TSUBAKI Heavy Duty Large Conveyor Chain (AT Spec) S Roller (Part 1)

Description

TSUBAKI RF — Heavy Duty Large Conveyor Chain (AT Spec) S Roller, genuine TSUBAKI product.

Overview

This heavy duty large conveyor chain to TSUBAKI AT specification uses standard S rollers, which engage sprockets while the chain is supported by the attachments or plates. Strengthened components handle high tension and abrasive bulk materials. It is used in drag, flight and bucket conveyors in cement, steel, recycling and environmental plants.

Key Features

  • Strengthened construction for heavy conveying
  • S rollers for sprocket engagement
  • Resists wear in abrasive service
  • Attachments for flights and buckets

Specifications

Part No. Material (Body) Type Pitch Type Pitch (mm) Link Width (mm) Approx. Mass (kg/m) Roller Diameter (Ømm) Chain No. Plate Thickness (mm) Min. Tensile Strength (kN) Chain Type Avg. Tensile Strength (kN)
RF03075S-AT-1LA1-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-1LA2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-1LK1-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-1LK2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-2LA1-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-2LA2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-2LGA2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-2LK1-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-2LK2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-3LA1-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-3LA2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-3LGA2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-3LK1-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-3LK2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-4LA1-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-4LA2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-4LGA2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-4LK1-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-4LK2-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03075S-AT-L Steel Per link Metric pitch Vertical conveyor chain 75 16.1 1.8 15.9 RF03075S 3.2 59.2 69.6
RF03100S-AT-1LA1-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-1LA2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-1LGA2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-1LK1-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-1LK2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-2LA1-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-2LA2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-2LGA2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-2LK1-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-2LK2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-3LA1-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-3LA2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-3LGA2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-3LK1-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-3LK2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-4LA1-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-4LA2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-4LGA2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-4LK1-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-4LK2-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF03100S-AT-L Steel Per link Metric pitch Vertical conveyor chain 100 16.1 1.6 15.9 RF03100S 3.2 59.2 69.6
RF05075S-AT-1LA1-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-1LA2-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-1LK1-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-1LK2-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-2LA1-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-2LA2-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-2LK1-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-2LK2-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-3LA1-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-3LA2-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-3LK1-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-3LK2-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-4LA1-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-4LA2-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-4LK1-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-4LK2-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05075S-AT-L Steel Per link Metric pitch Vertical conveyor chain 75 22 4.3 22.2 RF05075S 4.5 121 142
RF05100S-AT-1LA1-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-1LA2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-1LGA2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-1LK1-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-1LK2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-2LA1-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-2LA2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-2LGA2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-2LGA4-L Steel Per link Metric pitch Vertical conveyor chain 100 22 22.2 RF05100S 4.5 121 Heavy-duty large conveyor chain 142
RF05100S-AT-2LK1-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-2LK2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-3LA1-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-3LA2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-3LGA2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-3LK1-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-3LK2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-4LA1-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-4LA2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-4LGA2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-4LK1-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-4LK2-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05100S-AT-L Steel Per link Metric pitch Vertical conveyor chain 100 22 3.8 22.2 RF05100S 4.5 121 142
RF05125S-AT-1LA1-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-1LA2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-1LGA2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-1LK1-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-1LK2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-2LA1-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-2LA2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-2LGA2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-2LK1-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-2LK2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-3LA1-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-3LA2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-3LGA2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-3LK1-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-3LK2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-4LA1-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-4LA2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-4LGA2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-4LK1-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142
RF05125S-AT-4LK2-L Steel Per link Metric pitch Vertical conveyor chain 125 22 3.4 22.2 RF05125S 4.5 121 142

How to Order

Confirm chain number, attachment type and conveyor length. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.

Product image is representative of the TSUBAKI series; appearance varies by size and model.

About TSUBAKI

Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.

Ordering & Shipping

  • Genuine TSUBAKI product sourced through Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Lead time varies by model; please inquire for exact delivery
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
Product form

TSUBAKI RF — Heavy Duty Large Conveyor Chain (AT Spec) S Roller, genuine TSUBAKI product.OverviewThis heavy duty large conveyor chain... Read more

SKU: RF03075S-AT-1LA1-L

$10.72 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
