TSUBAKI R — BS Roller Chain (ISO 606 Standard, B Series), genuine TSUBAKI product.
Overview
BS roller chain follows the ISO 606 B series standard used in Europe and many other regions. This TSUBAKI version transmits power between sprockets in machinery and conveyors originally designed to British or DIN standards. It is commonly used for maintenance on imported equipment. B series dimensions differ from ANSI RS chain, so the two are not interchangeable.
Key Features
- ISO 606 B series dimensions
- Suitable for European and imported machinery
- Hardened components for wear resistance
- Sold by length with connecting links
Specifications
| Part No. |
Dim. T1 (mm) |
Min. Tensile Strength (kN[kgf]) |
Link Width (mm) |
Dim. C (mm) |
Dim. l1 (mm) |
Dim. T2 (mm) |
Links per Unit |
Pin Diameter D (mm) |
Tensile Strength (kN[kgf]) |
Chain No. |
Max. Allowable Tension (kN) |
Body Material |
Type |
Dim. H (mm) |
Shape |
Dim. l2 (mm) |
No. of Strands |
Connection Pitch (mm) |
JIS Grade |
Roller Outer Diameter (R) (Ømm) |
Approx. Mass (kg/m) |
| RF06B-2 |
1.3 |
|
|
10.24 |
11.2 |
|
320 |
|
16.9 (ISO606) |
|
3.32 |
|
Per unit |
8.2 |
|
12.8 |
|
|
06B |
|
0.75 |
| RF06B-2-JL |
1.3 |
|
5.72 |
|
11.2 |
1 |
- |
|
|
RF06B |
2.656 |
Steel |
|
|
RF (flat type) |
|
2 |
9.525 |
|
6.35 |
|
| RS12B-2 |
1.8 |
61 |
|
19.46 |
20.85 |
|
|
5.72 |
57.8 (ISO606) |
|
|
|
|
16.1 |
|
22.75 |
2 |
19.05 |
12B |
|
2.5 |
How to Order
Confirm B series chain number, strand count and required length. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
