TSUBAKI RS35-1B — RS35 Lock Sprocket S Type, Form B, genuine TSUBAKI product.
Overview
The TSUBAKI RS35 Lock Sprocket S Type in Form B combines an RS35 sprocket with an integrated keyless locking element. The lock grips the shaft by friction so the sprocket can be positioned precisely without keyways. It is used in conveyors and automation drives that require easy timing adjustment.
Key Features
- Integrated keyless lock
- Form B lock arrangement
- RS35 chain tooth form
Specifications
| Part No. |
No. of Teeth |
Bore Type |
Chain Pitch (mm) |
Tooth Width (mm) |
Type |
Mounting Method |
L1(mm) |
No. of Strands |
Tightening Torque (N·m) |
Pitch Diameter (Dp) (Ømm) |
Outer Diameter (Do) (Ømm) |
Roller Diameter (Ømm) |
| RS35-1B15TQ-S1410B |
15 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
45.81 |
51 |
5.08 |
| RS35-1B15TQ-S1411B |
15 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
45.81 |
51 |
5.08 |
| RS35-1B15TQ-S1412B |
15 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
45.81 |
51 |
5.08 |
| RS35-1B15TQ-S1414B |
15 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
45.81 |
51 |
5.08 |
| RS35-1B15TQ-S1415B |
15 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
45.81 |
51 |
5.08 |
| RS35-1B15TQ-S1416B |
15 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
45.81 |
51 |
5.08 |
| RS35-1B16TQ-S1410B |
16 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
48.82 |
54 |
5.08 |
| RS35-1B16TQ-S1411B |
16 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
48.82 |
54 |
5.08 |
| RS35-1B16TQ-S1412B |
16 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
48.82 |
54 |
5.08 |
| RS35-1B16TQ-S1414B |
16 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
48.82 |
54 |
5.08 |
| RS35-1B16TQ-S1415B |
16 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
48.82 |
54 |
5.08 |
| RS35-1B16TQ-S1416B |
16 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
48.82 |
54 |
5.08 |
| RS35-1B17TQ-S1410B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S1411B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S1412B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S1414B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S1415B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S1416B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S2417B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S2418B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S2419B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S2420B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
51.84 |
57 |
5.08 |
| RS35-1B17TQ-S2422B |
17 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
51.84 |
57 |
5.08 |
| RS35-1B18TQ-S1411B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S1412B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S1414B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S1415B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S1416B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S2417B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S2418B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S2419B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S2420B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
54.85 |
60 |
5.08 |
| RS35-1B18TQ-S2422B |
18 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
54.85 |
60 |
5.08 |
| RS35-1B19TQ-S1411B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S1412B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S1414B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S1415B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S1416B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S2417B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S2418B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S2419B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S2420B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
57.87 |
63 |
5.08 |
| RS35-1B19TQ-S2422B |
19 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
57.87 |
63 |
5.08 |
| RS35-1B20TQ-S1412B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S1414B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S1415B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S1416B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S2417B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S2418B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S2419B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S2420B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S2422B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S3324B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S3325B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
60.89 |
66 |
5.08 |
| RS35-1B20TQ-S3328B |
20 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
60.89 |
66 |
5.08 |
| RS35-1B21TQ-S1614B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S1615B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S1616B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S2417B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S2418B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S2419B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S2420B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S2422B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S3424B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S3425B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
63.91 |
69 |
5.08 |
| RS35-1B21TQ-S3428B |
21 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
63.91 |
69 |
5.08 |
| RS35-1B22TQ-S1614B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S1615B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S1616B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S2417B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S2418B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S2419B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S2420B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S2422B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S4424B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S4425B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S4428B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S4430B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S4432B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B22TQ-S4435B |
22 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
66.93 |
72 |
5.08 |
| RS35-1B23TQ-S1614B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S1615B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S1616B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S2417B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S2418B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S2419B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S2420B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S2422B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S4424B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S4425B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S4428B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S4430B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S4432B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B23TQ-S4435B |
23 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
15.5 |
1 |
8.3 |
69.95 |
75 |
5.08 |
| RS35-1B24TQ-S1614B |
24 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
72.97 |
78 |
5.08 |
| RS35-1B24TQ-S1615B |
24 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
72.97 |
78 |
5.08 |
| RS35-1B24TQ-S1616B |
24 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
12 |
1 |
4.2 |
72.97 |
78 |
5.08 |
| RS35-1B24TQ-S2417B |
24 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
72.97 |
78 |
5.08 |
| RS35-1B24TQ-S2418B |
24 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
72.97 |
78 |
5.08 |
| RS35-1B24TQ-S2419B |
24 |
Surface-pressure type |
9.525 |
4.4 |
Sprocket |
B |
14 |
1 |
8.3 |
72.97 |
78 |
5.08 |
How to Order
Specify the number of teeth and the shaft bore of the lock element. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
