TSUBAKI Cable Carrier, TKUA (Part 3)

VendorTSUBAKI

Description

TSUBAKI TKUA — Cable Carrier, genuine TSUBAKI product.

Overview

This Tsubaki cable carrier series uses side links joined by removable stays, with aluminum or steel stay options and separators to arrange cables and hoses. The construction supports larger cable bundles and longer unsupported spans than small plastic carriers. It is applied on large machine tools, gantry robots, cranes and other equipment with long travel.

Key Features

Removable stays allow cables to be laid in from above
Aluminum or steel stay options by model
Separators keep cables and hoses organized
Suited to larger cable bundles and longer spans

Specifications

Part No.	Type	Type	Pitch (mm)	Model Type	Outer Width (mm)	Inner Width (mm)
TKUA66H44-STBS	Common	Vertical separator	66.5	TKUA66H44	Common	Common
TKUA66H44W100-CL-P		Cable clamp	66.5	TKUA66H44	122	100
TKUA66H44W100-CL-U		Cable clamp	66.5	TKUA66H44	122	100
TKUA66H44W100-CRA		Clamp rail	66.5	TKUA66H44	122	100
TKUA66H44W100-FI	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-FICL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-FO	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-FOCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-FU	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-FUCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-MI	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-MICL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-MO	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-MOCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-MU	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W100-MUCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	122	100
TKUA66H44W125-CL-P		Cable clamp	66.5	TKUA66H44	147	125
TKUA66H44W125-CL-U		Cable clamp	66.5	TKUA66H44	147	125
TKUA66H44W125-CRA		Clamp rail	66.5	TKUA66H44	147	125
TKUA66H44W125-FI	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-FICL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-FO	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-FOCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-FU	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-FUCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-MI	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-MICL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-MO	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-MOCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-MU	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W125-MUCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	147	125
TKUA66H44W150-CL-P		Cable clamp	66.5	TKUA66H44	172	150
TKUA66H44W150-CL-U		Cable clamp	66.5	TKUA66H44	172	150
TKUA66H44W150-CRA		Clamp rail	66.5	TKUA66H44	172	150
TKUA66H44W150-FI	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-FICL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-FO	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-FOCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-FU	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-FUCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-MI	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-MICL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-MO	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-MOCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-MU	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W150-MUCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	172	150
TKUA66H44W175-CL-P		Cable clamp	66.5	TKUA66H44	197	175
TKUA66H44W175-CL-U		Cable clamp	66.5	TKUA66H44	197	175
TKUA66H44W175-CRA		Clamp rail	66.5	TKUA66H44	197	175
TKUA66H44W175-FI	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-FICL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-FO	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-FOCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-FU	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-FUCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-MI	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-MICL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-MO	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-MOCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-MU	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W175-MUCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	197	175
TKUA66H44W225-CL-P		Cable clamp	66.5	TKUA66H44	247	225
TKUA66H44W225-CRA		Clamp rail	66.5	TKUA66H44	247	225
TKUA66H44W225-FI	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-FICL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-FO	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-FOCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-FU	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-MI	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-MICL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-MO	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-MOCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W225-MU	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	247	225
TKUA66H44W250-CL-P		Cable clamp	66.5	TKUA66H44	272	250
TKUA66H44W250-CRA		Clamp rail	66.5	TKUA66H44	272	250
TKUA66H44W250-FI	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-FICL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-FO	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-FOCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-FU	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-MI	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-MICL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-MO	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-MOCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W250-MU	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	272	250
TKUA66H44W50-CL-P		Cable clamp	66.5	TKUA66H44	72	50
TKUA66H44W50-CL-U		Cable clamp	66.5	TKUA66H44	72	50
TKUA66H44W50-FI	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-FICL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-FO	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-FOCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-FU	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-FUCL	Common	Fixed-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-MI	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-MICL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-MO	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-MOCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-MU	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W50-MUCL	Common	Moving-end bracket / mounting fitting	66.5	TKUA66H44	72	50
TKUA66H44W75-CL-P		Cable clamp	66.5	TKUA66H44	97	75

How to Order

Specify inner width and height, pitch, stay type, bending radius and total length. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.

Product image is representative of the TSUBAKI series; appearance varies by size and model.
