barrel version |
made of zinc-plated steel, special colours available, Ø 56 mm |
barrel length |
296 mm |
suitable for |
grease up to NLGI 3 |
filling capacity |
400 g (14.0 Oz.) grease cartridge / 500 ccm (17.5 Oz.) bulk grease |
connection thread |
M 10 x 1 or G 1/8 |
upon request |
1/8 NPT |
upon adjustment to volume |
operating pressure approx. 200bar/2,900PSI, output approx. 1.1 ccm/stroke |
upon adjustment to pressure |
operating pressure approx. 250bar/3,625PSI, output approx. 0.7 ccm/stroke |
testing pressure |
800 bar / 11,600 PSI |
gun dimension |
403 x 170 x 60 mm |
packed in |
polybag |
or |
printed UMETA cardboard box |
weight |
1,220 g + accessories and packaging |
dimensions (LxWxH) |
405 x 172 x 77 mm |
