The TSUBAKI RS35 Finished Bore Sprocket Type 1B is supplied with the bore, keyway and set screw holes already machined. This avoids in-house machining and gets drives running faster. It runs with RS35 roller chain and is used in light machinery, conveyors and equipment where standard shaft sizes are used.
| Part No. |
Shape |
No. of Teeth |
Bore Type |
Chain Pitch (mm) |
Tooth Width (mm) |
Type |
Dim. A (mm) |
No. of Strands |
Set Screw |
Groove Diameter (Ømm) |
Pitch Diameter (Dp) (Ømm) |
Set Screw |
Outer Diameter (Do) (Ømm) |
| RS35-1B10TQ-H010N-J04D2M04 |
1B |
10 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M4 |
18 |
30.82 |
|
35 |
| RS35-1B10TQ-H012N-J04D2M04 |
1B |
10 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
18 |
30.82 |
|
35 |
| RS35-1B11TQ-H010N-J04D2M04 |
1B |
11 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M4 |
22 |
33.81 |
|
38 |
| RS35-1B11TQ-H012N-J04D2M04 |
1B |
11 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
22 |
33.81 |
|
38 |
| RS35-1B11TQ-H014N-J05D2M05 |
1B |
11 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
22 |
33.81 |
|
38 |
| RS35-1B12TQ-H010N-J04D2M04 |
1B |
12 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M4 |
24 |
36.8 |
|
40 |
| RS35-1B12TQ-H012N-J04D2M04 |
1B |
12 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
24 |
36.8 |
|
40 |
| RS35-1B12TQ-H014N-J05D2M05 |
1B |
12 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
24 |
36.8 |
|
40 |
| RS35-1B12TQ-H015N-J05D2M05 |
1B |
12 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
24 |
36.8 |
|
40 |
| RS35-1B12TQ-H016N-J05D2M05 |
1B |
12 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
24 |
36.8 |
|
40 |
| RS35-1B13TQ-H010N-J04D2M04 |
1B |
13 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M4 |
28 |
39.8 |
|
44 |
| RS35-1B13TQ-H012N-J04D2M04 |
1B |
13 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
28 |
39.8 |
|
44 |
| RS35-1B13TQ-H014N-J05D2M05 |
1B |
13 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
28 |
39.8 |
|
44 |
| RS35-1B13TQ-H015N-J05D2M05 |
1B |
13 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
28 |
39.8 |
|
44 |
| RS35-1B13TQ-H016N-J05D2M05 |
1B |
13 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M5 |
28 |
39.8 |
|
44 |
| RS35-1B13TQ-H017N-J05D2M05 |
1B |
13 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M6 |
28 |
39.8 |
|
44 |
| RS35-1B13TQ-H018N-J06D2M06 |
1B |
13 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
5 |
1 |
M6 |
28 |
39.8 |
|
44 |
| RS35-1B14TQ-H010N-J04D2M04 |
1B |
14 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M4 |
|
42.81 |
2 locations |
46 |
| RS35-1B14TQ-H012N-J04D2M04 |
1B |
14 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
42.81 |
2 locations |
46 |
| RS35-1B14TQ-H014N-J05D2M05 |
1B |
14 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
42.81 |
2 locations |
46 |
| RS35-1B14TQ-H015N-J05D2M05 |
1B |
14 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
42.81 |
2 locations |
46 |
| RS35-1B14TQ-H016N-J05D2M05 |
1B |
14 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
42.81 |
2 locations |
46 |
| RS35-1B15TQ-H010N-J04D2M04 |
1B |
15 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M4 |
|
45.81 |
2 locations |
51 |
| RS35-1B15TQ-H012N-J04D2M04 |
1B |
15 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
45.81 |
2 locations |
51 |
| RS35-1B15TQ-H014N-J05D2M05 |
1B |
15 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
45.81 |
2 locations |
51 |
| RS35-1B15TQ-H015N-J05D2M05 |
1B |
15 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
45.81 |
2 locations |
51 |
| RS35-1B15TQ-H016N-J05D2M05 |
1B |
15 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
45.81 |
2 locations |
51 |
| RS35-1B15TQ-H017N-J05D2M05 |
1B |
15 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
45.81 |
2 locations |
51 |
| RS35-1B15TQ-H018N-J06D2M06 |
1B |
15 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
45.81 |
2 locations |
51 |
| RS35-1B15TQ-H019N-J06D2M06 |
1B |
15 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
45.81 |
2 locations |
51 |
| RS35-1B16TQ-H012N-J04D2M04 |
1B |
16 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
48.82 |
2 locations |
53 |
| RS35-1B16TQ-H014N-J05D2M05 |
1B |
16 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
48.82 |
2 locations |
53 |
| RS35-1B16TQ-H015N-J05D2M05 |
1B |
16 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
48.82 |
2 locations |
53 |
| RS35-1B16TQ-H016N-J05D2M05 |
1B |
16 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
48.82 |
2 locations |
53 |
| RS35-1B16TQ-H017N-J05D2M05 |
1B |
16 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
48.82 |
2 locations |
53 |
| RS35-1B16TQ-H018N-J06D2M06 |
1B |
16 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
48.82 |
2 locations |
53 |
| RS35-1B16TQ-H019N-J06D2M06 |
1B |
16 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
48.82 |
2 locations |
53 |
| RS35-1B16TQ-H020N-J06D2M06 |
1B |
16 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
48.82 |
2 locations |
53 |
| RS35-1B17TQ-H012N-J04D2M04 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H014N-J05D2M05 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H015N-J05D2M05 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H016N-J05D2M05 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H017N-J05D2M05 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H018N-J06D2M06 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H019N-J06D2M06 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H020N-J06D2M06 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H022N-J06D2M06 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
51.84 |
2 locations |
57 |
| RS35-1B17TQ-H024N-J08D2M06 |
1B |
17 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
51.84 |
2 locations |
57 |
| RS35-1B18TQ-H012N-J04D2M04 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H014N-J05D2M05 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H015N-J05D2M05 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H016N-J05D2M05 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H017N-J05D2M05 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H018N-J06D2M06 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H019N-J06D2M06 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H020N-J06D2M06 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H022N-J06D2M06 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
54.85 |
2 locations |
60 |
| RS35-1B18TQ-H024N-J08D2M06 |
1B |
18 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
54.85 |
2 locations |
60 |
| RS35-1B19TQ-H012N-J04D2M04 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H014N-J05D2M05 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H015N-J05D2M05 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H016N-J05D2M05 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H017N-J05D2M05 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H018N-J06D2M06 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H019N-J06D2M06 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H020N-J06D2M06 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H022N-J06D2M06 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H024N-J08D2M06 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H025N-J08D2M06 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
57.87 |
2 locations |
63 |
| RS35-1B19TQ-H028N-J08D2M06 |
1B |
19 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
57.87 |
2 locations |
63 |
| RS35-1B20TQ-H012N-J04D2M04 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H014N-J05D2M05 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H015N-J05D2M05 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H016N-J05D2M05 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H017N-J05D2M05 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H018N-J06D2M06 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H019N-J06D2M06 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H020N-J06D2M06 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H022N-J06D2M06 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H024N-J08D2M06 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H025N-J08D2M06 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H028N-J08D2M06 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
60.89 |
2 locations |
66 |
| RS35-1B20TQ-H030N-J08D2M06 |
1B |
20 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M8 |
|
60.89 |
2 locations |
66 |
| RS35-1B21TQ-H012N-J04D2M04 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H014N-J05D2M05 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H015N-J05D2M05 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H016N-J05D2M05 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H017N-J05D2M05 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H018N-J06D2M06 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H019N-J06D2M06 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H020N-J06D2M06 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H022N-J06D2M06 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H024N-J08D2M06 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H025N-J08D2M06 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H028N-J08D2M06 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M6 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H030N-J08D2M06 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M8 |
|
63.91 |
2 locations |
69 |
| RS35-1B21TQ-H032N-J10D2M08 |
1B |
21 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M8 |
|
63.91 |
2 locations |
69 |
| RS35-1B22TQ-H012N-J04D2M04 |
1B |
22 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
66.93 |
2 locations |
72 |
| RS35-1B22TQ-H014N-J05D2M05 |
1B |
22 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
66.93 |
2 locations |
72 |
| RS35-1B22TQ-H015N-J05D2M05 |
1B |
22 |
Shaft bore finished type |
9.525 |
4.4 |
Sprocket |
8 |
1 |
M5 |
|
66.93 |
2 locations |
72 |
Specify the number of teeth, bore diameter, keyway standard and set screw configuration. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
