TSUBAKI TGB — Shock Guard TGB Series, genuine TSUBAKI product.
Overview
The TSUBAKI Shock Guard TGB Series is a mechanical torque limiter that disengages the drive when an overload occurs. Balls held in detents by spring force transmit torque normally and roll out of their seats when the set torque is exceeded, separating input from output. It protects machinery such as conveyors, packaging machines and indexing drives from jams.
Key Features
- Ball-detent design trips at a set torque
- Quickly separates drive on overload
- Trip torque adjustable within range
- Can be combined with a detection sensor
Specifications
| Part No. |
Mass (kg) |
Dim. l (mm) |
Max. Bore Diameter (mm) |
Pilot Bore Diameter (Ømm) |
Dim. A (mm) |
P |
Size S (mm) |
Dim. D (mm) |
Dim. E (mm) |
Dim. B (mm) |
Dim. C (mm) |
N(mm) |
Dim. J (mm) |
Dim. T (mm) |
| TGB08-H |
0.14 |
|
8 |
5 |
39 |
M3-L4 |
|
20 |
40 |
6.5 |
5 |
3 |
29.5 |
0.9 |
| TGB08-L |
0.14 |
|
8 |
5 |
39 |
M3-L4 |
|
20 |
40 |
6.5 |
5 |
3 |
29.5 |
0.9 |
| TGB08-M |
0.14 |
|
8 |
5 |
39 |
M3-L4 |
|
20 |
40 |
6.5 |
5 |
3 |
29.5 |
0.9 |
| TGB12-H |
0.24 |
|
12 |
6 |
47 |
M4-L6 |
|
23.5 |
48 |
8 |
6 |
3 |
35 |
1 |
| TGB12-L |
0.24 |
|
12 |
6 |
47 |
M4-L6 |
|
23.5 |
48 |
8 |
6 |
3 |
35 |
1 |
| TGB12-M |
0.24 |
|
12 |
6 |
47 |
M4-L6 |
|
23.5 |
48 |
8 |
6 |
3 |
35 |
1 |
| TGB16-H |
0.44 |
|
16 |
7 |
56 |
M5-L6 |
|
27.7 |
58 |
8.5 |
8 |
3 |
46 |
1.2 |
| TGB16-L |
0.44 |
|
16 |
7 |
56 |
M5-L6 |
|
27.7 |
58 |
8.5 |
8 |
3 |
46 |
1.2 |
| TGB16-M |
0.44 |
|
16 |
7 |
56 |
M5-L6 |
|
27.7 |
58 |
8.5 |
8 |
3 |
46 |
1.2 |
| TGB20-H |
0.9 |
30 |
20 |
8 |
47 |
M5-L6 |
2 |
25 |
90 |
7.5 |
5.7 |
|
|
1.8 |
| TGB30-H |
2 |
42.5 |
30 |
12 |
60 |
M5-L6 |
2 |
33 |
113 |
9.5 |
7 |
|
|
2 |
| TGB30-L |
2 |
42.5 |
30 |
12 |
60 |
M5-L6 |
2 |
33 |
113 |
9.5 |
7 |
|
|
2 |
| TGB50-H |
5.9 |
70 |
50 |
22 |
81 |
M5-L10 |
3 |
44.8 |
160 |
14.5 |
8.5 |
|
|
2.7 |
| TGB50-L |
5.9 |
70 |
50 |
22 |
81 |
M5-L10 |
3 |
44.8 |
160 |
14.5 |
8.5 |
|
|
2.7 |
| TGB50-M |
5.9 |
70 |
50 |
22 |
81 |
M5-L10 |
3 |
44.8 |
160 |
14.5 |
8.5 |
|
|
2.7 |
How to Order
Confirm the size, set torque range, bore and the sprocket or coupling to be fitted. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
