| Sensing type |
Through-beam type |
| Applicable pipe |
Using binding band: Ø6 to 13mm,
Using protection bracket: Ø12.7mm (1/2 inch) transparent pipe in 1mm thickness (FEP (fluoroplastic) or with equivalent transparency) |
| Standard sensing target |
Liquid in a pipe |
| Light source |
Infrared LED(950nm) |
| Response time |
Max. 2ms |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 30mA |
| Operation mode |
Light ON/Dark ON(set by button) |
| Control output |
PNP open collector |
| Connection type |
Cable type(Ø2.5, 1m) |
| Environment_Ambient illumination |
Sunlight/Incandescent lamp: Max. 3,000lx for each(received illumination) |
| Environment_Ambient temperature |
10 to 55℃ |
| Protection structure |
IP64 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
Case: Polycarbonate |
| Accessories |
Binding band: 2, Anti-slip tube: 2 |
| Weight |
Approx. 50g(approx. 13g) |
