| Sensing type |
Through-beam type |
| Sensing distance |
30m |
| Sensing target |
Opaque material of min. Ø7mm |
| Light source |
Red LED(660nm) |
| Response time |
Max. 1ms |
| Power voltage |
10-30VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Emitter/Receiver: Max. 20mA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by control wire) |
| Control output |
NPN open collector |
| Connection type |
Cable type(Ø4, 2m) |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-25 to 60℃, storage: -30 to 70℃ |
| Protection structure |
IP67(IEC standard) |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
Case: Polycarbonate
Lens, Lens cover: Polymethyl Methacrylate Acrylic |
| Weight |
Approx. 160g(approx. 110g) |
