SMC Clamp Cylinder

SMC CKZT40-90T — CKZT series power clamp cylinder, ø40 bore, base mounted. A toggle mechanism multiplies the cylinder force and locks the arm at the clamped position, and the whole unit is built to survive a welding cell. Specification — CKZT40-90T Series CKZT (power clamp cylinder, base type) Bore ø40 mm Clamp force 1,200 N (100 mm arm at 0.5 MPa) Dimensions 54 mm wide × 265.9 mm high Construction Anti-spatter Switch Proximity switch rated for welding magnetic fields Product weight 1,600 g Toggle mechanism and locking A plain cylinder holds a clamp only as long as air pressure holds. The toggle linkage in a power clamp passes over centre at the clamped position, so the arm is held mechanically — air loss does not release the part, and the holding force does not depend on the line staying up. The same geometry multiplies the cylinder force, which is how a ø40 bore produces 1,200 N at the arm. Built for the welding cell Weld spatter destroys ordinary cylinders: it sticks to the rod, tears the seal, and jams the linkage. The anti-spatter construction shields the moving parts, and the proximity switches are specified to keep working in the magnetic field around a weld gun, where a standard reed switch gives false signals. At 54 mm wide the unit also fits between fixtures on a crowded jig. Typical use Body-in-white welding jigs, fixture clamping on assembly lines, and any station where a part must stay located through a process that would defeat a standard clamp. Ordering Order by the full code CKZT40-90T. Bore, arm arrangement and switch type are all in the code. A manual handle version with a lock specification is available where the clamp has to be released by hand. Supply from Korea Genuine SMC, stocked and shipped from Gyeonggi-do, Korea, with export packing and commercial documents prepared as standard.

Read more less

SMC MK2TG20-10RN — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 20mm bore, 10mm stroke, double acting. Specification — MK2TG20-10RN Mounting Head side flange Bore 20mm Fluid Air Action Double acting Cushion Rubber bumper Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 12 mm Weight 600 g Specification values above are for model code MK2TG20-10RN as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB63-50RN — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 63mm bore, 50mm stroke, double acting. Specification — MK2TB63-50RN Bore 63mm Fluid Air Action Double acting Cushion Rubber bumper Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 25 mm Weight 3,954 g Specification values above are for model code MK2TB63-50RN as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB63-50R — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 63mm bore, 50mm stroke, double acting. Specification — MK2TB63-50R Bore 63mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M12X1.75 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 25 mm Weight 3,354 g Specification values above are for model code MK2TB63-50R as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB63-50L — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 63mm bore, 50mm stroke, double acting. Specification — MK2TB63-50L Bore 63mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M12X1.75 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 25 mm Weight 3,354 g Specification values above are for model code MK2TB63-50L as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB63-20R — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 63mm bore, 20mm stroke, double acting. Specification — MK2TB63-20R Bore 63mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M12X1.75 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 25 mm Weight 2,609 g Specification values above are for model code MK2TB63-20R as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB50-20R-M9N — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 50mm bore, 20mm stroke, double acting. Specification — MK2TB50-20R-M9N Bore 50mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M12X1.75 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 20 mm Weight 2,000 g Specification values above are for model code MK2TB50-20R-M9N as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB50-20R — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 50mm bore, 20mm stroke, double acting. Specification — MK2TB50-20R Bore 50mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M12X1.75 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 20 mm Weight 2,049 g Specification values above are for model code MK2TB50-20R as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB50-20L — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 50mm bore, 20mm stroke, double acting. Specification — MK2TB50-20L Bore 50mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M12X1.75 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 20 mm Weight 2,049 g Specification values above are for model code MK2TB50-20L as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB40-20R — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MK2TB40-20R Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 1,127 g Specification values above are for model code MK2TB40-20R as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB40-10L — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 40mm bore, 10mm stroke, double acting. Specification — MK2TB40-10L Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 1,008 g Specification values above are for model code MK2TB40-10L as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB32-20RN — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MK2TB32-20RN Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 1,114 g Specification values above are for model code MK2TB32-20RN as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB32-20R-A93 — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MK2TB32-20R-A93 Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 926 g Specification values above are for model code MK2TB32-20R-A93 as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB32-20R — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MK2TB32-20R Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 914 g Specification values above are for model code MK2TB32-20R as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB32-20L-A93 — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MK2TB32-20L-A93 Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 926 g Specification values above are for model code MK2TB32-20L-A93 as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB25-10L — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 25mm bore, 10mm stroke, double acting. Specification — MK2TB25-10L Bore 25mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M8X1.25 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 12 mm Weight 448 g Specification values above are for model code MK2TB25-10L as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB20-20R — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 20mm bore, 20mm stroke, double acting. Specification — MK2TB20-20R Bore 20mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M8X1.25 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 12 mm Weight 433 g Specification values above are for model code MK2TB20-20R as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB20-10RN — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 20mm bore, 10mm stroke, double acting. Specification — MK2TB20-10RN Bore 20mm Fluid Air Action Double acting Cushion Rubber bumper Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 12 mm Weight 467 g Specification values above are for model code MK2TB20-10RN as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MK2TB20-10R-M9BL — MK2T Series Rotary Clamp Cylinder Double Guide Type. This code specifies 20mm bore, 10mm stroke, double acting. Specification — MK2TB20-10R-M9BL Bore 20mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M8X1.25 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 12 mm Weight 433 g Specification values above are for model code MK2TB20-10R-M9BL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK2T seriesThe double guide type adopts a guide roller in the rotating mechanism to improve non-rotating accuracy. Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20RZ-M9PW — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke. Specification — MKB40-20RZ-M9PW Weight 650 g Specification values above are for model code MKB40-20RZ-M9PW as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20RZ-M9PL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20RZ-M9PL Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 652 g Specification values above are for model code MKB40-20RZ-M9PL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20RZ-M9NL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20RZ-M9NL Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 638 g Specification values above are for model code MKB40-20RZ-M9NL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20RZ-M9BVL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20RZ-M9BVL Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 632 g Specification values above are for model code MKB40-20RZ-M9BVL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20RZ-A93LS — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20RZ-A93LS Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 600 g Specification values above are for model code MKB40-20RZ-A93LS as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20RZ-A93L — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20RZ-A93L Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 630 g Specification values above are for model code MKB40-20RZ-A93L as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20RZ — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20RZ Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 570 g Specification values above are for model code MKB40-20RZ as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20LZ-M9PW — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke. Specification — MKB40-20LZ-M9PW Weight 650 g Specification values above are for model code MKB40-20LZ-M9PW as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20LZ-M9PL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20LZ-M9PL Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 652 g Specification values above are for model code MKB40-20LZ-M9PL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20LZ-M9P — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke. Specification — MKB40-20LZ-M9P Weight 650 g Specification values above are for model code MKB40-20LZ-M9P as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20LZ-M9NL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20LZ-M9NL Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 638 g Specification values above are for model code MKB40-20LZ-M9NL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20LZ-M9BW — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20LZ-M9BW Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 584 g Specification values above are for model code MKB40-20LZ-M9BW as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20LZ-M9BL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20LZ-M9BL Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 636 g Specification values above are for model code MKB40-20LZ-M9BL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB40-20LZ-A73 — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 40mm bore, 20mm stroke, double acting. Specification — MKB40-20LZ-A73 Bore 40mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 597 g Specification values above are for model code MKB40-20LZ-A73 as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20RZ-M9PW — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke. Specification — MKB32-20RZ-M9PW Weight 540 g Specification values above are for model code MKB32-20RZ-M9PW as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20RZ-M9P — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20RZ-M9P Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 510 g Specification values above are for model code MKB32-20RZ-M9P as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20RZ-M9NW — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20RZ-M9NW Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 510 g Specification values above are for model code MKB32-20RZ-M9NW as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20RZ-M9N — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20RZ-M9N Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 510 g Specification values above are for model code MKB32-20RZ-M9N as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20RZ-M9BWL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20RZ-M9BWL Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 570 g Specification values above are for model code MKB32-20RZ-M9BWL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20RZ-M9BL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20RZ-M9BL Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 560 g Specification values above are for model code MKB32-20RZ-M9BL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20RZ-A93Z — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20RZ-A93Z Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 588 g Specification values above are for model code MKB32-20RZ-A93Z as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20RZ-A93LS — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20RZ-A93LS Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 524 g Specification values above are for model code MKB32-20RZ-A93LS as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20LZ-M9P — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20LZ-M9P Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 510 g Specification values above are for model code MKB32-20LZ-M9P as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20LZ-M9NLS — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke. Specification — MKB32-20LZ-M9NLS Weight 540 g Specification values above are for model code MKB32-20LZ-M9NLS as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20LZ-M9BWL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20LZ-M9BWL Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 570 g Specification values above are for model code MKB32-20LZ-M9BWL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20LZ-M9B — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20LZ-M9B Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Fluid temp. min -10 °C Fluid temp. max 60 °C Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 508 g Specification values above are for model code MKB32-20LZ-M9B as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20LZ-A93Z — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20LZ-A93Z Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 588 g Specification values above are for model code MKB32-20LZ-A93Z as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20LZ-A93VL — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20LZ-A93VL Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 554 g Specification values above are for model code MKB32-20LZ-A93VL as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less

SMC MKB32-20LZ-A93LS — MK Series Rotary Clamp Cylinder Standard Type. This code specifies 32mm bore, 20mm stroke, double acting. Specification — MKB32-20LZ-A93LS Bore 32mm Fluid Air Action Double acting Cushion Rubber bumper Rod end male thread M10X1.5 Min. operating pressure 0.1 MPa Max. operating pressure 1.0 MPa Proof pressure 1.5 MPa Ambient temp. min -10 °C Ambient temp. max 60 °C Lubrication Non-lube Piston speed min 50 mm/s Piston speed max 200 mm/s Rod diameter 16 mm Weight 524 g Specification values above are for model code MKB32-20LZ-A93LS as published by SMC. A change of one character in the suffix gives a different part, so order by the full code. About the SMC MK series 3 times higher allowable moment of inertia(equivalent to the high load type MK2 series) Small auto switches can be attached to 4 sides Total length is the same as the existing MK series Existing MK and MK2 integrated into the New MK series Supply from KoreaGenuine SMC, sourced through Korean distribution and shipped from Korea by FedEx International Priority with export packing and commercial documents. Need a different stroke, switch or suffix? Send the full model code and quantity and we will quote it.

Read more less
