Description
TSUBAKI Closed Motor — Closed Motor, genuine TSUBAKI product.
Overview
This Tsubaki closed motor is a totally enclosed gearmotor combining an induction motor and a gear reducer. It provides reduced output speed with high torque for conveyors, mixers and general machinery. Models vary by output, reduction ratio, mounting and shaft arrangement. It suits applications where a compact, enclosed geared drive is preferred over a separate motor and reducer.
Key Features
- Totally enclosed motor construction
- Integrated gear reduction
- Range of reduction ratios
- Brake options available
Specifications
| Part No. |
Reduction Ratio |
Brake |
Mounting Method |
Power Supply |
Output Shaft Allowable O.H.L (N) |
Shaft Arrangement |
Reduction Stages |
Motor Capacity Code |
Motor Output (kW) |
Actual Reduction Ratio |
| HCMA040-280L120L |
120 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
40 |
0.4 |
1/120 |
| HCMA040-280L120R |
120 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
40 |
0.4 |
1/120 |
| HCMA040-280L150L |
150 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
40 |
0.4 |
1/150 |
| HCMA040-280L150R |
150 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
40 |
0.4 |
1/150 |
| HCMA040-280L180L |
180 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
40 |
0.4 |
1/180 |
| HCMA040-280L180R |
180 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
40 |
0.4 |
1/180 |
| HCMA040-280L200L |
200 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
40 |
0.4 |
1/200 |
| HCMA040-280L200R |
200 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
40 |
0.4 |
1/200 |
| HCMA040-280L90L |
90 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
40 |
0.4 |
1/90 |
| HCMA040-280L90R |
90 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
40 |
0.4 |
1/90 |
| HCMA055-220L40L |
40 |
Without brake |
Foot mount type |
3-phase 200V |
3730 |
Left |
2 |
55 |
0.55 |
1/40 |
| HCMA055-220L40R |
40 |
Without brake |
Foot mount type |
3-phase 200V |
3730 |
Right |
2 |
55 |
0.55 |
1/40 |
| HCMA055-220L50L |
50 |
Without brake |
Foot mount type |
3-phase 200V |
3730 |
Left |
2 |
55 |
0.55 |
1/50 |
| HCMA055-220L50R |
50 |
Without brake |
Foot mount type |
3-phase 200V |
3730 |
Right |
2 |
55 |
0.55 |
1/50 |
| HCMA055-280L100L |
100 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
55 |
0.55 |
1/100 |
| HCMA055-280L100R |
100 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
55 |
0.55 |
1/100 |
| HCMA055-280L120L |
120 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
55 |
0.55 |
1/120 |
| HCMA055-280L120R |
120 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
55 |
0.55 |
1/120 |
| HCMA055-280L150L |
150 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
55 |
0.55 |
1/150 |
| HCMA055-280L150R |
150 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
55 |
0.55 |
1/150 |
| HCMA055-280L60L |
60 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
55 |
0.55 |
1/60 |
| HCMA055-280L60R |
60 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
55 |
0.55 |
1/60 |
| HCMA055-280L75L |
75 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
55 |
0.55 |
1/75 |
| HCMA055-280L75R |
75 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
55 |
0.55 |
1/75 |
| HCMA055-280L90L |
90 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Left |
2 |
55 |
0.55 |
1/90 |
| HCMA055-280L90R |
90 |
Without brake |
Foot mount type |
3-phase 200V |
5150 |
Right |
2 |
55 |
0.55 |
1/90 |
How to Order
Specify motor output, reduction ratio, voltage, mounting method and brake. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
