YG-1 E·FORCE Long Neck Corner Radius End Mill, 2F (Part 5)

Description

YG-1 E·FORCE Long Neck Corner Radius End Mill, 2F

A corner-radius end mill has a rounded corner on its flat end, used for pocketing, profiling and finishing where an internal radius is wanted. A reduced-diameter neck gives extra reach into deep pockets and walls. It is used on CNC machining centers and milling machines in mold, die and general machining.

Key Features

  • The corner radius is stronger than a sharp corner and resists chipping.
  • Long neck reaches deep features but flexes more; use lighter cuts.
  • Check the work material and coating the series is made for.
  • Choose by diameter, flute count, length and shank to suit your holder.

Specifications

Model Specification Sold as
EFRICRE2-040R03-26 D4(R0.3)X6X6(26)X65 (GNX610400326) 1 pc
EFRICRE2-040R03-30 D4(R0.3)X6X6(30)X70 (GNX610400330) 1 pc
EFRICRE2-040R03-35 D4(R0.3)X6X6(35)X70 (GNX610400335) 1 pc
EFRICRE2-040R03-40 D4(R0.3)X6X6(40)X80 (GNX610400340) 1 pc
EFRICRE2-040R03-45 D4(R0.3)X6X6(45)X90 (GNX610400345) 1 pc
EFRICRE2-040R03-50 D4(R0.3)X6X6(50)X100 (GNX610400350) 1 pc
EFRICRE2-040R05-10 D4(R0.5)X6X6(10)X50 (GNX610400510) 1 pc
EFRICRE2-040R05-12 D4(R0.5)X6X6(12)X50 (GNX610400512) 1 pc
EFRICRE2-040R05-14 D4(R0.5)X6X6(14)X60 (GNX610400514) 1 pc
EFRICRE2-040R05-16 D4(R0.5)X6X6(16)X60 (GNX610400516) 1 pc
EFRICRE2-040R05-20 D4(R0.5)X6X6(20)X60 (GNX610400520) 1 pc
EFRICRE2-040R05-26 D4(R0.5)X6X6(26)X65 (GNX610400526) 1 pc
EFRICRE2-040R05-30 D4(R0.5)X6X6(30)X70 (GNX610400530) 1 pc
EFRICRE2-040R05-35 D4(R0.5)X6X6(35)X70 (GNX610400535) 1 pc
EFRICRE2-040R05-40 D4(R0.5)X6X6(40)X80 (GNX610400540) 1 pc
EFRICRE2-040R05-45 D4(R0.5)X6X6(45)X90 (GNX610400545) 1 pc
EFRICRE2-040R05-50 D4(R0.5)X6X6(50)X100 (GNX610400550) 1 pc
EFRICRE2-040R10-10 D4(R1)X6X6(10)X50 (GNX610401010) 1 pc
EFRICRE2-040R10-12 D4(R1)X6X6(12)X50 (GNX610401012) 1 pc
EFRICRE2-040R10-14 D4(R1)X6X6(14)X60 (GNX610401014) 1 pc
EFRICRE2-040R10-16 D4(R1)X6X6(16)X60 (GNX610401016) 1 pc
EFRICRE2-040R10-20 D4(R1)X6X6(20)X60 (GNX610401020) 1 pc
EFRICRE2-040R10-26 D4(R1)X6X6(26)X65 (GNX610401026) 1 pc
EFRICRE2-040R10-30 D4(R1)X6X6(30)X70 (GNX610401030) 1 pc
EFRICRE2-040R10-35 D4(R1)X6X6(35)X70 (GNX610401035) 1 pc
EFRICRE2-040R10-40 D4(R1)X6X6(40)X80 (GNX610401040) 1 pc
EFRICRE2-040R10-45 D4(R1)X6X6(45)X90 (GNX610401045) 1 pc
EFRICRE2-040R10-50 D4(R1)X6X6(50)X100 (GNX610401050) 1 pc
EFRICRE2-050R01-15 D5(R0.1)X6X8(15)X60 (GNX610500115) 1 pc
EFRICRE2-050R01-25 D5(R0.1)X6X8(25)X70 (GNX610500125) 1 pc
EFRICRE2-050R01-30 D5(R0.1)X6X8(30)X70 (GNX610500130) 1 pc
EFRICRE2-050R01-40 D5(R0.1)X6X8(40)X80 (GNX610500140) 1 pc
EFRICRE2-050R01-50 D5(R0.1)X6X8(50)X100 (GNX610500150) 1 pc
EFRICRE2-050R02-15 D5(R0.2)X6X8(15)X60 (GNX610500215) 1 pc
EFRICRE2-050R02-25 D5(R0.2)X6X8(25)X70 (GNX610500225) 1 pc
EFRICRE2-050R02-30 D5(R0.2)X6X8(30)X70 (GNX610500230) 1 pc
EFRICRE2-050R02-40 D5(R0.2)X6X8(40)X80 (GNX610500240) 1 pc
EFRICRE2-050R02-50 D5(R0.2)X6X8(50)X100 (GNX610500250) 1 pc
EFRICRE2-050R03-15 D5(R0.3)X6X8(15)X60 (GNX610500315) 1 pc
EFRICRE2-050R03-25 D5(R0.3)X6X8(25)X70 (GNX610500325) 1 pc
EFRICRE2-050R03-30 D5(R0.3)X6X8(30)X70 (GNX610500330) 1 pc
EFRICRE2-050R03-40 D5(R0.3)X6X8(40)X80 (GNX610500340) 1 pc
EFRICRE2-050R03-50 D5(R0.3)X6X8(50)X100 (GNX610500350) 1 pc
EFRICRE2-050R05-15 D5(R0.5)X6X8(15)X60 (GNX610500515) 1 pc
EFRICRE2-050R05-25 D5(R0.5)X6X8(25)X70 (GNX610500525) 1 pc
EFRICRE2-050R05-30 D5(R0.5)X6X8(30)X70 (GNX610500530) 1 pc
EFRICRE2-050R05-40 D5(R0.5)X6X8(40)X80 (GNX610500540) 1 pc
EFRICRE2-050R05-50 D5(R0.5)X6X8(50)X100 (GNX610500550) 1 pc
EFRICRE2-050R10-15 D5(R1)X6X8(15)X60 (GNX610501015) 1 pc
EFRICRE2-050R10-25 D5(R1)X6X8(25)X70 (GNX610501025) 1 pc
EFRICRE2-050R10-30 D5(R1)X6X8(30)X70 (GNX610501030) 1 pc
EFRICRE2-050R10-40 D5(R1)X6X8(40)X80 (GNX610501040) 1 pc
EFRICRE2-050R10-50 D5(R1)X6X8(50)X100 (GNX610501050) 1 pc
EFRICRE2-060R01-20 D6(R0.1)X6X8(20)X60 (GNX6106001) 1 pc
EFRICRE2-060R01-30 D6(R0.1)X6X12(30)X90 (GNX6106001090) 1 pc
EFRICRE2-060R02-20 D6(R0.2)X6X8(20)X60 (GNX6106002) 1 pc
EFRICRE2-060R02-30 D6(R0.2)X6X12(30)X90 (GNX6106002090) 1 pc
EFRICRE2-060R03-20 D6(R0.3)X6X8(20)X60 (GNX6106003) 1 pc
EFRICRE2-060R03-30 D6(R0.3)X6X12(30)X90 (GNX6106003090) 1 pc
EFRICRE2-060R05-20 D6(R0.5)X6X8(20)X60 (GNX6106005) 1 pc

40 more sizes are available in the option selector.

  • Brand: YG-1
  • Country of origin: Korea

About YG-1

YG-1 of South Korea is a major manufacturer of solid cutting tools: end mills, drills, taps and thread mills for metalworking.

Ordering & Shipping

  • Genuine product sourced through official Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
Product form

YG-1 E·FORCE Long Neck Corner Radius End Mill, 2FA corner-radius end mill has a rounded corner on its flat end,... Read more

SKU: kb-958-1452

$21.33 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
    • Secure payments Paypal
