Description
TSUBAKI TPU — Sprocket for Top Chain, genuine TSUBAKI product.
Overview
This Tsubaki sprocket is designed for plastic top chain such as TPUSR and TPUN types, with a tooth form that matches the chain's hinge geometry. It drives or idles the chain on conveyor shafts and may be split or solid depending on construction. It is used in container conveyors throughout the food, beverage and packaging industries.
Key Features
- Tooth form matched to top chain hinges
- Drive or idler use on conveyor shafts
- Plastic or metal construction options
- Defined working dimensions for layout
Specifications
| Part No. |
Material |
Approx. Mass (kg) |
Construction |
Working Dimension |
Outer Diameter Do (Ømm) |
| TPUN555-1000TQ |
Carbon steel for machine structural use |
2.7 |
Machined |
10 |
163 |
| TPUN555-1200TQ |
Carbon steel for machine structural use |
3.1 |
Welded |
12 |
198 |
| TPUN555-800TQ |
Carbon steel for machine structural use |
1.9 |
Machined |
8 |
134 |
| TPUSR1500T |
Carbon steel for machine structural use |
2 |
Welded |
15 |
|
| TPUSR1500T-SS |
Stainless steel |
2 |
Machined |
15 |
|
How to Order
Specify the chain type, number of teeth, bore and sprocket construction. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
