| Sensing type |
Retroreflective type |
| Sensing distance |
10~200mm |
| Sensing target |
Opaque material of min. Ø27mm(min. sensing target: opaque material of Ø2mm) |
| Light source |
Red LED(650nm) |
| Response time |
Max. 1ms |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 20mA |
| Operation mode |
Light ON |
| Control output |
PNP open collector |
| Connection type |
Cable type(Ø2.5, 2m) |
| Environment_Ambient illumination |
Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-20 to 55℃, storage: -30 to 70℃ |
| Protection structure |
IP67 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
Case: Polybutylene terephthalate, Sensing part: Polymethyl methacrylate, Bracket: Stainless steel 304,
Bolt: Carbon steel wire for cold heading(SWCH10A) |
| Weight |
Approx. 45g(approx. 25g) |
