Description
MITSUBISHI ELECTRIC LJ72MS15 — SSCNET III/H Head Unit, genuine MITSUBISHI ELECTRIC product.
Overview
The LJ72MS15 is an SSCNET III/H head unit from MITSUBISHI ELECTRIC that connects MELSEC-L Series I/O modules to an SSCNET III/H motion network. It allows remote I/O to share the servo network. It is used in motion systems needing distributed I/O. Distributed I/O on the same network reduces cabling.
Key Features
- Connects L Series I/O to SSCNET III/H
- Shares servo network with I/O
- Reduces wiring
- Supports motion systems
Specifications
| Part No. |
Mass (kg) |
Connection Method |
Current Consumption (A) |
Connection Cable |
Synchronization Method |
Communication Speed |
Communication Port |
No. of Units |
| LJ72MS15 |
0.2 |
Daisy chain connection (regenerative relay via servo amplifier) |
0.55 (DC5V internal) |
SSCNETIII cable (optical fiber cable) |
Synchronization of control and communication cycles with controller data transmission |
150Mbps |
SSCNETIII/H×2 |
Max mounting: 10 |
How to Order
Confirm the motion controller and I/O modules. Please confirm the full part number and options against the MITSUBISHI ELECTRIC catalog; contact us if you need help identifying the right model.
About MITSUBISHI ELECTRIC
Mitsubishi Electric is a Japanese manufacturer of factory automation and low-voltage power distribution equipment, including MELSEC PLCs, servo systems, inverters, magnetic contactors and starters, circuit breakers and measuring instruments.
Ordering & Shipping
- Genuine MITSUBISHI ELECTRIC product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
