TSUBAKI RF2 — Top Roller Wheel, genuine TSUBAKI product.
Overview
The Tsubaki top roller wheel is a sprocket-like wheel designed to engage double pitch chain with R rollers. It is used in conveyors where the chain needs guidance or drive at specific points, and is supplied with pilot or finished bores. It is often used on conveyor turns or as a support wheel for chain carrying loads on top rollers.
Key Features
- Engages R roller double pitch chain
- Pilot bore for machining
- Suitable for conveyor drive or guide
- Defined tooth width
Specifications
| Part No. |
Bore Type |
Tooth Width (mm) |
Type |
No. of Strands |
Chain No. |
Pilot Bore Diameter d (Ømm) |
Boss Length L (mm) |
Outer Diameter Do (Ømm) |
Roller Type |
Tooth Profile |
Roller Pitch Circle Diameter dp (mm) |
Bore Diameter (Ømm) |
| RF2040R-1B1100T-TR |
Pilot bore type |
7.3 |
Sprocket |
1 |
RF2040R |
12.7 |
25 |
97 |
R roller |
Type B |
90.16 |
～42 |
| RF2040R-1B1200T-TR |
Pilot bore type |
7.3 |
Sprocket |
1 |
RF2040R |
12.7 |
25 |
105 |
R roller |
Type B |
98.14 |
～42 |
| RF2040R-1B1300T-TR |
Pilot bore type |
7.3 |
Sprocket |
1 |
RF2040R |
12.7 |
25 |
114 |
R roller |
Type B |
106.14 |
～42 |
| RF2050R-1B1100T-TR |
Pilot bore type |
8.9 |
Sprocket |
1 |
RF2050R |
15.9 |
28 |
124 |
R roller |
Type B |
112.7 |
～48 |
| RF2050R-1B1200T-TR |
Pilot bore type |
8.9 |
Sprocket |
1 |
RF2050R |
18 |
28 |
134 |
R roller |
Type B |
122.67 |
～48 |
| RF2050R-1B1300T-TR |
Pilot bore type |
8.9 |
Sprocket |
1 |
RF2050R |
18 |
28 |
144 |
R roller |
Type B |
132.67 |
～48 |
| RF2060R-1B1100T-TR |
Pilot bore type |
11.9 |
Sprocket |
1 |
RF2060R |
18 |
45 |
150 |
R roller |
Type B |
135.24 |
～55 |
| RF2060R-1B1200T-TR |
Pilot bore type |
11.9 |
Sprocket |
1 |
RF2060R |
18 |
45 |
162 |
R roller |
Type B |
147.21 |
～55 |
| RF2060R-1B1300T-TR |
Pilot bore type |
11.9 |
Sprocket |
1 |
RF2060R |
18 |
45 |
175 |
R roller |
Type B |
159.2 |
～55 |
| RF2080R-1B1100T-TR |
Pilot bore type |
15 |
Sprocket |
1 |
RF2080R |
28 |
45 |
199 |
R roller |
Type B |
180.31 |
～75 |
| RF2080R-1B1200T-TR |
Pilot bore type |
15 |
Sprocket |
1 |
RF2080R |
28 |
45 |
216 |
R roller |
Type B |
196.28 |
～75 |
| RF2080R-1B1300T-TR |
Pilot bore type |
15 |
Sprocket |
1 |
RF2080R |
28 |
45 |
323 |
R roller |
Type B |
212.27 |
～75 |
| RF2100R-1B1100T-TR |
Pilot bore type |
18 |
Sprocket |
1 |
RF2100R |
33 |
56 |
244 |
R roller |
Type B |
225.39 |
～80 |
How to Order
Specify chain number, number of teeth and bore. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
