| Sensing type |
Convergent reflective type |
| Sensing distance |
15mm |
| Sensing target |
Color(opaque,translucent Material) |
| Light source |
Full Color LED(red, green,blue) |
| Response time |
500㎲ |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 30mA |
| Sensitivity adjustment |
3-level |
| Operation mode |
color only,color + intensity |
| Control output |
PNP open collector |
| Timer function |
Timer Function |
| Connection type |
Connector type(M12) |
| Environment_Ambient illumination |
Incandescent lamp: Max. 3,000lx |
| Environment_Ambient temperature |
-10 to 55℃, storage: -25 to 75℃ |
| Protection structure |
IP67 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Hysteresis(distance) |
Max. 20% of sensing distance(may vary by sensing mode or sensitivity) |
| Spot size |
1.24×6.7mm(rectangular) |
| Sensing mode |
C(color only) mode, C+I(color + intensity) mode |
| Output mode |
Color match output, color mismatch output |
| External input |
External SET cable input |
| Material |
Case: polycarbonate, Sensing part: acrylic, Bracket: stainless steel 304 , Bolt: carbon steel |
| Accessories |
Bracket, Fixing bolts: 2 , Adjustment screwdriver: 1 |
| Weight |
Approx. 80g(approx. 14g) |
