Description
TSUBAKI RS1 — End Bolt (for RS Roller Chain), genuine TSUBAKI product.
Overview
An end bolt connects RS roller chain to a fixed point, such as a lifting attachment, take-up or machine frame. This TSUBAKI end bolt is used in lifting, tensioning and counterweight applications where chain must be anchored rather than looped. It is threaded for adjustment.
Key Features
- Anchors chain ends to fixed points
- Threaded shank allows tension adjustment
- Matched to RS chain pitch
- Used in lifting and take-up systems
Specifications
| Part No. |
Compatible Body |
Mass (kg) |
Type |
Dim. l (mm) |
Dim. H (mm) |
Dim. A (mm) |
Dim. D (mm) |
Dim. B (mm) |
Dim. C (mm) |
Size M (mm) |
Dim. O (mm) |
SW(mm) |
| RS100EB |
RS100-1 |
0.51 |
Chain bolt turnbuckle |
145.1 |
16 |
98 |
34 |
91 |
15.1 |
M20 |
9.58 |
30 |
| RS120EB |
RS120-1 |
0.86 |
Chain bolt turnbuckle |
173.1 |
19 |
117 |
40 |
108 |
18.1 |
M24 |
11.15 |
35.5 |
How to Order
Confirm chain number and required thread size. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
