| Sensing type |
BGS reflective type |
| Sensing distance |
10 to 100mm |
| Sensing target |
Opaque |
| Light source |
Red LED(660nm) |
| Response time |
Max. 1.5ms |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 30mA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by switch) |
| Control output |
NPN open collector |
| Connection type |
Cable type(Ø3.5, 2m) |
| Environment_Ambient illumination |
Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-25 to 55℃, storage: -40 to 70℃ |
| Protection structure |
IP65(IEC standard) |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Available setting distance |
20 to 100mm |
| Hysteresis(distance) |
Max. 10% of setting distance |
| Material |
Case: polycarbonate+acrylonitrile butadiene styrene,
LED indicator: polycarbonate, sensing part: polymethyl methacrylate |
| Accessories |
Adjustment screwdriver, bracket A, M3 bolts: 2, M3 nuts: 2 |
| Weight |
Approx. 105g(approx. 50g) |
