Description
TSUBAKI TSU — Standard Roller Chain (Single Strand), genuine TSUBAKI product.
Overview
Tsubaki standard single-strand roller chain transmits power between sprockets in drives, conveyors and machinery. Each link consists of pin and roller links joined by press-fitted pins, bushings and rollers that engage the sprocket teeth with low friction. It is used across packaging, agricultural, food processing and general industrial power transmission equipment.
Key Features
- Single-strand construction for light to moderate loads
- Pins, bushings and rollers made of heat-treated steel
- Interchangeable with standard ANSI-pitch sprockets
- Supplied in lengths with connecting links available
Specifications
| Part No. |
No. of Strands |
Chain No. |
Overall Length |
Pitch (mm) |
Roller Link Inner Width (mm) |
Roller Outer Diameter (mm) |
| TSU 025-1RP |
1 |
25 |
10FT(3M) |
6.35 |
3.18 |
3.3 |
| TSU 035-1RP |
1 |
35 |
10FT(3M) |
9.525 |
4.78 |
5.08 |
| TSU 040-1RP |
1 |
40 |
10FT(3M) |
12.7 |
7.95 |
7.92 |
| TSU 040-SS-1 |
1 |
40 |
10FT(3M) |
12.7 |
7.95 |
7.92 |
| TSU 050-1RP |
1 |
50 |
10FT(3M) |
15.875 |
9.53 |
10.16 |
| TSU 050-SS-1 |
1 |
50 |
10FT(3M) |
15.875 |
9.53 |
10.16 |
| TSU 060-1RP |
1 |
60 |
10FT(3M) |
19.05 |
12.7 |
11.91 |
| TSU 060-SS-1 |
1 |
60 |
10FT(3M) |
19.05 |
12.7 |
11.91 |
| TSU 080-1RP |
1 |
80 |
10FT(3M) |
25.4 |
15.88 |
15.88 |
| TSU 080-SS-1 |
1 |
80 |
10FT(3M) |
25.4 |
15.88 |
15.88 |
| TSU 100-1RP |
1 |
100 |
10FT(3M) |
31.75 |
19.05 |
19.05 |
| TSU 120-1RP |
1 |
120 |
10FT(3M) |
38.1 |
25.4 |
22.23 |
| TSU 140-1CP |
1 |
140 |
10FT(3M) |
42.2 |
25.4 |
25.4 |
| TSU 160-1CP |
1 |
160 |
10FT(3M) |
50.8 |
31.75 |
28.58 |
| TSU 200-1CP |
1 |
200 |
10FT(3M) |
63.5 |
38.1 |
39.68 |
| TSU 240-1RP |
1 |
240 |
10FT(3M) |
76.2 |
47.63 |
47.63 |
How to Order
Confirm chain number (pitch), number of strands, required length in links and connecting link type. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
