| Sensing type |
Through-beam type |
| Sensing distance |
15m |
| Sensing target |
Opaque material of min. Ø15mm |
| Light source |
Infrared LED(850nm) |
| Response time |
Max. 20ms |
| Power voltage |
24-240VAC~ ±10% 50/60Hz, 24-240VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Emitter/Receiver: Max. 3VA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by switch) |
| Control output |
Relay |
| Timer function |
Timer Function |
| Connection type |
Terminal block type |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-20 to 55℃, storage: -25 to 70℃ |
| Protection structure |
IP65 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
Case, Lens cover: Polycarbonate, Sensing part: Acrylic, Bracket: Steel plate cold commercial,
Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Accessories_Common |
Adjuster driver, Fixing bracket, Bolts, Nuts |
| Weight |
Approx. 226g |
