TSUBAKI DCRD0 — DC Brushless Hypoid Gearmotor, genuine TSUBAKI product.
Overview
This TSUBAKI DC brushless hypoid gearmotor combines a brushless DC motor with a right-angle hypoid gear reducer. Brushless motors offer wide speed control and long life, while hypoid gearing provides efficient, quiet right-angle drive. It is used in conveyors, automated guided vehicles and compact machinery.
Key Features
- Brushless DC motor for speed control
- Hypoid gearing for right-angle drive
- Compact and quiet design
- Long life without brush wear
Specifications
| Part No. |
Control Method |
Supply Voltage |
Allowable Frequency Fluctuation |
Applicable Motor Capacity (kW) |
Output Fluctuation (%) |
Rated Input Current (A) |
Supply Frequency (Hz) |
Resistance |
Allowable Voltage Fluctuation |
Speed Control Range |
Torque Limit |
Accel./Decel. Time (ms) |
| DCRD020B10K |
Sine wave control |
[1-phase/3-phase] 200~240V |
±5% |
0.2 |
[Speed] ±0.5 |
[3-phase] 1.6, [1-phase] 2.9 |
50/60 |
Regenerative resistor compatible specification |
±10% |
100~2500 r/min (short time 3000) |
1.7 |
100～10000 |
| DCRD040B10K |
Sine wave control |
[1-phase/3-phase] 200~240V |
±5% |
0.4 |
[Speed] ±0.5 |
[3-phase] 2.8, [1-phase] 5.1 |
50/60 |
Regenerative resistor compatible specification |
±10% |
100~2500 r/min (short time 3000) |
1.7 |
100～10000 |
| DCRD075B10K |
Sine wave control |
[1-phase/3-phase] 200~240V |
±5% |
0.75 |
[Speed] ±0.5 |
[3-phase] 4.9, [1-phase] 9 |
50/60 |
Regenerative resistor compatible specification |
±10% |
100~2500 r/min (short time 3000) |
1.7 |
100～10000 |
How to Order
Confirm motor output, reduction ratio, voltage and controller requirements. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
