| Sensing type |
Diffuse reflective type |
| Sensing distance |
100mm |
| Sensing target |
Opaque, Translucent material |
| Light source |
Infrared LED(850nm) |
| Response time |
Max. 1ms |
| Power voltage |
10-30VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 30mA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by control wire) |
| Control output |
PNP open collector |
| Connection type |
Cable type(Ø4, 2m) |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-25 to 60℃, storage: -30 to 70℃ |
| Protection structure |
IP67(IEC standard) |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Hysteresis(distance) |
Max. 20% at rated sensing distance |
| Material |
Case: Polycarbonate
Lens, Lens cover: Polymethyl Methacrylate Acrylic |
| Weight |
Approx. 120g (approx. 60g) |
