TSUBAKI PT — PX Lock Pulley S Type P5M10BF (Aluminum), genuine TSUBAKI product.
Overview
This PX Lock Pulley S Type is an aluminum TSUBAKI timing pulley for P5M PX belts with a keyless locking element built into the hub. Tightening the locking bolts clamps the pulley to a plain shaft, so no keyway or set screw is required and the pulley can be phased precisely. Aluminum keeps inertia low for automation and indexing drives.
Key Features
- Keyless locking hub for plain shafts
- Aluminum body for low inertia
- P5M tooth profile for PX belts
- Precise phase adjustment during setup
Specifications
| Part No. |
Material |
No. of Teeth |
Belt Width (mm) |
Type |
Mounting Method |
Pitch Circle Diameter (Ømm) |
Dim. l (mm) |
Nominal Width (mm) |
L1(mm) |
Dim. T (mm) |
Dim. D (Ømm) |
| PT44P5M10BF-A-SS4330 |
High-strength aluminum alloy |
44 |
10 |
PX lock pulley |
BF-S (standard mounting) |
70.03 |
26 |
10 |
15.5 |
8 |
56 |
| PT44P5M10BF-A-SS4332 |
High-strength aluminum alloy |
44 |
10 |
PX lock pulley |
BF-S (standard mounting) |
70.03 |
26 |
10 |
15.5 |
8 |
56 |
| PT44P5M10BF-A-SS4335 |
High-strength aluminum alloy |
44 |
10 |
PX lock pulley |
BF-S (standard mounting) |
70.03 |
26 |
10 |
15.5 |
8 |
56 |
| PT48P5M10BF-A-SS4330 |
High-strength aluminum alloy |
48 |
10 |
PX lock pulley |
BF-S (standard mounting) |
76.39 |
26 |
10 |
15.5 |
8 |
56 |
| PT48P5M10BF-A-SS4332 |
High-strength aluminum alloy |
48 |
10 |
PX lock pulley |
BF-S (standard mounting) |
76.39 |
26 |
10 |
15.5 |
8 |
56 |
| PT48P5M10BF-A-SS4335 |
High-strength aluminum alloy |
48 |
10 |
PX lock pulley |
BF-S (standard mounting) |
76.39 |
26 |
10 |
15.5 |
8 |
56 |
| PT50P5M10BF-A-SS4330 |
High-strength aluminum alloy |
50 |
10 |
PX lock pulley |
BF-S (standard mounting) |
79.58 |
26 |
10 |
15.5 |
8 |
56 |
| PT50P5M10BF-A-SS4332 |
High-strength aluminum alloy |
50 |
10 |
PX lock pulley |
BF-S (standard mounting) |
79.58 |
26 |
10 |
15.5 |
8 |
56 |
| PT50P5M10BF-A-SS4335 |
High-strength aluminum alloy |
50 |
10 |
PX lock pulley |
BF-S (standard mounting) |
79.58 |
26 |
10 |
15.5 |
8 |
56 |
| PT60P5M10BF-A-SS4330 |
High-strength aluminum alloy |
60 |
10 |
PX lock pulley |
BF-S (standard mounting) |
95.49 |
26 |
10 |
15.5 |
8 |
56 |
| PT60P5M10BF-A-SS4332 |
High-strength aluminum alloy |
60 |
10 |
PX lock pulley |
BF-S (standard mounting) |
95.49 |
26 |
10 |
15.5 |
8 |
56 |
| PT60P5M10BF-A-SS4335 |
High-strength aluminum alloy |
60 |
10 |
PX lock pulley |
BF-S (standard mounting) |
95.49 |
26 |
10 |
15.5 |
8 |
56 |
How to Order
Confirm tooth count, belt width and shaft diameter for the locking element. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
