| Sensing type |
Narrow beam reflective type |
| Sensing distance |
200mm |
| Sensing target |
Opaque, Translucent material |
| Light source |
Infrared LED(850nm) |
| Response time |
Max. 1ms |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 45mA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by control wire) |
| Control output |
NPN open collector |
| Connection type |
Cable type(Ø5, 2m) |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-10 to 60℃, storage: -25 to 75℃ |
| Protection structure |
IP66 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Hysteresis(distance) |
Max. 20% at rated sensing distance |
| Material |
Case - Brass, Ni-plate
Sensing part - Polycarbonate lens |
| Accessories |
M18 fixing nut: 2, washer:1, adjustment screwdriver |
| Weight |
Approx. 160g(approx. 120g) |
