| Sensing type |
Through-beam type |
| Sensing distance |
1m |
| Sensing target |
Opaque material of min. Ø2mm |
| Light source |
Red LED(650nm) |
| Response time |
Max. 1ms |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Emitter/Receiver: Max. 20mA |
| Operation mode |
Light ON |
| Control output |
PNP open collector |
| Connection type |
Cable type(Ø2.5, 2m) |
| Environment_Ambient illumination |
Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-25 to 55℃, storage: -40 to 70℃ |
| Protection structure |
IP67 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
Case: polybutylene terephthalate, sensing part: polymethyl methacrylate,
bracket: SUS304(steel use stainless 304), bolt: carbon steel, sleeve: SUS304(steel use stainless 304) |
| Accessories |
Fixing bracket, M2 bolt: 4 |
| Weight |
Approx. 70g (approx. 40g) |
