This moving end bracket is a mounting part for the TSUBAKI TKP plastic cable carrier. Cable carriers guide and protect cables and hoses that move with machine axes, and the moving end bracket attaches the carrier's last link to the travelling part of the machine. Correct brackets keep the carrier aligned and prevent stress on cables during repeated strokes.
| Part No. |
Mounting Direction |
Compatibility |
Inner Width (mm) |
Inner Width (mm) |
Type |
Type |
Material |
Mass (g) |
Remarks |
Type |
Connection Pitch (mm) |
Model Type |
Outer Width (mm) |
| TKP13H10W10TC-MO |
Moving-end side / outer side |
|
|
10 |
|
Outer: removable |
Engineering plastic |
|
Integrated type / outer-side mounting |
Moving-end bracket mounting bracket |
13 |
TKP13H10 |
17 |
| TKP13H10W20TC-MO |
Moving-end side * inner side |
|
|
20 |
|
Outer: removable |
Engineering plastic |
|
Integrated type / outer-side mounting |
Moving-end bracket mounting bracket |
13 |
TKP13H10 |
27 |
| TKP35H22W25-MI |
|
(Cable carrier body) TKP35H22- □□ W25R □□ |
|
25 |
|
Moving end, inner opening |
|
15 |
Integrated type * inner-side mounting |
Moving-end bracket mounting bracket |
35 |
TKP35H22 |
37 |
| TKP35H22W25-MO |
|
(Cable carrier body) TKP35H22- □□ W25R □□ |
25 |
|
|
Moving end, outer opening |
|
15 |
Integrated type / outer-side mounting |
Moving-end bracket mounting bracket |
35 |
TKP35H22 |
37 |
| TKP35H22W38-MI |
|
(Cable carrier body) TKP35H22- □□ W38R □□ |
|
38 |
Moving end, inner opening |
|
|
18 |
Integrated type * inner-side mounting |
Moving-end bracket mounting bracket |
35 |
TKP35H22 |
50 |
| TKP35H22W38-MO |
|
(Cable carrier body) TKP35H22- □□ W38R □□ |
|
38 |
|
Moving end, outer opening |
|
18 |
Integrated type / outer-side mounting |
Moving-end bracket mounting bracket |
35 |
TKP35H22 |
50 |
| TKP35H22W50-MO |
|
(Cable carrier body) TKP35H22- □□ W50R □□ |
|
50 |
|
Moving end, outer opening |
|
20 |
Integrated type / outer-side mounting |
Moving-end bracket mounting bracket |
35 |
TKP35H22 |
62 |
| TKP45H25-MOA |
Moving-end side * inner side |
|
|
- |
|
General |
Steel (bright zinc plated) |
|
Split type (inward) / outer-side mounting |
Moving-end bracket mounting bracket |
45 |
TKP45H25 |
General |
Confirm carrier type, inner height and width, and whether a moving or fixed end bracket is required. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
