| Oil resistant/oil proof |
Oil proof type |
| Sensing type |
Diffuse reflective type |
| Sensing distance |
1m |
| Sensing target |
Opaque, Translucent material |
| Light source |
Red LED(660nm) |
| Response time |
Max. 1ms |
| Power voltage |
10-30VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 30mA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by switch) |
| Control output |
PNP open collector |
| Connection type |
M8 connector |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-25 to 60℃, storage: -40 to 70℃ |
| Protection structure |
IP67(IEC standard), IP67F(JEM standard) |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Hysteresis(distance) |
Max. 20% at rated sensing distance |
| Material |
Case: Acrylonitrile butadiene styrene, LED Cap: PA12, Lens cover: Polymethyl Methacrylate Acrylic |
| Accessories_Common |
Fixing bracket, M3 Bolts: 2, M3 Nuts: 2, Adjuster driver |
| Weight |
Approx. 60g(approx. 6g) |
