OSG Long Spiral Flute Tap (Steam Oxide)

  • VendorOSG

Description

Confirm the thread standard, size and pitch, and whether the tap suits blind or through holes.

OSG Long Spiral Flute Tap (Steam Oxide)

A spiral flute tap for cutting internal threads in blind holes on machining centers and tapping machines. The helical flute lifts chips out of the hole to prevent packing.

Key Features

  • Spiral flutes draw chips back out of the hole, which suits blind holes.
  • Match thread size, pitch and tolerance class to your gauge.
  • Works in machine tapping; use cutting fluid suited to the workpiece.
  • Long shank gives reach into deep or recessed holes.

Specifications

Model Specification Sold as
LSFT030-100G LT-SFT M3X0.5-100 H (17310K) 1 pc
LSFT040-100G LT-SFT M4X0.7-100 H (17318K) 1 pc
LSFT050-100G LT-SFT M5X0.8-100 H (17326K) 1 pc
LSFT060-100G LT-SFT M6X1.0-100 H (17334K) 1 pc
LSFT100-100G LT-SFT M10X1.5-100 H (23350K) 1 pc
LSFT120-100G LT-SFT M12X1.75-100 H (23366K) 1 pc
LSFT030-150G LT-SFT M3X0.5-150 H (23312K) 1 pc
LSFT060-120G LT-SFT M6X1.0-120 H (23335K) 1 pc
LSFT060-150G LT-SFT M6X1.0-150 H (17336K) 1 pc
LSFT080-100G LT-SFT M8X1.25-100 H (17342K) 1 pc
LSFT080-120G LT-SFT M8X1.25-120 H (23343K) 1 pc
LSFT080-150G LT-SFT M8X1.25-150 H (17344K) 1 pc
LSFT100-120G LT-SFT M10X1.5-120 H (23351K) 1 pc
LSFT100-150G LT-SFT M10X1.5-150 H (17352K) 1 pc
LSFT120-120G LT-SFT M12X1.75-120 H (23367K) 1 pc
LSFT120-150G LT-SFT M12X1.75-150 H (17368K) 1 pc
LSFT120-200G LT-SFT M12X1.75-200 H (17370K) 1 pc
LSFT160-150G LT-SFT M16X2.0-150 H (79120K) 1 pc
LSFT160-200G LT-SFT M16X2.0-200 H (79122K) 1 pc
LSFT200-150G LT-SFT M20X2.5-150 H (79152K) 1 pc
LSFT200-200G LT-SFT M20X2.5-200 H (79154K) 1 pc
LSFT200-250G LT-SFT M20X2.5-250 H (23441K) 1 pc
LSFT220-1501 LT-SFT M22X1.5-150 H (79176K) 1 pc
LSFT240-150G LT-SFT M24X3.0-150 H (79184K) 1 pc
LSFT240-200G LT-SFT M24X3.0-200 H (79186K) 1 pc
LSFT020-80G LT-SFT M2.0X0.4-80L (27760K) 1 pc
LSFT023-80G LT-SFT M2.3X0.4-80L 1 pc
LSFT025-80G LT-SFT M2.5X0.45-80L (27768K) 1 pc
LSFT026-80G LT-SFT M2.6X0.45-80L 1 pc
LSFT020-100G LT-SFT M2X0.4-100 H (27761K) 1 pc
LSFT023-100G LT-SFT M2.3X0.4-100 H 1 pc
LSFT025-100G LT-SFT M2.5X0.45-100 H 1 pc
LSFT026-100G LT-SFT M2.6X0.45-100 H 1 pc
LSFT120-100G1 LT-SFT M12X1.25-100 H 1 pc
LSFT120-100G2 LT-SFT M12X1.5-100 H(23374K) 1 pc
LSFT140-100G1 LT-SFT M14X1.5-100 H 1 pc
LSFT140-100G LT-SFT M14X2.0-100 H 1 pc
LSFT030-120G LT-SFT M3X0.5-120 H(23311K) 1 pc
LSFT050-120G LT-SFT M5X0.8-120 H(23327K) 1 pc
LSFT100-120G1 LT-SFT M10X1.25-120 H (23359K) 1 pc
LSFT120-120G1 LT-SFT M12X1.5-120 H 1 pc
LSFT140-120G LT-SFT M14X2.0-120 H 1 pc
LSFT160-120G1 LT-SFT M16X1.5-120 H 1 pc
LSFT160-120G LT-SFT M16X2.0-120 H 1 pc
LSFT040-150G LT-SFT M4X0.7-150 H (23320K) 1 pc
LSFT050-150G LT-SFT M5X0.8-150 H (23328K) 1 pc
LSFT100-150G1 LT-SFT M10X1.25-150 H 1 pc
LSFT140-150G LT-SFT M14X2.0-150 H(79104K) 1 pc
LSFT180-150G1 LT-SFT M18X1.5-150L (79144K) 1 pc
LSFT180-150G LT-SFT M18X2.5-150 H 1 pc
LSFT200-150G1 LT-SFT M20X1.5-150 H 1 pc
LSFT220-150G LT-SFT M22X2.5-150 H 1 pc
LSFT240-150G1 LT-SFT M24X1.5-150 H (79192K) 1 pc
LSFT060-200G LT-SFT M6X1.0-200L H 1 pc
LSFT080-200G LT-SFT M8X1.25-200L H 1 pc
LSFT100-200G1 LT-SFT M10X1.25-200L H 1 pc
LSFT100-200G LT-SFT M10X1.5-200L H 1 pc
LSFT140-200G1 LT-SFT M14X1.5-200L H 1 pc
LSFT140-200G LT-SFT M14X2.0-200L H 1 pc
LSFT160-200G1 LT-SFT M16X1.5-200L H 1 pc

17 more sizes are available in the option selector.

  • Brand: OSG
  • Country of origin: Korea

About OSG

OSG of Japan is a major manufacturer of taps, drills, end mills and thread-forming tools for metalworking.

Ordering & Shipping

  • Genuine product sourced through official Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
