| Sensing type |
Diffuse reflective type |
| Sensing distance |
200mm |
| Sensing target |
Opaque, Translucent material |
| Light source |
Infrared LED(940nm) |
| Response time |
Max. 3ms |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 40mA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON(option: Dark ON) |
| Control output |
NPN open collector |
| Connection type |
Cable type(Ø4, 2m) |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-10 to 60℃, storage: -25 to 70℃ |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Hysteresis(distance) |
Max. 10% at sensing distance |
| Material |
Case: Acrylonitrile butadiene styrene, Sensing part: Acryl, Bracket: Steel plate cold commercial, Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Unit weight (packaged weight) |
≈ 88 g (≈ 156 g) |
