| Sensing type |
Retroreflective type(built-in polarizing filter) |
| Sensing distance |
3m |
| Sensing target |
Opaque material of min. Ø75mm |
| Light source |
Red LED(660nm) |
| Response time |
Max. 1ms |
| Power voltage |
10-30VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 30mA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by control wire) |
| Control output |
PNP open collector |
| Connection type |
Connector type(M12) |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-25 to 60℃, storage: -30 to 70℃ |
| Protection structure |
IP67(IEC standard) |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
ㆍCase: brass, Ni-plate
ㆍLens, Lens cover: polymethyl methacrylate acrylic |
| Weight |
Approx. 140g(approx. 30g) |
