Description
TSUBAKI RS60-1B — RS60 Stainless Steel Sprocket Type 1B, genuine TSUBAKI product.
Overview
The TSUBAKI RS60 stainless steel sprocket Type 1B has a single-side hub and is made for RS60 roller chain. Stainless steel resists corrosion in wet, chemical or washdown environments, avoiding rust contamination of products. It is used together with stainless chain in food processing, chemical plants, water treatment and outdoor applications.
Key Features
- Stainless steel construction
- Single-side hub for RS60 chain
- Pairs with stainless roller chain
Specifications
| Part No. |
Material |
Shape |
No. of Teeth |
Bore Type |
Chain Pitch (mm) |
Tooth Width (mm) |
Type |
Approx. Mass (kg) |
No. of Strands |
Groove Diameter (Ømm) |
Pitch Diameter (Dp) (Ømm) |
Outer Diameter (Do) (Ømm) |
Roller Diameter (Ømm) |
| RS60-1B10T-SS |
Stainless steel, machined specification |
1B |
10 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
0.49 |
1 |
37 |
61.65 |
70 |
|
| RS60-1B11T-SS |
Stainless steel, machined specification |
1B |
11 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
0.6 |
1 |
45 |
67.62 |
76 |
|
| RS60-1B12T-SS |
Stainless steel, machined specification |
1B |
12 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
0.69 |
1 |
|
73.6 |
83 |
11.91 |
| RS60-1B13T-SS |
Stainless steel, machined specification |
1B |
13 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
0.81 |
1 |
|
79.6 |
89 |
11.91 |
| RS60-1B14T-SS |
Stainless steel, machined specification |
1B |
14 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
0.96 |
1 |
|
85.61 |
95 |
11.91 |
| RS60-1B15T-SS |
Stainless steel, machined specification |
1B |
15 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
1.1 |
1 |
|
91.63 |
101 |
11.91 |
| RS60-1B16T-SS |
Stainless steel, machined specification |
1B |
16 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
1.3 |
1 |
|
97.65 |
107 |
11.91 |
| RS60-1B17T-SS |
Stainless steel, machined specification |
1B |
17 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
1.4 |
1 |
|
103.67 |
113 |
11.91 |
| RS60-1B18T-SS |
Stainless steel, machined specification |
1B |
18 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2 |
1 |
|
109.7 |
119 |
11.91 |
| RS60-1B19T-SS |
Stainless steel, machined specification |
1B |
19 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2.1 |
1 |
|
115.74 |
126 |
11.91 |
| RS60-1B20T-SS |
Stainless steel, machined specification |
1B |
20 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2.2 |
1 |
|
121.78 |
132 |
11.91 |
| RS60-1B21T-SS |
Stainless steel, machined specification |
1B |
21 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2.3 |
1 |
|
127.82 |
138 |
11.91 |
| RS60-1B22T-SS |
Stainless steel, machined specification |
1B |
22 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2.5 |
1 |
|
133.86 |
144 |
11.91 |
| RS60-1B23T-SS |
Stainless steel, machined specification |
1B |
23 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2.5 |
1 |
|
139.9 |
150 |
11.91 |
| RS60-1B24T-SS |
Stainless steel, machined specification |
1B |
24 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2.6 |
1 |
|
145.95 |
156 |
11.91 |
| RS60-1B25T-SS |
Stainless steel, machined specification |
1B |
25 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2.7 |
1 |
|
151.99 |
162 |
11.91 |
| RS60-1B26T-SS |
Stainless steel, machined specification |
1B |
26 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
2.9 |
1 |
|
158.04 |
168 |
11.91 |
| RS60-1B27T-SS |
Stainless steel, machined specification |
1B |
27 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
3 |
1 |
|
164.09 |
174 |
11.91 |
| RS60-1B28T-SS |
Stainless steel, machined specification |
1B |
28 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
3.1 |
1 |
|
170.14 |
180 |
11.91 |
| RS60-1B30T-SS |
Stainless steel, machined specification |
1B |
30 |
Pilot bore type |
19.05 |
11.9 |
Sprocket |
3.4 |
1 |
|
182.25 |
193 |
11.91 |
How to Order
Specify the number of teeth and bore requirements. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
