TSUBAKI RF2060 — Lock Sprocket for Double Pitch Chain RF2060, genuine TSUBAKI product.
Overview
This Tsubaki lock sprocket is for RF2060 double pitch chain, supplied with a keyless locking element so it can be fixed to a plain shaft. The lock simplifies installation and lets the sprocket be timed precisely. It is used in conveyors and indexing equipment using RF2060 chain.
Key Features
- Pre-fitted keyless locking element
- Teeth for RF2060 double pitch chain
- Easy timing and alignment
- Removable without damaging the shaft
