| Sensing type |
Through-beam type(direct beam) |
| Sensing distance |
0.1 to 7m |
| Light source |
Infrared LED(850nm modulated) |
| Optical axis pitch |
40mm |
| Number of optical axes |
8 |
| Sensing height/Total length |
280/320mm |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Control output |
PNP open collector |
| Operation mode |
Light ON |
| Environment_Ambient illumination |
Ambient light: Max. 100,000lx(receiver illumination) |
| Environment_Ambient temperature |
-10 to 55℃, storage: -20 to 60℃ |
| Connection type |
Cable connector type |
| Protection structure |
IP65(IEC standard) |
| Environment_Ambient humidity |
35 to 85 %RH, storage: 35 to 85 %RH (no freezing or condensation) |
| Min. sensing target |
Opaque material of min. Ø50mm |
| Response time |
Max. 10ms |
| Material |
• Case: Aluminum
• Front cover, sensing part: Acrylic |
| Cable specification |
Ø5mm, 4-wire, 300mm, M12 connector |
| Accessories |
Bracket A: 4, Bracket B: 4, Fixing bolt: 8 |
| Weight |
BW40-24: Approx. 2.1kg(approx. 1.4kg) |
