The Tsubaki Ultra PX belt HC spec is a high-capacity timing belt designed to transmit more power per width than standard PX belts. Higher capacity allows narrower belts or smaller pulleys, saving space and weight. It is used in industrial drives, machine tools and automation equipment.
| Part No. |
No. of Teeth |
Type |
Belt Width (mm) |
Pitch (mm) |
Max. Tension (N) |
Circumference (mm) |
Tooth Profile |
| BG525UP3M6-HC |
175 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
525 |
UP3M |
| BG537UP3M10-HC |
179 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
537 |
UP3M |
| BG537UP3M15-HC |
179 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
537 |
UP3M |
| BG537UP3M6-HC |
179 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
537 |
UP3M |
| BG552UP3M10-HC |
184 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
552 |
UP3M |
| BG552UP3M15-HC |
184 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
552 |
UP3M |
| BG552UP3M6-HC |
184 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
552 |
UP3M |
| BG561UP3M10-HC |
187 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
561 |
UP3M |
| BG561UP3M15-HC |
187 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
561 |
UP3M |
| BG561UP3M6-HC |
187 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
561 |
UP3M |
| BG588UP3M10-HC |
196 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
588 |
UP3M |
| BG588UP3M15-HC |
196 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
588 |
UP3M |
| BG588UP3M6-HC |
196 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
588 |
UP3M |
| BG600UP3M10-HC |
200 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
600 |
UP3M |
| BG600UP3M15-HC |
200 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
600 |
UP3M |
| BG600UP3M6-HC |
200 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
600 |
UP3M |
| BG618UP3M10-HC |
206 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
618 |
UP3M |
| BG618UP3M15-HC |
206 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
618 |
UP3M |
| BG618UP3M6-HC |
206 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
618 |
UP3M |
| BG633UP3M10-HC |
211 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
633 |
UP3M |
| BG633UP3M15-HC |
211 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
633 |
UP3M |
| BG633UP3M6-HC |
211 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
633 |
UP3M |
| BG660UP3M10-HC |
220 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
660 |
UP3M |
| BG660UP3M15-HC |
220 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
660 |
UP3M |
| BG660UP3M6-HC |
220 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
660 |
UP3M |
| BG675UP3M10-HC |
225 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
675 |
UP3M |
| BG675UP3M15-HC |
225 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
675 |
UP3M |
| BG675UP3M6-HC |
225 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
675 |
UP3M |
| BG681UP3M10-HC |
227 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
681 |
UP3M |
| BG681UP3M15-HC |
227 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
681 |
UP3M |
| BG681UP3M6-HC |
227 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
681 |
UP3M |
| BG687UP3M10-HC |
229 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
687 |
UP3M |
| BG687UP3M15-HC |
229 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
687 |
UP3M |
| BG687UP3M6-HC |
229 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
687 |
UP3M |
| BG693UP3M10-HC |
231 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
693 |
UP3M |
| BG693UP3M15-HC |
231 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
693 |
UP3M |
| BG693UP3M6-HC |
231 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
693 |
UP3M |
| BG699UP3M10-HC |
233 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
699 |
UP3M |
| BG699UP3M15-HC |
233 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
699 |
UP3M |
| BG699UP3M6-HC |
233 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
699 |
UP3M |
| BG702UP3M10-HC |
234 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
702 |
UP3M |
| BG702UP3M15-HC |
234 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
702 |
UP3M |
| BG702UP3M6-HC |
234 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
702 |
UP3M |
| BG705UP3M10-HC |
235 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
705 |
UP3M |
| BG705UP3M15-HC |
235 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
705 |
UP3M |
| BG705UP3M6-HC |
235 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
705 |
UP3M |
| BG720UP3M10-HC |
240 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
720 |
UP3M |
| BG720UP3M15-HC |
240 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
720 |
UP3M |
| BG720UP3M6-HC |
240 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
720 |
UP3M |
| BG738UP3M10-HC |
246 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
738 |
UP3M |
| BG738UP3M15-HC |
246 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
738 |
UP3M |
| BG738UP3M6-HC |
246 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
738 |
UP3M |
| BG753UP3M10-HC |
251 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
753 |
UP3M |
| BG753UP3M15-HC |
251 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
753 |
UP3M |
| BG753UP3M6-HC |
251 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
753 |
UP3M |
| BG756UP3M10-HC |
252 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
756 |
UP3M |
| BG756UP3M15-HC |
252 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
756 |
UP3M |
| BG756UP3M6-HC |
252 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
756 |
UP3M |
| BG789UP3M10-HC |
263 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
789 |
UP3M |
| BG789UP3M15-HC |
263 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
789 |
UP3M |
| BG789UP3M6-HC |
263 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
789 |
UP3M |
| BG804UP3M10-HC |
268 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
804 |
UP3M |
| BG804UP3M15-HC |
268 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
804 |
UP3M |
| BG804UP3M6-HC |
268 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
804 |
UP3M |
| BG822UP3M10-HC |
274 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
822 |
UP3M |
| BG822UP3M15-HC |
274 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
822 |
UP3M |
| BG822UP3M6-HC |
274 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
822 |
UP3M |
| BG852UP3M10-HC |
284 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
852 |
UP3M |
| BG852UP3M15-HC |
284 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
852 |
UP3M |
| BG852UP3M6-HC |
284 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
852 |
UP3M |
| BG861UP3M10-HC |
287 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
861 |
UP3M |
| BG861UP3M15-HC |
287 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
861 |
UP3M |
| BG861UP3M6-HC |
287 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
861 |
UP3M |
| BG870UP3M10-HC |
290 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
870 |
UP3M |
| BG870UP3M15-HC |
290 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
870 |
UP3M |
| BG870UP3M6-HC |
290 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
870 |
UP3M |
| BG879UP3M10-HC |
293 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
879 |
UP3M |
| BG879UP3M15-HC |
293 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
879 |
UP3M |
| BG879UP3M6-HC |
293 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
879 |
UP3M |
| BG885UP3M10-HC |
295 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
885 |
UP3M |
| BG885UP3M15-HC |
295 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
885 |
UP3M |
| BG885UP3M6-HC |
295 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
885 |
UP3M |
| BG891UP3M10-HC |
297 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
891 |
UP3M |
| BG891UP3M15-HC |
297 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
891 |
UP3M |
| BG891UP3M6-HC |
297 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
891 |
UP3M |
| BG918UP3M10-HC |
306 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
918 |
UP3M |
| BG918UP3M15-HC |
306 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
918 |
UP3M |
| BG918UP3M6-HC |
306 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
918 |
UP3M |
| BG933UP3M10-HC |
311 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
933 |
UP3M |
| BG933UP3M15-HC |
311 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
933 |
UP3M |
| BG933UP3M6-HC |
311 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
933 |
UP3M |
| BG948UP3M10-HC |
316 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
948 |
UP3M |
| BG948UP3M15-HC |
316 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
948 |
UP3M |
| BG948UP3M6-HC |
316 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
948 |
UP3M |
| BG957UP3M10-HC |
319 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
957 |
UP3M |
| BG957UP3M15-HC |
319 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
957 |
UP3M |
| BG957UP3M6-HC |
319 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
957 |
UP3M |
| BG972UP3M10-HC |
324 |
Single-sided teeth |
10 |
3 |
Mounting: 72, Recommended mounting value: 54 |
972 |
UP3M |
| BG972UP3M15-HC |
324 |
Single-sided teeth |
15 |
3 |
Mounting: 118, Recommended mounting value: 88 |
972 |
UP3M |
| BG972UP3M6-HC |
324 |
Single-sided teeth |
6 |
3 |
Mounting: 40, Recommended mounting value: 29 |
972 |
UP3M |
Specify profile, belt pitch length and width. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
