| Switching voltage |
≤ 24VDC
|
| Contact type |
Normally Open |
| Operation distance_OFF→ON |
± 10 mm |
| Operation distance_ON→OFF |
± 20 mm |
| Standard sensing target |
Steel plate - a galvanized steel sheet 1.6t |
| Operating frequency |
≤ 500 Hz |
| Material |
Cover/Case: PC (915R) |
| Protection structure |
IP67(IEC standard) |
| Environment_Ambient temperature |
-10 to 65 ℃, storage: -10 to 70 ℃ (no freezing or condensation) |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Insulation resistance |
≥ 1,000 MΩ (500 VDC megger) |
| Dielectric strength |
500VAC~ 50/60Hz for 1 min. |
| Vibration |
1.5mm amplitude at frequency of 10 to 55Hzin each X, Y, Z direction for 2 hours |
| Shock |
100m/s² (approx. 10G) in each X, Y, Z direction for 3 times |
| Applied REED SWITCH |
Model : ORD324-10-15 (STANDEX MEDER) |
| Weight |
≈ 132.5 g (≈ 172.3 g) |
