TSUBAKI Plastic Cable Carrier (Part 5) - TKP91H80W300R200

Description

TSUBAKI TK — Plastic Cable Carrier, genuine TSUBAKI product.

Overview

This Tsubaki plastic cable carrier guides power cables, signal lines and hoses that move with a machine axis, keeping them at a controlled bending radius. Interlocking resin links are light, quiet and resistant to corrosion, so the carrier needs no lubrication. It is fitted to machine tools, robots, injection molding machines and automated transfer equipment.

Key Features

  • Interlocking resin links are light and quiet
  • Controlled bending radius extends cable life
  • Corrosion-free and needs no lubrication
  • Length adjusted by adding or removing links

Specifications

Part No. Class Type Pitch (mm) Model Type Outer Width (mm) Inner Width (mm) Mounting Dimension (Height) (mm) Max. Travel Stroke (mm) No. of Links
TKP91H80W300R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 350 300 518～538 8.8
TKP91H80W300R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 350 300 618～638 8.8
TKP91H80W300R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 350 300 718～738 8.8
TKP91H80W300R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 350 300 818～838 8.8
TKP91H80W300R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 350 300 918～938 8.8
TKP91H80W300R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 350 300 1018～1038 8.8
TKP91H80W300R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 350 300 1118～1138 8.8
TKP91H80W325R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 375 325 418～438 8.8
TKP91H80W325R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 375 325 518～538 8.8
TKP91H80W325R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 375 325 618～638 8.8
TKP91H80W325R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 375 325 718～738 8.8
TKP91H80W325R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 375 325 818～838 8.8
TKP91H80W325R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 375 325 918～938 8.8
TKP91H80W325R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 375 325 1018～1038 8.8
TKP91H80W325R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 375 325 1118～1138 8.8
TKP91H80W350R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 400 350 418～438 8.8
TKP91H80W350R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 400 350 518～538 8.8
TKP91H80W350R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 400 350 618～638 8.8
TKP91H80W350R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 400 350 718～738 8.8
TKP91H80W350R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 400 350 818～838 8.8
TKP91H80W350R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 400 350 918～938 8.8
TKP91H80W350R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 400 350 1018～1038 8.8
TKP91H80W350R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 400 350 1118～1138 8.8
TKP91H80W400R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 450 400 418～438 8.8
TKP91H80W400R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 450 400 518～538 8.8
TKP91H80W400R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 450 400 618～638 8.8
TKP91H80W400R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 450 400 718～738 8.8
TKP91H80W400R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 450 400 818～838 8.8
TKP91H80W400R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 450 400 918～938 8.8
TKP91H80W400R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 450 400 1018～1038 8.8
TKP91H80W400R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 450 400 1118～1138 8.8
TKP91H80W450R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 500 450 418～438 8.8
TKP91H80W450R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 500 450 518～538 8.8
TKP91H80W450R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 500 450 618～638 8.8
TKP91H80W450R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 500 450 718～738 8.8
TKP91H80W450R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 500 450 818～838 8.8
TKP91H80W450R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 500 450 918～938 8.8
TKP91H80W450R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 500 450 1018～1038 8.8
TKP91H80W450R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 500 450 1118～1138 8.8
TKP91H80W500R150 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 550 500 418～438 8.8
TKP91H80W500R200 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 550 500 518～538 8.8
TKP91H80W500R250 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 550 500 618～638 8.8
TKP91H80W500R300 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 550 500 718～738 8.8
TKP91H80W500R350 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 550 500 818～838 8.8
TKP91H80W500R400 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 550 500 918～938 8.8
TKP91H80W500R450 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 550 500 1018～1038 8.8
TKP91H80W500R500 Cable carrier body Outer: removable / Inner: removable 91 TKP91H80 550 500 1118～1138 8.8
TKQ15H28E108R110 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 148 108 285～305 2.3
TKQ15H28E108R150 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 148 108 365～385 2.3
TKQ15H28E108R60 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 148 108 185～205 2.3
TKQ15H28E108R75 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 148 108 215～235 2.3
TKQ15H28E108R90 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 148 108 245～265 2.3
TKQ15H28E36R110 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 76 36 285～305 2.3
TKQ15H28E36R150 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 76 36 365～385 2.3
TKQ15H28E36R60 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 76 36 185～205 2.3
TKQ15H28E36R75 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 76 36 215～235 2.3
TKQ15H28E36R90 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 76 36 245～265 2.3
TKQ15H28E60R110 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 100 60 285～305 2.3
TKQ15H28E60R150 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 100 60 365～385 2.3
TKQ15H28E60R60 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 100 60 185～205 2.3
TKQ15H28E60R75 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 100 60 215～235 2.3
TKQ15H28E60R90 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 100 60 245～265 2.3
TKQ15H28E76R110 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 116 76 285～305 2.3
TKQ15H28E76R150 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 116 76 365～385 2.3
TKQ15H28E76R60 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 116 76 185～205 2.3
TKQ15H28E76R75 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 116 76 215～235 2.3
TKQ15H28E76R90 Cable carrier body Outer: removable / Inner: removable 15 TKQ15H28 116 76 245～265 2.3
TKR15H22-30W20R40 Cable carrier body Outer: openable both sides 15 TKR15H22 34 20 120～140 1.77 Min. 12 links ~ (number of links must be even.)
TKR15H22-30W20R50 Cable carrier body Outer: openable both sides 15 TKR15H22 34 20 140～160 1.77
TKR15H22-30W20R75 Cable carrier body Outer: openable both sides 15 TKR15H22 34 20 190～210 1.77
TKR15H22-30W40R40 Cable carrier body Outer: openable both sides 15 TKR15H22 54 40 120～140 1.77
TKR15H22-30W40R50 Cable carrier body Outer: openable both sides 15 TKR15H22 54 40 140～160 1.77
TKR15H22-30W40R75 Cable carrier body Outer: openable both sides 15 TKR15H22 54 40 190～210 1.77
TKR15H22-30W60R40 Cable carrier body Outer: openable both sides 15 TKR15H22 74 60 120～140 1.77
TKR15H22-30W60R50 Cable carrier body Outer: openable both sides 15 TKR15H22 74 60 140～160 1.77
TKR15H22-30W60R75 Cable carrier body Outer: openable both sides 15 TKR15H22 74 60 190～210 1.77
TKR20H28W100R150 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 116 100 372～392 2.76
TKR20H28W100R55 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 116 100 182～202 2.76
TKR20H28W100R75 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 116 100 222～242 2.76
TKR20H28W100R95 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 116 100 262～382 2.76
TKR20H28W120R150 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 136 120 372～392 2.76
TKR20H28W120R55 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 136 120 182～202 2.76
TKR20H28W120R75 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 136 120 222～242 2.76
TKR20H28W120R95 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 136 120 262～382 2.76
TKR20H28W30R150 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 46 30 372～392 2.76
TKR20H28W30R55 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 46 30 182～202 2.76
TKR20H28W30R75 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 46 30 222～242 2.76
TKR20H28W30R95 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 46 30 262～382 2.76
TKR20H28W40R150 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 56 40 372～392 2.76
TKR20H28W40R55 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 56 40 182～202 2.76
TKR20H28W40R75 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 56 40 222～242 2.76
TKR20H28W40R95 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 56 40 262～382 2.76
TKR20H28W50R150 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 66 50 372～392 2.76
TKR20H28W50R55 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 66 50 182～202 2.76
TKR20H28W50R75 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 66 50 222～242 2.76
TKR20H28W50R95 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 66 50 262～382 2.76
TKR20H28W60R150 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 76 60 372～392 2.76
TKR20H28W60R55 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 76 60 182～202 2.76
TKR20H28W60R75 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 76 60 222～242 2.76
TKR20H28W60R95 Cable carrier body Outer: removable / Inner: removable 20 TKR20H28 76 60 262～382 2.76

How to Order

Select by inner height and width, bending radius, travel length and cable fill. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.

Product image is representative of the TSUBAKI series; appearance varies by size and model.

About TSUBAKI

Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.

Ordering & Shipping

  • Genuine TSUBAKI product sourced through Korean distribution
  • Ships worldwide from South Korea by FedEx International Priority Express
  • Lead time varies by model; please inquire for exact delivery
  • Import duties and taxes are payable by the recipient
  • Bulk and trade pricing available on request
Product form

TSUBAKI TK — Plastic Cable Carrier, genuine TSUBAKI product.OverviewThis Tsubaki plastic cable carrier guides power cables, signal lines and hoses... Read more

SKU: TKP91H80W300R200

$38.76 Excl. VAT

    • Ships within 5–10 business days
    • Ships from South Korea
    • Export packing available
    • Worldwide shipping
    • Secure payments Paypal
