| Operation method |
Push Button Type |
| Button operation_Stop position |
5.0±0.4mm |
| Button operation_Output switching position |
4.0±0.5mm |
| Button operation_Operation limit position |
Max. 0mm |
| Light source |
Infrared LED(940nm) |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 35mA |
| Operation load |
Max. 3N(Max. 0.3kgf) |
| Operation mode |
Light ON(output OFF when button ispushed) |
| Control output |
NPN open collector |
| Connection type |
Cable type(Ø3, 1m) |
| Environment_Ambient illumination |
Fluorescent lamp: Max. 1,000lx(received illumination) |
| Environment_Ambient temperature |
-20 to 55℃, storage: -25 to 70℃ |
| Protection structure |
IP40 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| External input_Response |
Max. 1ms |
| Material |
Case: Polycarbonate + Glass fiber, Button: Polyoxymethylene, Sleeve: SUS304(steel use Stainless 304) |
| Weight |
Approx. 50g(approx. 30g) |
