Description
TSUBAKI R — Side Roller Chain Joint, genuine TSUBAKI product.
Overview
This Tsubaki connecting link is designed for roller chain fitted with side rollers, which project from the chain sides to carry pallets or workpieces resting on them. The joint keeps side roller spacing continuous so conveyed items run smoothly over the connection. Such chains are used in accumulation conveyors and assembly lines.
Key Features
- Connecting link for side roller chain
- Maintains side roller pitch through the joint
- Versions for plated and Lambda chains
- Suitable for pallet and accumulation conveyors
Specifications
| Part No. |
Type |
Chain No. |
| RS40-SS-3LSRP-H-JL |
Connecting link |
RS40 |
| RS40-SS-3LSRP-T-JL |
Connecting link |
RS40 |
| RS50-3LSR-H-JL |
Connecting link |
RS50 |
| RS50-3LSR-T-JL |
Connecting link |
RS50 |
| RS50-3LSRP-H-JL |
Connecting link |
RS50 |
| RS50-3LSRP-T-JL |
Connecting link |
RS50 |
| RS50-3LSRPE-H-JL |
Connecting link |
RS50 |
| RS50-3LSRPE-T-JL |
Connecting link |
RS50 |
| RS50-AS-3LSRP-H-JL |
Connecting link |
RS50 |
| RS50-AS-3LSRP-T-JL |
Connecting link |
RS50 |
| RS50-LMC-3LSR-H-JL |
Connecting link |
RS50 |
| RS50-LMC-3LSR-T-JL |
Connecting link |
RS50 |
| RS50-LMC-3LSRP-H-JL |
Connecting link |
RS50 |
| RS50-LMC-3LSRP-T-JL |
Connecting link |
RS50 |
| RS50-NP-3LSR-H-JL |
Connecting link |
RS50 |
| RS50-NP-3LSR-T-JL |
Connecting link |
RS50 |
| RS50-NP-3LSRP-H-JL |
Connecting link |
RS50 |
| RS50-NP-3LSRP-T-JL |
Connecting link |
RS50 |
| RS50-PC-3LSRP-H-JL |
Connecting link |
RS50 |
| RS50-PC-3LSRP-T-JL |
Connecting link |
RS50 |
| RS50-SS-3LSR-H-JL |
Connecting link |
RS50 |
| RS50-SS-3LSR-T-JL |
Connecting link |
RS50 |
| RS50-SS-3LSRP-H-JL |
Connecting link |
RS50 |
| RS50-SS-3LSRP-T-JL |
Connecting link |
RS50 |
| RS60-3LSR-H-JL |
Connecting link |
RS60 |
| RS60-3LSR-T-JL |
Connecting link |
RS60 |
| RS60-3LSRP-H-JL |
Connecting link |
RS60 |
| RS60-3LSRP-T-JL |
Connecting link |
RS60 |
| RS60-3LSRPE-H-JL |
Connecting link |
RS60 |
| RS60-3LSRPE-T-JL |
Connecting link |
RS60 |
| RS60-AS-3LSRP-H-JL |
Connecting link |
RS60 |
| RS60-AS-3LSRP-T-JL |
Connecting link |
RS60 |
| RS60-LMC-3LSR-H-JL |
Connecting link |
RS60 |
| RS60-LMC-3LSR-T-JL |
Connecting link |
RS60 |
| RS60-LMC-3LSRP-H-JL |
Connecting link |
RS60 |
| RS60-LMC-3LSRP-T-JL |
Connecting link |
RS60 |
| RS60-NP-3LSR-H-JL |
Connecting link |
RS60 |
| RS60-NP-3LSR-T-JL |
Connecting link |
RS60 |
| RS60-NP-3LSRP-H-JL |
Connecting link |
RS60 |
| RS60-NP-3LSRP-T-JL |
Connecting link |
RS60 |
| RS60-PC-3LSRP-H-JL |
Connecting link |
RS60 |
| RS60-PC-3LSRP-T-JL |
Connecting link |
RS60 |
| RS60-SS-3LSR-H-JL |
Connecting link |
RS60 |
| RS60-SS-3LSR-T-JL |
Connecting link |
RS60 |
| RS60-SS-3LSRP-H-JL |
Connecting link |
RS60 |
| RS60-SS-3LSRP-T-JL |
Connecting link |
RS60 |
| RS80-3LSR-H-JL |
Connecting link |
RS80 |
| RS80-3LSR-T-JL |
Connecting link |
RS80 |
| RS80-3LSRP-H-JL |
Connecting link |
RS80 |
| RS80-3LSRP-T-JL |
Connecting link |
RS80 |
| RS80-LMC-3LSR-H-JL |
Connecting link |
RS80 |
| RS80-LMC-3LSR-T-JL |
Connecting link |
RS80 |
| RS80-LMC-3LSRP-H-JL |
Connecting link |
RS80 |
| RS80-LMC-3LSRP-T-JL |
Connecting link |
RS80 |
How to Order
Check the base chain number, side roller arrangement and specification (standard, NP or LMC). Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
