TSUBAKI PX Pulley P8M Type (Aluminum)

Description

TSUBAKI PT — PX Pulley P8M Type (Aluminum), genuine TSUBAKI product.

Overview

This Tsubaki PX pulley for P8M belts is an aluminum timing pulley with an 8mm tooth pitch, used in higher-torque synchronous drives where weight must stay low. Flanges keep the belt tracking on the pulley face. It is applied to conveyors, packaging machines, machine tool axes and general industrial drives running P8M PX belts.

Key Features

  • 8mm pitch profile for PX P8M belts
  • Aluminum body reduces weight and inertia
  • Flanged versions keep the belt aligned
  • Pilot bore can be finished to shaft size

Specifications

Part No. Shape No. of Teeth Type Applicable Belt Width (mm) Pitch Diameter (Dp) (Ømm) Dim. BL (mm) Max. Bore Diameter d (Ømm) Dim. do (mm) Min. Bore Diameter D (Ømm) Dim. Bw (mm) Hub Diameter Dh (Ømm)
PT20P8M15AF-A AF 20 PX pulley 15 50.93 - 22 49.56 12 22 -
PT20P8M15BF-A BF 20 PX pulley 15 50.93 39 22 49.56 12 22 36
PT20P8M25AF-A AF 20 PX pulley 25 50.93 - 22 49.56 12 33 -
PT20P8M40AF-A AF 20 PX pulley 40 50.93 - 22 49.56 12 49 -
PT22P8M15AF-A AF 22 PX pulley 15 56.02 - 25 54.65 12 22 -
PT22P8M15BF-A BF 22 PX pulley 15 56.02 39 25 54.65 12 22 41
PT22P8M25AF-A AF 22 PX pulley 25 56.02 - 25 54.65 12 33 -
PT22P8M40AF-A AF 22 PX pulley 40 56.02 - 25 54.65 12 49 -
PT24P8M15AF-A AF 24 PX pulley 15 61.12 - 28 59.74 12 22 -
PT24P8M15BF-A BF 24 PX pulley 15 61.12 39 28 59.74 12 22 46
PT24P8M25AF-A AF 24 PX pulley 25 61.12 - 28 59.74 12 33 -
PT24P8M40AF-A AF 24 PX pulley 40 61.12 - 28 59.74 12 49 -
PT26P8M15AF-A AF 26 PX pulley 15 66.21 - 30 64.84 16 22 -
PT26P8M15BF-A BF 26 PX pulley 15 66.21 39 30 64.84 16 22 51
PT26P8M25AF-A AF 26 PX pulley 25 66.21 - 30 64.84 16 33 -
PT26P8M40AF-A AF 26 PX pulley 40 66.21 - 30 64.84 16 49 -
PT28P8M15AF-A AF 28 PX pulley 15 71.3 - 34 69.93 16 22 -
PT28P8M15BF-A BF 28 PX pulley 15 71.3 39 34 69.93 16 22 55
PT28P8M25AF-A AF 28 PX pulley 25 71.3 - 34 69.93 16 33 -
PT28P8M40AF-A AF 28 PX pulley 40 71.3 - 34 69.93 16 49 -
PT30P8M15AF-A AF 30 PX pulley 15 76.39 - 36 75.02 16 22 -
PT30P8M15BF-A BF 30 PX pulley 15 76.39 39 36 75.02 16 22 60
PT30P8M25AF-A AF 30 PX pulley 25 76.39 - 36 75.02 16 33 -
PT30P8M40AF-A AF 30 PX pulley 40 76.39 - 36 75.02 16 49 -
PT32P8M15AF-A AF 32 PX pulley 15 81.49 - 38 80.12 16 22 -
PT32P8M15BF-A BF 32 PX pulley 15 81.49 39 38 80.12 16 22 65
PT32P8M25AF-A AF 32 PX pulley 25 81.49 - 38 80.12 16 33 -
PT32P8M40AF-A AF 32 PX pulley 40 81.49 - 38 80.12 16 49 -
PT34P8M15AF-A AF 34 PX pulley 15 86.58 - 42 85.21 16 22 -
PT34P8M15BF-A BF 34 PX pulley 15 86.58 39 42 85.21 16 22 70
PT34P8M25AF-A AF 34 PX pulley 25 86.58 - 42 85.21 16 33 -
PT34P8M40AF-A AF 34 PX pulley 40 86.58 - 42 85.21 16 49 -
PT36P8M15AF-A AF 36 PX pulley 15 91.67 - 45 90.3 16 22 -
PT36P8M15BF-A BF 36 PX pulley 15 91.67 39 45 90.3 16 22 75
PT36P8M25AF-A AF 36 PX pulley 25 91.67 - 45 90.3 16 33 -
PT36P8M40AF-A AF 36 PX pulley 40 91.67 - 45 90.3 16 49 -
PT40P8M15AF-A AF 40 PX pulley 15 101.86 - 50 100.49 20 22 -
PT40P8M15BF-A BF 40 PX pulley 15 101.86 39 50 100.49 20 22 85
PT40P8M25AF-A AF 40 PX pulley 25 101.86 - 50 100.49 20 33 -
PT40P8M40AF-A AF 40 PX pulley 40 101.86 - 50 100.49 20 49 -
PT44P8M15AF-A AF 44 PX pulley 15 112.05 - 56 110.67 20 22 -
PT44P8M15BF-A BF 44 PX pulley 15 112.05 44 56 110.67 20 22 90
PT44P8M25AF-A AF 44 PX pulley 25 112.05 - 56 110.67 20 33 -
PT44P8M40AF-A AF 44 PX pulley 40 112.05 - 56 110.67 20 49 -
PT48P8M15AF-A AF 48 PX pulley 15 122.23 - 62 120.86 20 22 -
PT48P8M15BF-A BF 48 PX pulley 15 122.23 44 62 120.86 20 22 100
PT48P8M25AF-A AF 48 PX pulley 25 122.23 - 62 120.86 20 33 -
PT48P8M40AF-A AF 48 PX pulley 40 122.23 - 62 120.86 20 49 -
PT50P8M15AF-A AF 50 PX pulley 15 127.32 - 62 125.95 20 22 -
PT50P8M15BF-A BF 50 PX pulley 15 127.32 44 62 125.95 20 22 100
PT50P8M25AF-A AF 50 PX pulley 25 127.32 - 62 125.95 20 33 -
PT50P8M40AF-A AF 50 PX pulley 40 127.32 - 62 125.95 20 49 -
PT60P8M15AF-A AF 60 PX pulley 15 152.79 - 62 151.42 20 22 -
PT60P8M15BF-A BF 60 PX pulley 15 152.79 44 62 151.42 20 22 100
PT60P8M25AF-A AF 60 PX pulley 25 152.79 - 62 151.42 20 33 -
PT60P8M40AF-A AF 60 PX pulley 40 152.79 - 62 151.42 20 49 -

How to Order

Confirm the number of teeth, belt width code, flange requirement and the final bore size. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.

Product image is representative of the TSUBAKI series; appearance varies by size and model.

About TSUBAKI

Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.

Ordering & Shipping

  • Genuine TSUBAKI product sourced through Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Lead time varies by model; please inquire for exact delivery
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
Product form

TSUBAKI PT — PX Pulley P8M Type (Aluminum), genuine TSUBAKI product.OverviewThis Tsubaki PX pulley for P8M belts is an aluminum... Read more

SKU: PT20P8M15AF-A

$46.38 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
    • Secure payments Paypal
