| Sensing type |
Retroreflective type(built-in polarizing filter) |
| Sensing distance |
3m |
| Sensing target |
Opaque material of min. Ø60mm |
| Light source |
Red LED(660nm) |
| Response time |
Max. 1ms |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 50mA |
| Sensitivity adjustment |
Sensitivity adjuster |
| Operation mode |
Light ON/Dark ON(set by switch) |
| Control output |
NPN, PNP open collector simultaneous output |
| Timer function |
Timer Function |
| Connection type |
Terminal block type |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-20 to 55℃, storage: -25 to 70℃ |
| Protection structure |
IP65 |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Material |
Case, Lens cover: Polycarbonate, Sensing part: Acrylic, Bracket: Steel plate cold commercial,
Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Accessories_Individual |
Reflector(MS-3) |
| Accessories_Common |
Adjuster driver, Fixing bracket, Bolts, Nuts |
| Weight |
Approx. 142g |
