming to EN/IEC 60947-2 Utilisation category Category A conforming to EN 60947-2Category A conforming to IEC 60947-2 Suitability for isolation Yes conforming to EN 60898-1Yes conforming to EN 60947-2Yes conforming to IEC 60898-1Yes conforming to IEC 60947-2 Standards IEC 60898-1EN 60898-1IEC 60947-2EN 60947-2 Quality labels NF Complementary Network frequency 50/60 Hz Magnetic tripping limit 8 x In +/- 20 % [Ics] rated service breaking capacity 50 kA 100 % conforming to EN 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 380...415 V AC 50/60 Hz25 kA 100 % conforming to EN 60947-2 - 440 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 380...415 V AC 50/60 Hz25 kA 100 % conforming to IEC 60947-2 - 440 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 12...133 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 12...133 V AC 50/60 Hz6000 A 100 % conforming to EN 60898-1 - 400 V AC 50/60 Hz6000 A 100 % conforming to IEC 60898-1 - 400 V AC 50/60 Hz10 kA 100 % conforming to IEC 60947-2 - 72...125 V DC10 kA 100 % conforming to EN 60947-2 - 72...125 V DC Limitation class 3 conforming to EN 60898-13 conforming to IEC 60898-1 [Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to EN 60947-2500 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to EN 60947-26 kV conforming to IEC 60947-2 Contact position indicator Yes Control type Toggle local signalling Trip indicator Mounting mode Fixed mounting support DIN rail Comb busbar and distribution block compatibility Top or bottom: YES 9 mm pitches 4 height 85 mm Width 36 mm Depth 78.5 mm Net weight 0.25 kg Colour White Mechanical durability 20000 cycles Electrical durability 10000 cycles Connections - terminals Single terminal (top or bottom) 1…25 mm² rigidSingle terminal (top or bottom) 1…16 mm² flexible Wire stripping length 14 mm for top or bottom connection Tightening torque 2 N.m top or bottom earth-leakage protection Separate block Environment IP degree of protection IP20 conforming to IEC 60529IP20 conforming to EN 60529 Pollution degree 3 conforming to EN 60947-23 conforming to IEC 60947-2 Overvoltage category IV Tropicalisation 2 conforming to IEC 60068-1 Relative humidity 95 % at 55 °C Operating altitude 0...2000 m Ambient air temperature for operation -35…70 °C Ambient air temperature for storage -40…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 7.300 cm Package 1 Width 3.500 cm Package 1 Length 9.400 cm Package 1 Weight 221.000 g Unit Type of Package 2 BB1 Number of Units in Package 2 6 Package 2 Height 2.920 cm Package 2 Width 30.000 cm Package 2 Length 20.000 cm Package 2 Weight 1.386 kg Unit Type of Package 3 S03 Number of Units in Package 3 66 Package 3 Height 30.000 cm Package 3 Width 30.000 cm Package 3 Length 40.000 cm Package 3 Weight 15.816 kg
$22.11
Schneider Electric Schneider Electric Miniature circuit breaker (MCB), Acti9 iC60N, 1P, 1A, C curve, 6000A (IEC/EN 60898-1), 50kA (IEC/EN 60947-2) A9F74101
Description This Acti9 iC60N is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected pole, 1A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 50kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 6000A at 230VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. The product can be clipped on a DIN rail. Its width is 2 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 18mm x (H) 85mm x (D) 78.5mm. The weight is 0.215kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 85°C Specifications Main Device application Distribution Range Acti9 Product name Acti9 iC60 Product or component type Miniature circuit-breaker Device short name IC60N Poles description 1P Number of protected poles 1 [In] rated current 1 A Network type DCAC Trip unit technology Thermal-magnetic Curve code C Breaking capacity 6000 A Icn at 230 V AC 50/60 Hz conforming to EN/IEC 60898-150 kA Icu at 12...60 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 100...133 V AC 50/60 Hz conforming to EN/IEC 60947-210 kA Icu at 60...72 V DC conforming to EN/IEC 60947-215 kA Icu at 12...60 V DC conforming to EN/IEC 60947-2 Utilisation category Category A conforming to EN 60947-2Category A conforming to IEC 60947-2 Suitability for isolation Yes conforming to EN 60898-1Yes conforming to EN 60947-2Yes conforming to IEC 60898-1Yes conforming to IEC 60947-2 Standards EN 60898-1EN 60947-2IEC 60898-1IEC 60947-2 Quality labels NF Complementary Network frequency 50/60 Hz Magnetic tripping limit 8 x In +/- 20 % [Ics] rated service breaking capacity 50 kA 100 % conforming to EN 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 100...133 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 100...133 V AC 50/60 Hz6000 A 100 % conforming to EN 60898-1 - 230 V AC 50/60 Hz6000 A 100 % conforming to IEC 60898-1 - 230 V AC 50/60 Hz10 kA 100 % conforming to EN 60947-2 - 72 V DC10 kA 100 % conforming to IEC 60947-2 - 72 V DC15 kA 100 % conforming to EN 60947-2 - 12...60 V DC15 kA 100 % conforming to IEC 60947-2 - 12...60 V DC Limitation class 3 conforming to EN 60898-13 conforming to IEC 60898-1 [Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to EN 60947-2500 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to EN 60947-26 kV conforming to IEC 60947-2 Contact position indicator Yes Control type Toggle local signalling Trip indicator Mounting mode Fixed mounting support DIN rail Comb busbar and distribution block compatibility Top or bottom: YES 9 mm pitches 2 height 85 mm Width 18 mm Depth 78.5 mm Net weight 0.215 kg Colour White Mechanical durability 20000 cycles Electrical durability 10000 cycles Connections - terminals Single terminal (top or bottom) 1…25 mm² rigidSingle terminal (top or bottom) 1…16 mm² flexible Wire stripping length 14 mm for top or bottom connection Tightening torque 2 N.m top or bottom earth-leakage protection Without Environment IP degree of protection IP20 conforming to IEC 60529IP20 conforming to EN 60529 Pollution degree 3 conforming to EN 60947-23 conforming to IEC 60947-2 Overvoltage category IV Tropicalisation 2 conforming to IEC 60068-1 Relative humidity 95 % at 55 °C Operating altitude 0...2000 m Ambient air temperature for operation -35…70 °C Ambient air temperature for storage -40…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 1.7 cm Package 1 Length 7.5 cm Package 1 Weight 118.0 g Unit Type of Package 2 BB1 Number of Units in Package 2 12 Package 2 Height 3.0 cm Package 2 Width 30.0 cm Package 2 Length 20.0 cm Package 2 Weight 1.42 kg Unit Type of Package 3 S03 Number of Units in Package 3 132 Package 3 Height 30.0 cm Package 3 Width 30.0 cm Package 3 Length 40.0 cm Package 3 Weight 16.237 kg
$9.74
Schneider Electric Schneider Electric Miniature circuit breaker (MCB), Acti9 iC60N, 2P, 4A, C curve, 6000A (IEC/EN 60898-1), 50kA (IEC/EN 60947-2) A9F74204
Description This Acti9 iC60N is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected pole, 1A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 50kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 6000A at 230VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. The product can be clipped on a DIN rail. Its width is 2 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 18mm x (H) 85mm x (D) 78.5mm. The weight is 0.215kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 85°C. Specifications Main Device application Distribution Range Acti9 Product name Acti9 iC60 Product or component type Miniature circuit-breaker Device short name IC60N Poles description 1P Number of protected poles 1 [In] rated current 1 A Network type DCAC Trip unit technology Thermal-magnetic Curve code C Breaking capacity 6000 A Icn at 230 V AC 50/60 Hz conforming to EN/IEC 60898-150 kA Icu at 12...60 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 100...133 V AC 50/60 Hz conforming to EN/IEC 60947-210 kA Icu at 60...72 V DC conforming to EN/IEC 60947-215 kA Icu at 12...60 V DC conforming to EN/IEC 60947-2 Utilisation category Category A conforming to EN 60947-2Category A conforming to IEC 60947-2 Suitability for isolation Yes conforming to EN 60898-1Yes conforming to EN 60947-2Yes conforming to IEC 60898-1Yes conforming to IEC 60947-2 Standards EN 60898-1EN 60947-2IEC 60898-1IEC 60947-2 Quality labels NF Complementary Network frequency 50/60 Hz Magnetic tripping limit 8 x In +/- 20 % [Ics] rated service breaking capacity 50 kA 100 % conforming to EN 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 12...60 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 100...133 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 100...133 V AC 50/60 Hz6000 A 100 % conforming to EN 60898-1 - 230 V AC 50/60 Hz6000 A 100 % conforming to IEC 60898-1 - 230 V AC 50/60 Hz10 kA 100 % conforming to EN 60947-2 - 72 V DC10 kA 100 % conforming to IEC 60947-2 - 72 V DC15 kA 100 % conforming to EN 60947-2 - 12...60 V DC15 kA 100 % conforming to IEC 60947-2 - 12...60 V DC Limitation class 3 conforming to EN 60898-13 conforming to IEC 60898-1 [Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to EN 60947-2500 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to EN 60947-26 kV conforming to IEC 60947-2 Contact position indicator Yes Control type Toggle local signalling Trip indicator Mounting mode Fixed mounting support DIN rail Comb busbar and distribution block compatibility Top or bottom: YES 9 mm pitches 2 height 85 mm Width 18 mm Depth 78.5 mm Net weight 0.215 kg Colour White Mechanical durability 20000 cycles Electrical durability 10000 cycles Connections - terminals Single terminal (top or bottom) 1…25 mm² rigidSingle terminal (top or bottom) 1…16 mm² flexible Wire stripping length 14 mm for top or bottom connection Tightening torque 2 N.m top or bottom earth-leakage protection Without Environment IP degree of protection IP20 conforming to IEC 60529IP20 conforming to EN 60529 Pollution degree 3 conforming to EN 60947-23 conforming to IEC 60947-2 Overvoltage category IV Tropicalisation 2 conforming to IEC 60068-1 Relative humidity 95 % at 55 °C Operating altitude 0...2000 m Ambient air temperature for operation -35…70 °C Ambient air temperature for storage -40…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 1.7 cm Package 1 Length 7.5 cm Package 1 Weight 118.0 g Unit Type of Package 2 BB1 Number of Units in Package 2 12 Package 2 Height 3.0 cm Package 2 Width 30.0 cm Package 2 Length 20.0 cm Package 2 Weight 1.42 kg Unit Type of Package 3 S03 Number of Units in Package 3 132 Package 3 Height 30.0 cm Package 3 Width 30.0 cm Package 3 Length 40.0 cm Package 3 Weight 16.237 kg
$21.09
Schneider Electric Schneider Electric Miniature circuit breaker , Acti9 iC60N, 2P, 3 A, C curve, 6000 A (IEC 60898-1), 50 kA (IEC 60947-2) A9F74203
Description This Acti9 iC60N is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles, 3A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 50kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 6000A at 400VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. The product can be clipped on a DIN rail. Its width is 4 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 36mm x (H) 85mm x (D) 78.5mm. The weight is 0.25kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -35°C to 70°C. The storage temperature is -40°C to 85°C. Specifications Main Device application Distribution Range Acti9 Product name Acti9 iC60 Product or component type Miniature circuit-breaker Device short name IC60N Poles description 2P Number of protected poles 2 [In] rated current 3 A Network type ACDC Trip unit technology Thermal-magnetic Curve code C Breaking capacity 6000 A Icn at 400 V AC 50/60 Hz conforming to EN/IEC 60898-150 kA Icu at 12...60 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 100...133 V AC 50/60 Hz conforming to EN/IEC 60947-250 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-225 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-210 kA Icu at <= 125 V DC conforming to EN/IEC 60947-2 Utilisation category Category A conforming to EN 60947-2Category A conforming to IEC 60947-2 Suitability for isolation Yes conforming to EN 60898-1Yes conforming to EN 60947-2Yes conforming to IEC 60898-1Yes conforming to IEC 60947-2 Standards EN 60898-1IEC 60947-2EN 60947-2IEC 60898-1 Quality labels NF Complementary Network frequency 50/60 Hz Magnetic tripping limit 8 x In +/- 20 % [Ics] rated service breaking capacity 50 kA 100 % conforming to EN 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 220...240 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 380...415 V AC 50/60 Hz25 kA 100 % conforming to EN 60947-2 - 440 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 380...415 V AC 50/60 Hz25 kA 100 % conforming to IEC 60947-2 - 440 V AC 50/60 Hz50 kA 100 % conforming to IEC 60947-2 - 12...133 V AC 50/60 Hz50 kA 100 % conforming to EN 60947-2 - 12...133 V AC 50/60 Hz6000 A 100 % conforming to EN 60898-1 - 400 V AC 50/60 Hz6000 A 100 % conforming to IEC 60898-1 - 400 V AC 50/60 Hz10 kA 100 % conforming to IEC 60947-2 - 72...125 V DC10 kA 100 % conforming to EN 60947-2 - 72...125 V DC Limitation class 3 conforming to EN 60898-13 conforming to IEC 60898-1 [Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to EN 60947-2500 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to EN 60947-26 kV conforming to IEC 60947-2 Contact position indicator Yes Control type Toggle local signalling Trip indicator Mounting mode Fixed mounting support DIN rail Comb busbar and distribution block compatibility Top or bottom: YES 9 mm pitches 4 height 85 mm Width 36 mm Depth 78.5 mm Net weight 0.25 kg Colour White Mechanical durability 20000 cycles Electrical durability 10000 cycles Connections - terminals Single terminal (top or bottom) 1…25 mm² rigidSingle terminal (top or bottom) 1…16 mm² flexible Wire stripping length 14 mm for top or bottom connection Tightening torque 2 N.m top or bottom earth-leakage protection Separate block Environment IP degree of protection IP20 conforming to IEC 60529IP20 conforming to EN 60529 Pollution degree 3 conforming to EN 60947-23 conforming to IEC 60947-2 Overvoltage category IV Tropicalisation 2 conforming to IEC 60068-1 Relative humidity 95 % at 55 °C Operating altitude 0...2000 m Ambient air temperature for operation -35…70 °C Ambient air temperature for storage -40…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 3.5 cm Package 1 Width 7.5 cm Package 1 Length 9.4 cm Package 1 Weight 222.0 g Unit Type of Package 2 BB1 Number of Units in Package 2 6 Package 2 Height 3.42 cm Package 2 Width 30.0 cm Package 2 Length 20.0 cm Package 2 Weight 1.396 kg Unit Type of Package 3 S03 Number of Units in Package 3 66 Package 3 Height 30.0 cm Package 3 Width 30.0 cm Package 3 Length 40.0 cm Package 3 Weight 15.862 kg
$22.11
Schneider Electric Schneider Electric circuit breaker Easypact EZC100H - TMD - 50 A - 3 poles 3d EZC100H3050
Description EasyPact EZC100H is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 30kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 50A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100H is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100H Circuit breaker name Easypact EZC100H Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 50 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 10 kA Icu at 125 V DC 1P conforming to IEC 60947-210 kA Icu at 250 V DC 2P conforming to IEC 60947-210 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 15 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 125 V DC conforming to IEC 60947-25 kA at 250 V DC conforming to IEC 60947-250 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-250 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-25 kA at 440 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-27.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 50 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards JIS C8201-2-2EN/IEC 60947-1GB/T 14048.2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.0 cm Package 1 Width 8.5 cm Package 1 Length 14.0 cm Package 1 Weight 785.0 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 9.774 kg Unit Type of Package 3 P12 Number of Units in Package 3 192 Package 3 Height 50.0 cm Package 3 Width 80.0 cm Package 3 Length 120.0 cm Package 3 Weight 172.376 kg
$30.80
Schneider Electric Schneider Electric circuit breaker,EasyPact EZC100F ,TMD, 16A ,3 poles 3d EZC100F3016
Description EasyPact EZC100F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 10kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 16A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100F is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100F Circuit breaker name Easypact EZC100F Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 16 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code F Breaking capacity 25 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-25 kA Icu at 125 V DC 1P conforming to IEC 60947-25 kA Icu at 250 V DC 2P conforming to IEC 60947-25 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-27.5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 380...415 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 2.5 kA at 125 V DC conforming to IEC 60947-22.5 kA at 250 V DC conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-23.75 kA at 440 V AC 50/60 Hz conforming to IEC 60947-25 kA at 380...415 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 16 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60947 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards EN/IEC 60947-1JIS C8201-2-2GB/T 14048.2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to EN 50102 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 14.0 cm Package 1 Length 8.0 cm Package 1 Weight 792.0 g
$20.90
Schneider Electric Schneider Electric circuit breaker Easypact EZC100H - TMD - 30 A - 3 poles 3d EZC100H3030
Description EasyPact EZC100H is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 30kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 30A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100H is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100H Circuit breaker name Easypact EZC100H Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 30 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 10 kA Icu at 125 V DC 1P conforming to IEC 60947-210 kA Icu at 250 V DC 2P conforming to IEC 60947-210 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 15 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 125 V DC conforming to IEC 60947-25 kA at 250 V DC conforming to IEC 60947-250 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-250 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-25 kA at 440 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-27.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 30 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards JIS C8201-2-2EN/IEC 60947-1GB/T 14048.2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.5 cm Package 1 Length 14 cm Package 1 Weight 790 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 9.935 kg Unit Type of Package 3 P12 Number of Units in Package 3 384 Package 3 Height 75 cm Package 3 Width 80 cm Package 3 Length 120 cm Package 3 Weight 328 kg
$25.30
Schneider Electric Schneider Electric circuit breaker Easypact EZC100H - TMD - 100 A - 3 poles 3d EZC100H3100
Description EasyPact EZC100H is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 30kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 100A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100H is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100H Circuit breaker name Easypact EZC100H Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 100 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 10 kA Icu at 125 V DC 1P conforming to IEC 60947-210 kA Icu at 250 V DC 2P conforming to IEC 60947-210 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 15 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 125 V DC conforming to IEC 60947-25 kA at 250 V DC conforming to IEC 60947-250 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-250 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-25 kA at 440 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-27.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 100 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards GB/T 14048.2JIS C8201-2-2EN/IEC 60947-1EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.5 cm Package 1 Length 14.0 cm Package 1 Weight 839.0 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 10.12 kg Unit Type of Package 3 P12 Number of Units in Package 3 192 Package 3 Height 80.0 cm Package 3 Width 80.0 cm Package 3 Length 120.0 cm Package 3 Weight 175.568 kg
$34.10
Schneider Electric Schneider Electric circuit breaker Easypact EZC100F - TMD - 50 A - 3 poles 3d EZC100F3050
Description EasyPact EZC100F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 10kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 50A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100F is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100F Circuit breaker name Easypact EZC100F Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 50 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code F Breaking capacity 25 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-25 kA Icu at 125 V DC 1P conforming to IEC 60947-25 kA Icu at 250 V DC 2P conforming to IEC 60947-25 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-27.5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 12.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 125 V DC conforming to IEC 60947-22.5 kA at 250 V DC conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-23.75 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 50 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards EN/IEC 60947-1GB/T 14048.2JIS C8201-2-2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.4 cm Package 1 Width 8.2 cm Package 1 Length 14.0 cm Package 1 Weight 758.0 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 9.496 kg Unit Type of Package 3 P12 Number of Units in Package 3 384 Package 3 Height 75 cm Package 3 Width 120 cm Package 3 Length 80 cm Package 3 Weight 317 kg
$35.31
Schneider Electric Schneider Electric circuit breaker Easypact EZC100H - TMD - 60 A - 3 poles 3d EZC100H3060
Description EasyPact EZC100H is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 30kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 60A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100H is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100H Circuit breaker name Easypact EZC100H Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 60 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 10 kA Icu at 125 V DC 1P conforming to IEC 60947-210 kA Icu at 250 V DC 2P conforming to IEC 60947-210 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 15 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 125 V DC conforming to IEC 60947-25 kA at 250 V DC conforming to IEC 60947-250 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-250 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-25 kA at 440 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-27.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 60 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards GB/T 14048.2EN/IEC 60947-2EN/IEC 60947-1JIS C8201-2-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.5 cm Package 1 Length 14.0 cm Package 1 Weight 843.0 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 10.153 kg Unit Type of Package 3 P12 Number of Units in Package 3 192 Package 3 Height 80.0 cm Package 3 Width 80.0 cm Package 3 Length 120.0 cm Package 3 Weight 175.184 kg
$30.80
Schneider Electric Schneider Electric circuit breaker Easypact EZC100F - TMD - 15 A - 3 poles 3d EZC100F3015
Description EasyPact EZC100F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 10kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 15A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100F is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100F Circuit breaker name Easypact EZC100F Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 15 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code F Breaking capacity 25 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-25 kA Icu at 125 V DC 1P conforming to IEC 60947-25 kA Icu at 250 V DC 2P conforming to IEC 60947-25 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-27.5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 12.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 125 V DC conforming to IEC 60947-22.5 kA at 250 V DC conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-23.75 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 15 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards JIS C8201-2-2EN/IEC 60947-1GB/T 14048.2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.2 cm Package 1 Length 14.0 cm Package 1 Weight 817.0 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 9.892 kg Unit Type of Package 3 P12 Number of Units in Package 3 384 Package 3 Height 75 cm Package 3 Width 120 cm Package 3 Length 80 cm Package 3 Weight 330 kg
$29.22
Schneider Electric Schneider Electric circuit breaker Easypact EZC250H - TMD - 200 A - 3 poles 3d EZC250H3200
Description This is a 200A circuit breaker for EasyPact EZC250H. This product can work below rated operational voltage(Ue) 550VAC at 50/60Hz or 250VDC network. The ultimate breaking capacity(Icu) is shown differently, depended on the condition of network, Ics=50%Icu if need to match. This version of product is designed 3 poles frame with detection on 3 poles,equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947, CE certification and some independent lab(KEMA,ASEFA,TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947, and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure,and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle,and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning , depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 105mm(width),165mm(height),60mm(Depth). Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC250H Circuit breaker name Easypact EZC250H Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 200 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 10 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 125 V DC 1P conforming to IEC 60947-230 kA Icu at 250 V DC 2P conforming to IEC 60947-236 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-236 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-285 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-285 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-215 kA at 125 V DC conforming to IEC 60947-215 kA at 250 V DC conforming to IEC 60947-218 kA at 380 V AC 50/60 Hz conforming to IEC 60947-218 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 440 V AC 50/60 Hz conforming to IEC 60947-242.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-242.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 200 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 5000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 35 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 165 mm Width 105 mm Depth 60 mm Environment Standards EN/IEC 60947-1GB/T 14048.2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 10.600 cm Package 1 Width 11.600 cm Package 1 Length 18.200 cm Package 1 Weight 1.588 kg Unit Type of Package 2 S03 Number of Units in Package 2 8 Package 2 Height 30.000 cm Package 2 Width 30.000 cm Package 2 Length 40.000 cm Package 2 Weight 13.623 kg Unit Type of Package 3 P12 Number of Units in Package 3 64 Package 3 Height 50.000 cm Package 3 Width 80.000 cm Package 3 Length 120.000 cm Package 3 Weight 120.984 kg
$121.00
Schneider Electric Schneider Electric circuit breaker, Easypact EZC400H, TMD, 400A, 3 poles 3d EZC400H3400N
Description This is a 400A circuit breaker for EasyPact EZC400H. This product can work below rated operational voltage(Ue) 440VAC at 50/60Hz. The ultimate breaking capacity(Icu) is 50kA at 440V, in terms of complete range Ics=100%Icu(Ics= 50%Icu at 440V. This version of product is designed 3 poles frame with detection on 3 poles,equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947, CE certification and some independent lab(KEMA,ASEFA,TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947, and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure,and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle,and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning , depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 140mm(width),255mm(height),110mm(Depth). Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC400H Circuit breaker name Easypact EZC400H Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 400 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 250 V DC conforming to IEC 60947-2440 V AC 50/60 Hz conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 50 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-270 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-225 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-225 kA at 440 V AC 50/60 Hz conforming to IEC 60947-235 kA at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 400 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60947 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 3000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 45 mm local signalling Positive contact indication Contact position indicator Yes Magnetic tripping current 4000 A Neutral protection setting Without protection Long time pick-up adjustment type Ir Fixed Long time delay adjustment type Fixed earth-leakage protection Without height 255 mm Width 185 mm Depth 140 mm Net weight 6.4 kg Quantity per set 1 piece Colour Black Environment Standards JIS C8201-2-2EN/IEC 60947-2GB/T 14048.2EN/IEC 60947-1 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to EN 50102 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 15.0 cm Package 1 Width 16.0 cm Package 1 Length 29.0 cm Package 1 Weight 5.319 kg Unit Type of Package 2 S04 Number of Units in Package 2 3 Package 2 Height 30.0 cm Package 2 Width 40.0 cm Package 2 Length 60.0 cm Package 2 Weight 16.723 kg Unit Type of Package 3 PAL Number of Units in Package 3 36 Package 3 Height 80.0 cm Package 3 Width 120.0 cm Package 3 Length 36.0 cm Package 3 Weight 208.0 kg
$185.90
Schneider Electric Schneider Electric circuit breaker Easypact EZC250H - TMD - 175 A - 3 poles 3d EZC250H3175
Description This is a 175A circuit breaker for EasyPact EZC250H. This product can work below rated operational voltage(Ue) 550VAC at 50/60Hz or 250VDC network. The ultimate breaking capacity(Icu) is shown differently, depended on the condition of network, Ics=50%Icu if need to match. This version of product is designed 3 poles frame with detection on 3 poles,equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947, CE certification and some independent lab(KEMA,ASEFA,TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947, and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure,and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle,and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning , depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 105mm(width),165mm(height),60mm(Depth). Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC250H Circuit breaker name Easypact EZC250H Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 175 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 10 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 125 V DC 1P conforming to IEC 60947-230 kA Icu at 250 V DC 2P conforming to IEC 60947-236 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-236 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-285 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-285 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-215 kA at 125 V DC conforming to IEC 60947-215 kA at 250 V DC conforming to IEC 60947-218 kA at 380 V AC 50/60 Hz conforming to IEC 60947-218 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 440 V AC 50/60 Hz conforming to IEC 60947-242.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-242.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 175 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 5000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 35 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 165 mm Width 105 mm Depth 60 mm Environment Standards GB/T 14048.2EN/IEC 60947-1EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 11.4 cm Package 1 Width 11.3 cm Package 1 Length 18 cm Package 1 Weight 1.64 kg Unit Type of Package 2 S03 Number of Units in Package 2 8 Package 2 Height 30 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 13.61 kg
$130.44
Schneider Electric Schneider Electric circuit breaker,Easypact EZC400N ,TMD, 400A ,3 poles 3d EZC400N3400N
Description EasyPact EZC400N is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 400A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (140mm x 255mm x 110mm) comes with a variety of optional functions and accessories. Easypact EZC400N is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC400N Circuit breaker name Easypact EZC400N Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 400 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 250 V DC conforming to IEC 60947-2440 V AC 50/60 Hz conforming to IEC 60947-2 Breaking capacity code N Breaking capacity 36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-240 kA Icu at 220/230 V AC 50/60 Hz conforming to IEC 60947-236 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-236 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 18 kA at 440 V AC 50/60 Hz conforming to IEC 60947-220 kA at 220/230 V AC 50/60 Hz conforming to IEC 60947-218 kA at 380 V AC 50/60 Hz conforming to IEC 60947-218 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 400 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60947 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 1000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 44 mm local signalling Positive contact indication Contact position indicator Yes Magnetic tripping current 5000 A Neutral protection setting Without protection Long time pick-up adjustment type Ir Fixed Long time delay adjustment type Fixed earth-leakage protection Without height 255 mm Width 185 mm Depth 140 mm Net weight 4.8 kg Quantity per set 1 piece Colour Black Environment Standards EN/IEC 60947-2GB/T 14048.2JIS C8201-2-2EN/IEC 60947-1 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to EN 50102 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 15.200 cm Package 1 Width 16.000 cm Package 1 Length 29.400 cm Package 1 Weight 4.917 kg Unit Type of Package 2 S04 Number of Units in Package 2 3 Package 2 Height 30.000 cm Package 2 Width 40.000 cm Package 2 Length 60.000 cm Package 2 Weight 15.520 kg
$247.33
Schneider Electric Schneider Electric circuit breaker Easypact EZC100F - TMD - 25 A - 3 poles 3d EZC100F3025
Description EasyPact EZC100F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 10kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 25A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100F is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100F Circuit breaker name Easypact EZC100F Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 25 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code F Breaking capacity 25 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-25 kA Icu at 125 V DC 1P conforming to IEC 60947-25 kA Icu at 250 V DC 2P conforming to IEC 60947-25 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-27.5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 12.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 125 V DC conforming to IEC 60947-22.5 kA at 250 V DC conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-23.75 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 25 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards JIS C8201-2-2EN/IEC 60947-2EN/IEC 60947-1GB/T 14048.2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.5 cm Package 1 Length 14 cm Package 1 Weight 828 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 10.42 kg Unit Type of Package 3 P12 Number of Units in Package 3 384 Package 3 Height 75 cm Package 3 Width 80 cm Package 3 Length 120 cm Package 3 Weight 331 kg
$27.50
Schneider Electric Schneider Electric circuit breaker Easypact EZC100H - TMD - 15 A - 3 poles 3d EZC100H3015
Description EasyPact EZC100H is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 30kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 15A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100H is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100H Circuit breaker name Easypact EZC100H Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 15 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 10 kA Icu at 125 V DC 1P conforming to IEC 60947-210 kA Icu at 250 V DC 2P conforming to IEC 60947-210 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2100 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 15 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 125 V DC conforming to IEC 60947-25 kA at 250 V DC conforming to IEC 60947-250 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-250 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-25 kA at 440 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-27.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 15 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards EN/IEC 60947-1JIS C8201-2-2EN/IEC 60947-2GB/T 14048.2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.5 cm Package 1 Length 14.0 cm Package 1 Weight 790.0 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 9.854 kg Unit Type of Package 3 PAL Number of Units in Package 3 384 Package 3 Height 80.0 cm Package 3 Width 120.0 cm Package 3 Length 384.0 cm Package 3 Weight 314.88 kg
$30.69
Schneider Electric Schneider Electric EZC250N3225 circuit breaker Easypact EZC250N - TMD - 225 A - 3 poles 3d
Description EasyPact EZC250N is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 225A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (105mm x 165mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC250N is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC250N Circuit breaker name Easypact EZC250N Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 225 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code N Breaking capacity 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 125 V DC 1P conforming to IEC 60947-220 kA Icu at 250 V DC 2P conforming to IEC 60947-225 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-28 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-225 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-210 kA at 125 V DC conforming to IEC 60947-210 kA at 250 V DC conforming to IEC 60947-225 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-24 kA at 550 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 380 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 225 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 5000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 35 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 165 mm Width 105 mm Depth 60 mm Environment Standards EN/IEC 60947-2GB/T 14048.2EN/IEC 60947-1 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 11 cm Package 1 Width 11.5 cm Package 1 Length 18 cm Package 1 Weight 1.57 kg Unit Type of Package 2 S03 Number of Units in Package 2 8 Package 2 Height 30 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 12.95 kg
$129.60
Schneider Electric Schneider Electric EZC400H3320N circuit breaker, Easypact EZC400H, TMD, 320A, 3 poles 3d
Description his is a 320A circuit breaker for EasyPact EZC400H. This product can work below rated operational voltage(Ue) 440VAC at 50/60Hz. The ultimate breaking capacity(Icu) is 50kA at 440V, in terms of complete range Ics=100%Icu(Ics= 50%Icu at 440V. This version of product is designed 3 poles frame with detection on 3 poles,equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947, CE certification and some independent lab(KEMA,ASEFA,TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947, and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure,and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle,and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning , depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 140mm(width),255mm(height),110mm(Depth). Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC400H Circuit breaker name Easypact EZC400H Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 400 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 250 V DC conforming to IEC 60947-2440 V AC 50/60 Hz conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 50 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-270 kA Icu at 220/230 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-225 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-225 kA at 440 V AC 50/60 Hz conforming to IEC 60947-235 kA at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 320 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60947 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 3000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 45 mm local signalling Positive contact indication Contact position indicator Yes Magnetic tripping current 4000 A Neutral protection setting Without protection Long time pick-up adjustment type Ir Fixed Long time delay adjustment type Fixed earth-leakage protection Without height 255 mm Width 185 mm Depth 140 mm Net weight 6.4 kg Quantity per set 1 piece Colour Black Environment Standards EN/IEC 60947-2GB/T 14048.2EN/IEC 60947-1JIS C8201-2-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to EN 50102 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 15.0 cm Package 1 Width 16.0 cm Package 1 Length 29.0 cm Package 1 Weight 5.231 kg Unit Type of Package 2 S04 Number of Units in Package 2 3 Package 2 Height 30.0 cm Package 2 Width 40.0 cm Package 2 Length 60.0 cm Package 2 Weight 16.459 kg Unit Type of Package 3 PAL Number of Units in Package 3 36 Package 3 Height 80.0 cm Package 3 Width 120.0 cm Package 3 Length 36.0 cm Package 3 Weight 208.0 kg
$185.90
Schneider Electric Schneider Electric EZC250H3150 circuit breaker Easypact EZC250H - TMD - 150 A - 3 poles 3d
Description This is a 150A circuit breaker for EasyPact EZC250H. This product can work below rated operational voltage(Ue) 550VAC at 50/60Hz or 250VDC network. The ultimate breaking capacity(Icu) is shown differently, depended on the condition of network, Ics=50%Icu if need to match. This version of product is designed 3 poles frame with detection on 3 poles,equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947, CE certification and some independent lab(KEMA,ASEFA,TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947, and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure,and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle,and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning , depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 105mm(width),165mm(height),60mm(Depth). Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC250H Circuit breaker name Easypact EZC250H Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 150 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 10 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-230 kA Icu at 125 V DC 1P conforming to IEC 60947-230 kA Icu at 250 V DC 2P conforming to IEC 60947-236 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-236 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-285 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-285 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-215 kA at 125 V DC conforming to IEC 60947-215 kA at 250 V DC conforming to IEC 60947-218 kA at 380 V AC 50/60 Hz conforming to IEC 60947-218 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 440 V AC 50/60 Hz conforming to IEC 60947-242.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-242.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 150 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 5000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 35 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 165 mm Width 105 mm Depth 60 mm Environment Standards GB/T 14048.2EN/IEC 60947-2EN/IEC 60947-1JIS C8201-2-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 11.4 cm Package 1 Width 11.3 cm Package 1 Length 18 cm Package 1 Weight 1.64 kg Unit Type of Package 2 S03 Number of Units in Package 2 8 Package 2 Height 30 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 13.61 kg
$130.44
Schneider Electric Schneider Electric circuit breaker Easypact EZC100F - TMD - 30 A - 3 poles 3d
Description EasyPact EZC100F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 10kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 30A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100F is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100F Circuit breaker name Easypact EZC100F Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 30 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code F Breaking capacity 25 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-25 kA Icu at 125 V DC 1P conforming to IEC 60947-25 kA Icu at 250 V DC 2P conforming to IEC 60947-25 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-27.5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 12.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 125 V DC conforming to IEC 60947-22.5 kA at 250 V DC conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-23.75 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 30 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards EN/IEC 60947-1GB/T 14048.2JIS C8201-2-2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.5 cm Package 1 Length 14.0 cm Package 1 Weight 763.0 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 9.512 kg Unit Type of Package 3 P12 Number of Units in Package 3 384 Package 3 Height 75 cm Package 3 Width 120 cm Package 3 Length 80 cm Package 3 Weight 318 kg
$29.22
Schneider Electric Schneider Electric circuit breaker Easypact EZC250N - TMD - 200 A - 3 poles 3d
Description EasyPact EZC250N is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 200A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (105mm x 165mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC250N is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC250N Circuit breaker name Easypact EZC250N Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 200 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code N Breaking capacity 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 125 V DC 1P conforming to IEC 60947-220 kA Icu at 250 V DC 2P conforming to IEC 60947-225 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-28 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-225 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-210 kA at 125 V DC conforming to IEC 60947-210 kA at 250 V DC conforming to IEC 60947-225 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-24 kA at 550 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 380 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 200 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 5000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 35 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 165 mm Width 105 mm Depth 60 mm Environment Standards EN/IEC 60947-1GB/T 14048.2EN/IEC 60947-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 10.5 cm Package 1 Width 11.5 cm Package 1 Length 18.0 cm Package 1 Weight 1.57 kg Unit Type of Package 2 S03 Number of Units in Package 2 8 Package 2 Height 30 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 12.94 kg Unit Type of Package 3 P12 Number of Units in Package 3 64 Package 3 Height 50 cm Package 3 Width 80 cm Package 3 Length 120 cm Package 3 Weight 120.86 kg Contractual warranty Warranty 18 months
$121.00
Schneider Electric Schneider Electric circuit breaker Easypact EZC100F - TMD - 60 A - 3 poles 3d
Description EasyPact EZC100F is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 10kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 60A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (75mm x 130mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC100F is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC100F Circuit breaker name Easypact EZC100F Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 60 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code F Breaking capacity 25 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-25 kA Icu at 125 V DC 1P conforming to IEC 60947-25 kA Icu at 250 V DC 2P conforming to IEC 60947-25 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-210 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-27.5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 12.5 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-22.5 kA at 125 V DC conforming to IEC 60947-22.5 kA at 250 V DC conforming to IEC 60947-22.5 kA at 550 V AC 50/60 Hz conforming to IEC 60947-25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-25 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-23.75 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 60 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 8500 cycles Electrical durability Category A: 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 25 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 130 mm Width 75 mm Depth 60 mm Environment Standards EN/IEC 60947-2JIS C8201-2-2EN/IEC 60947-1GB/T 14048.2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 9.5 cm Package 1 Width 8.5 cm Package 1 Length 14.0 cm Package 1 Weight 786.0 g Unit Type of Package 2 S02 Number of Units in Package 2 12 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 9.792 kg Unit Type of Package 3 P12 Number of Units in Package 3 384 Package 3 Height 75 cm Package 3 Width 120 cm Package 3 Length 80 cm Package 3 Weight 326 kg Contractual warranty Warranty 18 months
$35.31
Schneider Electric Schneider Electric circuit breaker Easypact EZC400H - TMD - 350 A - 3 poles 3
Description This is a 350A circuit breaker for EasyPact EZC400H. This product can work below rated operational voltage(Ue) 440VAC at 50/60Hz. The ultimate breaking capacity(Icu) is 50kA at 440V, in terms of complete range Ics=100%Icu(Ics= 50%Icu at 440V. This version of product is designed 3 poles frame with detection on 3 poles,equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947, CE certification and some independent lab(KEMA,ASEFA,TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947, and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure,and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle,and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning , depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 140mm(width),255mm(height),110mm(Depth). Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC400H Circuit breaker name Easypact EZC400H Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 400 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 250 V DC conforming to IEC 60947-2440 V AC 50/60 Hz conforming to IEC 60947-2 Breaking capacity code H Breaking capacity 50 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-270 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 25 kA at 380 V AC 50/60 Hz conforming to IEC 60947-225 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-225 kA at 440 V AC 50/60 Hz conforming to IEC 60947-235 kA at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 350 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60947 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 1000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 44 mm local signalling Positive contact indication Contact position indicator Yes Magnetic tripping current 3200 A Neutral protection setting Without protection Long time pick-up adjustment type Ir Fixed Long time delay adjustment type Fixed earth-leakage protection Without height 255 mm Width 185 mm Depth 140 mm Net weight 6.4 kg Quantity per set 1 piece Colour Black Environment Standards GB/T 14048.2EN/IEC 60947-2EN/IEC 60947-1JIS C8201-2-2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to EN 50102 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 15.0 cm Package 1 Width 16.0 cm Package 1 Length 29.0 cm Package 1 Weight 5.313 kg Unit Type of Package 2 S04 Number of Units in Package 2 3 Package 2 Height 30.0 cm Package 2 Width 40.0 cm Package 2 Length 60.0 cm Package 2 Weight 16.705 kg Unit Type of Package 3 PAL Number of Units in Package 3 36 Package 3 Height 80.0 cm Package 3 Width 120.0 cm Package 3 Length 36.0 cm Package 3 Weight 208.0 kg Contractual warranty Warranty 18 months
$236.50
Schneider Electric Schneider Electric circuit breaker Easypact EZC250N - TMD - 175 A - 3 poles 3d
Description EasyPact EZC250N is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 175A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (105mm x 165mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC250N is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC250N Circuit breaker name Easypact EZC250N Device application Distribution Poles description 3P Protected poles description 3t Network type ACDC Network frequency 50/60 Hz [In] rated current 175 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code N Breaking capacity 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 125 V DC 1P conforming to IEC 60947-220 kA Icu at 250 V DC 2P conforming to IEC 60947-225 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-28 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-225 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-210 kA at 125 V DC conforming to IEC 60947-210 kA at 250 V DC conforming to IEC 60947-225 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-24 kA at 550 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 380 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 175 A at 50 °C Protection type Overload protectionShort-circuit protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 5000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 35 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 165 mm Width 105 mm Depth 60 mm Environment Standards EN/IEC 60947-2GB/T 14048.2EN/IEC 60947-1 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 11 cm Package 1 Width 11.5 cm Package 1 Length 18 cm Package 1 Weight 1.57 kg Unit Type of Package 2 S03 Number of Units in Package 2 8 Package 2 Height 30 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 13 kg Contractual warranty Warranty 18 months
$121.00
Schneider Electric Schneider Electric circuit breaker Easypact EZC250N - TMD - 250 A - 3 poles 3d
Description EasyPact EZC250N is a 3 poles fixed circuit breaker designed for the protection of low voltage electrical installations. It is used for standard applications in industries and buildings, offering good performance at competitive price The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 550VAC 50/60Hz or 250VDC. The rating of the thermal-magnetic trip unit is 250A. The trip unit provides fixed overload and instantaneous protections. This 3 poles version (105mm x 165mm x 60mm) comes with a variety of optional functions and accessories. Easypact EZC250N is compliant with international standards (IEC 60947, UL 508) and marine certifications. Specifications Main range of product EasyPact Product or component type Circuit breaker Device short name Easypact EZC250N Circuit breaker name Easypact EZC250N Device application Distribution Poles description 3P Protected poles description 3t Network type DCAC Network frequency 50/60 Hz [In] rated current 250 A at 40 °C [Ui] rated insulation voltage 690 V AC 50/60 Hz conforming to IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-2 [Ue] rated operational voltage 550 V AC 50/60 Hz conforming to IEC 60947-2250 V DC conforming to IEC 60947-2 Breaking capacity code N Breaking capacity 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-250 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-220 kA Icu at 125 V DC 1P conforming to IEC 60947-220 kA Icu at 250 V DC 2P conforming to IEC 60947-225 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-225 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-28 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2 [Ics] rated service breaking capacity 10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-225 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-210 kA at 125 V DC conforming to IEC 60947-210 kA at 250 V DC conforming to IEC 60947-225 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-24 kA at 550 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 380 V AC 50/60 Hz conforming to IEC 60947-212.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 Suitability for isolation Yes conforming to IEC 60947-2 utilisation category Category A Trip unit name TM-D Trip unit technology Thermal-magnetic Trip unit rating 250 A at 50 °C Protection type Short-circuit protectionOverload protection Pollution degree 3 conforming to IEC 60664-13 conforming to IEC 947-1 Complementary Control type Toggle Mounting mode Fixed mounting support Backplate Upside connection Front downside connection Front Mechanical durability 10000 cycles Electrical durability Category A: 5000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 Connection pitch 35 mm local signalling Positive contact indication Neutral protection setting Without protection earth-leakage protection Without height 165 mm Width 105 mm Depth 60 mm Environment Standards EN/IEC 60947-2EN/IEC 60947-1GB/T 14048.2 IP degree of protection IP20 conforming to IEC 60529 IK degree of protection IK07 conforming to IEC 62262 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -35…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 12.0 cm Package 1 Width 11.0 cm Package 1 Length 18.2 cm Package 1 Weight 1.583 kg Unit Type of Package 2 S03 Number of Units in Package 2 8 Package 2 Height 30 cm Package 2 Width 30 cm Package 2 Length 40 cm Package 2 Weight 14.09 kg Unit Type of Package 3 P12 Number of Units in Package 3 64 Package 3 Height 50 cm Package 3 Width 80 cm Package 3 Length 120 cm Package 3 Weight 124.7 kg Contractual warranty Warranty 18 months
$121.00
