Description
TSUBAKI RS — RS Roller Chain Quadruple Strand (Per Link), genuine TSUBAKI product.
Overview
Quadruple strand RS roller chain from TSUBAKI uses four parallel strands sharing common pins for very high transmission capacity. It is sold per link so users can build exact lengths. It is used in heavy-duty drives where high torque must be handled in a compact sprocket diameter.
Key Features
- Four strands for high transmission capacity
- Sold per link for exact lengths
- ANSI RS pitch standard
- Pre-lubricated components
Specifications
| Part No. |
Material (Body) |
Type |
Type |
Pitch (mm) |
Link Width (mm) |
No. of Strands |
Max. Allowable Tension (kN) |
| RS100-4-RP-L |
Steel |
Per link |
Roller chain |
31.75 |
19.05 |
4 |
74.4 |
| RS120-4-RP-L |
Steel |
Per link |
Roller chain |
38.1 |
25.4 |
4 |
100 |
| RS140-4-RP-L |
Steel |
Per link |
Roller chain |
44.45 |
25.4 |
4 |
133 |
| RS160-4-RP-L |
Steel |
Per link |
Roller chain |
50.8 |
31.75 |
4 |
175 |
| RS180-4-RP-L |
Steel |
Per link |
Roller chain |
57.15 |
35.72 |
4 |
201 |
| RS200-4-RP-L |
Steel |
Per link |
Roller chain |
63.5 |
38.1 |
4 |
236 |
| RS240-4-RP-L |
Steel |
Per link |
Roller chain |
76.2 |
47.63 |
4 |
327 |
| RS40-4-RP-L |
Steel |
Per link |
Roller chain |
12.7 |
7.95 |
4 |
12 |
| RS50-4-RP-L |
Steel |
Per link |
Roller chain |
15.875 |
9.53 |
4 |
21.1 |
| RS60-4-RP-L |
Steel |
Per link |
Roller chain |
19.05 |
12.7 |
4 |
29.1 |
| RS80-4-RP-L |
Steel |
Per link |
Roller chain |
25.4 |
15.88 |
4 |
48.5 |
How to Order
Confirm chain number, strand count and number of links. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
