TSUBAKI Cable Carrier Plastic Series TKUA Type (Part 1)

Description

TSUBAKI TKUA — Cable Carrier Plastic Series TKUA Type, genuine TSUBAKI product.

Overview

The TKUA Type is a TSUBAKI plastic cable carrier for guiding cables and hoses on moving machine axes. Its links form a flexible protective track that maintains a set bending radius. It is used on machine tools, automation, gantries and robots to prevent cable damage and tangling.

Key Features

  • Resin links form a protective cable track
  • Defined bending radius protects cables
  • Openable links for easy cable installation
  • Lightweight and quiet running

Specifications

Part No. Height (mm) Type Pitch (mm) Cable O.D. (Ømm) Inner Width (mm) Bending Radius R (mm)
TKUA45H26-30W103R125 26 Outer-side opening 46.5 23 103 125
TKUA45H26-30W103R150 26 Outer-side opening 46.5 23 103 150
TKUA45H26-30W103R180 26 Outer-side opening 46.5 23 103 180
TKUA45H26-30W103R200 26 Outer-side opening 46.5 23 103 200
TKUA45H26-30W103R52 26 Outer-side opening 46.5 23 103 52
TKUA45H26-30W103R65 26 Outer-side opening 46.5 23 103 65
TKUA45H26-30W103R95 26 Outer-side opening 46.5 23 103 95
TKUA45H26-30W25R125 26 Outer-side opening 46.5 23 25 125
TKUA45H26-30W25R150 26 Outer-side opening 46.5 23 25 150
TKUA45H26-30W25R180 26 Outer-side opening 46.5 23 25 80
TKUA45H26-30W25R200 26 Outer-side opening 46.5 23 25 200
TKUA45H26-30W25R52 26 Outer-side opening 46.5 23 25 52
TKUA45H26-30W25R65 26 Outer-side opening 46.5 23 25 65
TKUA45H26-30W25R95 26 Outer-side opening 46.5 23 25 95
TKUA45H26-30W38R125 26 Outer-side opening 46.5 23 38 125
TKUA45H26-30W38R150 26 Outer-side opening 46.5 23 38 150
TKUA45H26-30W38R180 26 Outer-side opening 46.5 23 38 180
TKUA45H26-30W38R200 26 Outer-side opening 46.5 23 38 200
TKUA45H26-30W38R52 26 Outer-side opening 46.5 23 38 52
TKUA45H26-30W38R65 26 Outer-side opening 46.5 23 38 65
TKUA45H26-30W38R95 26 Outer-side opening 46.5 23 38 95
TKUA45H26-30W58R125 26 Outer-side opening 46.5 23 58 125
TKUA45H26-30W58R150 26 Outer-side opening 46.5 23 58 150
TKUA45H26-30W58R180 26 Outer-side opening 46.5 23 58 180
TKUA45H26-30W58R200 26 Outer-side opening 46.5 23 58 200
TKUA45H26-30W58R52 26 Outer-side opening 46.5 23 58 52
TKUA45H26-30W58R65 26 Outer-side opening 46.5 23 58 65
TKUA45H26-30W58R95 26 Outer-side opening 46.5 23 58 95
TKUA45H26-30W78R125 26 Outer-side opening 46.5 23 78 125
TKUA45H26-30W78R150 26 Outer-side opening 46.5 23 78 150
TKUA45H26-30W78R180 26 Outer-side opening 46.5 23 78 180
TKUA45H26-30W78R200 26 Outer-side opening 46.5 23 78 200
TKUA45H26-30W78R52 26 Outer-side opening 46.5 23 78 52
TKUA45H26-30W78R65 26 Outer-side opening 46.5 23 78 65
TKUA45H26-30W78R95 26 Outer-side opening 46.5 23 78 95
TKUA45H26-40W103R125 26 Inner-side opening 46.5 23 103 125
TKUA45H26-40W103R150 26 Inner-side opening 46.5 23 103 150
TKUA45H26-40W103R180 26 Inner-side opening 46.5 23 103 180
TKUA45H26-40W103R200 26 Inner-side opening 46.5 23 103 200
TKUA45H26-40W103R52 26 Inner-side opening 46.5 23 103 52
TKUA45H26-40W103R65 26 Inner-side opening 46.5 23 103 65
TKUA45H26-40W103R95 26 Inner-side opening 46.5 23 103 95
TKUA45H26-40W25R125 26 Inner-side opening 46.5 23 25 125
TKUA45H26-40W25R150 26 Inner-side opening 46.5 23 25 150
TKUA45H26-40W25R180 26 Inner-side opening 46.5 23 25 180
TKUA45H26-40W25R200 26 Inner-side opening 46.5 23 25 200
TKUA45H26-40W25R52 26 Inner-side opening 46.5 23 25 52
TKUA45H26-40W25R65 26 Inner-side opening 46.5 23 25 65
TKUA45H26-40W25R95 26 Inner-side opening 46.5 23 25 95
TKUA45H26-40W38R125 26 Inner-side opening 46.5 23 38 125
TKUA45H26-40W38R150 26 Inner-side opening 46.5 23 38 150
TKUA45H26-40W38R180 26 Inner-side opening 46.5 23 38 180
TKUA45H26-40W38R200 26 Inner-side opening 46.5 23 38 200
TKUA45H26-40W38R52 26 Inner-side opening 46.5 23 38 52
TKUA45H26-40W38R65 26 Inner-side opening 46.5 23 38 65
TKUA45H26-40W38R95 26 Inner-side opening 46.5 23 38 95
TKUA45H26-40W58R125 26 Inner-side opening 46.5 23 58 125
TKUA45H26-40W58R150 26 Inner-side opening 46.5 23 58 150
TKUA45H26-40W58R180 26 Inner-side opening 46.5 23 58 180
TKUA45H26-40W58R200 26 Inner-side opening 46.5 23 58 200
TKUA45H26-40W58R52 26 Inner-side opening 46.5 23 58 52
TKUA45H26-40W58R65 26 Inner-side opening 46.5 23 58 65
TKUA45H26-40W58R95 26 Inner-side opening 46.5 23 58 95
TKUA45H26-40W78R125 26 Inner-side opening 46.5 23 78 125
TKUA45H26-40W78R150 26 Inner-side opening 46.5 23 78 150
TKUA45H26-40W78R180 26 Inner-side opening 46.5 23 78 180
TKUA45H26-40W78R200 26 Inner-side opening 46.5 23 78 200
TKUA45H26-40W78R52 26 Inner-side opening 46.5 23 78 52
TKUA45H26-40W78R65 26 Inner-side opening 46.5 23 78 65
TKUA45H26-40W78R95 26 Inner-side opening 46.5 23 78 95
TKUA55H38-30W100R100 38 Outer-side opening 55.5 34 100 100
TKUA55H38-30W100R125 38 Outer-side opening 55.5 34 100 125
TKUA55H38-30W100R160 38 Outer-side opening 55.5 34 100 160
TKUA55H38-30W100R200 38 Outer-side opening 55.5 34 100 200
TKUA55H38-30W100R63 38 Outer-side opening 55.5 34 100 63
TKUA55H38-30W100R80 38 Outer-side opening 55.5 34 100 80
TKUA55H38-30W125R100 38 Outer-side opening 55.5 34 125 100
TKUA55H38-30W125R125 38 Outer-side opening 55.5 34 125 125
TKUA55H38-30W125R160 38 Outer-side opening 55.5 34 125 160
TKUA55H38-30W125R200 38 Outer-side opening 55.5 34 125 200
TKUA55H38-30W125R63 38 Outer-side opening 55.5 34 125 63
TKUA55H38-30W125R80 38 Outer-side opening 55.5 34 125 80
TKUA55H38-30W150R100 38 Outer-side opening 55.5 34 150 100
TKUA55H38-30W150R125 38 Outer-side opening 55.5 34 150 125
TKUA55H38-30W150R160 38 Outer-side opening 55.5 34 150 160
TKUA55H38-30W150R200 38 Outer-side opening 55.5 34 150 200
TKUA55H38-30W150R63 38 Outer-side opening 55.5 34 150 63
TKUA55H38-30W150R80 38 Outer-side opening 55.5 34 150 80
TKUA55H38-30W50R100 38 Outer-side opening 55.5 34 50 100
TKUA55H38-30W50R125 38 Outer-side opening 55.5 34 50 125
TKUA55H38-30W50R160 38 Outer-side opening 55.5 34 50 160
TKUA55H38-30W50R200 38 Outer-side opening 55.5 34 50 200
TKUA55H38-30W50R63 38 Outer-side opening 55.5 34 50 63
TKUA55H38-30W50R80 38 Outer-side opening 55.5 34 50 80
TKUA55H38-30W75R100 38 Outer-side opening 55.5 34 75 100
TKUA55H38-30W75R125 38 Outer-side opening 55.5 34 75 25
TKUA55H38-30W75R160 38 Outer-side opening 55.5 34 75 160
TKUA55H38-30W75R200 38 Outer-side opening 55.5 34 75 200
TKUA55H38-30W75R63 38 Outer-side opening 55.5 34 75 63
TKUA55H38-30W75R80 38 Outer-side opening 55.5 34 75 80

How to Order

Confirm inner height and width, bending radius and length. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.

Product image is representative of the TSUBAKI series; appearance varies by size and model.

About TSUBAKI

Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.

Ordering & Shipping

  • Genuine TSUBAKI product sourced through Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Lead time varies by model; please inquire for exact delivery
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
