TSUBAKI RS15 Sprocket Type 1B, RS15-1B

Description

TSUBAKI RS15-1B — RS15 Sprocket Type 1B, genuine TSUBAKI product.

Overview

The Tsubaki RS15 Type 1B sprocket is a miniature sprocket for RS15 chain, one of the smallest standard roller chain sizes with a 4.7625mm pitch. A small hub on one side allows set-screw fixing to the shaft. It is used in office equipment, vending machines, small instruments and compact mechanisms where a light, precise chain drive is needed.

Key Features

  • Sized for miniature RS15 roller chain
  • Single hub for set-screw mounting
  • Compact for tight mechanism layouts
  • Range of small tooth counts

Specifications

Part No. Material Shape No. of Teeth Bore Type Chain Pitch (mm) Tooth Width (mm) Type Type No. of Strands Pitch Diameter (Dp) (Ømm) Outer Diameter (Do) (Ømm) Roller Diameter (Ømm)
RS15-1B11T Carbon steel for machine structural use, machined specification 1B 11 Pilot bore type 4.7625 2 Standard product Sprocket 1 16.9 19 2.48
RS15-1B12T Carbon steel for machine structural use, machined specification 1B 12 Pilot bore type 4.7625 2 Standard product Sprocket 1 18.4 20.5 2.48
RS15-1B13T Carbon steel for machine structural use, machined specification 1B 13 Pilot bore type 4.7625 2 Standard product Sprocket 1 19.9 22 2.48
RS15-1B14T Carbon steel for machine structural use, machined specification 1B 14 Pilot bore type 4.7625 2 Standard product Sprocket 1 21.4 23.5 2.48
RS15-1B15T Carbon steel for machine structural use, machined specification 1B 15 Pilot bore type 4.7625 2 Standard product Sprocket 1 22.91 25 2.48
RS15-1B16T Carbon steel for machine structural use, machined specification 1B 16 Pilot bore type 4.7625 2 Standard product Sprocket 1 24.41 26.5 2.48
RS15-1B17T Carbon steel for machine structural use, machined specification 1B 17 Pilot bore type 4.7625 2 Standard product Sprocket 1 25.92 28 2.48
RS15-1B18T Carbon steel for machine structural use, machined specification 1B 18 Pilot bore type 4.7625 2 Standard product Sprocket 1 27.43 29.5 2.48
RS15-1B19T Carbon steel for machine structural use, machined specification 1B 19 Pilot bore type 4.7625 2 Standard product Sprocket 1 28.93 31 2.48
RS15-1B20T Carbon steel for machine structural use, machined specification 1B 20 Pilot bore type 4.7625 2 Standard product Sprocket 1 30.44 32.5 2.48
RS15-1B21T Carbon steel for machine structural use, machined specification 1B 21 Pilot bore type 4.7625 2 Standard product Sprocket 1 31.95 34 2.48
RS15-1B22T Carbon steel for machine structural use, machined specification 1B 22 Pilot bore type 4.7625 2 Standard product Sprocket 1 33.46 35.5 2.48
RS15-1B23T Carbon steel for machine structural use, machined specification 1B 23 Pilot bore type 4.7625 2 Standard product Sprocket 1 34.98 37.5 2.48
RS15-1B24T Carbon steel for machine structural use, machined specification 1B 24 Pilot bore type 4.7625 2 Standard product Sprocket 1 36.49 39 2.48
RS15-1B25T Carbon steel for machine structural use, machined specification 1B 25 Pilot bore type 4.7625 2 Standard product Sprocket 1 38 40.5 2.48
RS15-1B26T Carbon steel for machine structural use, machined specification 1B 26 Pilot bore type 4.7625 2 Standard product Sprocket 1 39.51 42 2.48
RS15-1B27T Carbon steel for machine structural use, machined specification 1B 27 Pilot bore type 4.7625 2 Standard product Sprocket 1 41.02 43.5 2.48
RS15-1B28T Carbon steel for machine structural use, machined specification 1B 28 Pilot bore type 4.7625 2 Standard product Sprocket 1 42.54 45 2.48
RS15-1B29T Carbon steel for machine structural use, machined specification 1B 29 Pilot bore type 4.7625 2 Standard product Sprocket 1 44.05 46.5 2.48
RS15-1B30T Carbon steel for machine structural use, machined specification 1B 30 Pilot bore type 4.7625 2 Standard product Sprocket 1 45.56 48 2.48
RS15-1B31T Carbon steel for machine structural use, machined specification 1B 31 Pilot bore type 4.7625 2 Standard product Sprocket 1 47.08 49.5 2.48
RS15-1B32T Carbon steel for machine structural use, machined specification 1B 32 Pilot bore type 4.7625 2 Standard product Sprocket 1 48.59 51 2.48
RS15-1B33T Carbon steel for machine structural use, machined specification 1B 33 Pilot bore type 4.7625 2 Standard product Sprocket 1 50.1 52.5 2.48
RS15-1B34T Carbon steel for machine structural use, machined specification 1B 34 Pilot bore type 4.7625 2 Standard product Sprocket 1 51.62 54 2.48
RS15-1B35T Carbon steel for machine structural use, machined specification 1B 35 Pilot bore type 4.7625 2 Standard product Sprocket 1 53.13 55.5 2.48

How to Order

Check the number of teeth and the bore size, and confirm the shaft fixing method. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.

Product image is representative of the TSUBAKI series; appearance varies by size and model.

About TSUBAKI

Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.

Ordering & Shipping

  • Genuine TSUBAKI product sourced through Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Lead time varies by model; please inquire for exact delivery
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
Product form

TSUBAKI RS15-1B — RS15 Sprocket Type 1B, genuine TSUBAKI product.OverviewThe Tsubaki RS15 Type 1B sprocket is a miniature sprocket for... Read more

SKU: RS15-1B11T

$30.45 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
    • Secure payments Paypal
