Description
TSUBAKI RS35-1B16TQ-H10J — RS35 Finished Bore Sprocket Type 1B, genuine TSUBAKI product.
Overview
The TSUBAKI RS35 Finished Bore Sprocket Type 1B is supplied with the bore, keyway and set screw holes already machined. This avoids in-house machining and gets drives running faster. It runs with RS35 roller chain and is used in light machinery, conveyors and equipment where standard shaft sizes are used.
Key Features
- Finished bore ready for installation
- Keyway and set screw holes pre-machined
- Single-side hub, sized for RS35 chain
Specifications
| Part No. |
Chain Pitch (mm) |
Set Screw |
No. of Teeth (T) |
Hub Diameter DH (mm) |
No. of Strands |
Tooth Profile |
Hub Length L (mm) |
Bore Type |
Chain No. |
Type |
Roller Diameter (Ømm) |
Outer Diameter (Do) (Ømm) |
| RS35-1B16TQ-H10J |
9.525 |
M4 |
16 |
37 |
1 |
Type B |
20 |
Shaft bore finished type |
RS35 |
Sprocket |
5.08 |
53 |
How to Order
Specify the number of teeth, bore diameter, keyway standard and set screw configuration. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
Ordering & Shipping
- Genuine TSUBAKI product sourced through Korean distribution
- Ships worldwide from South Korea by FedEx International Priority Express
- Lead time varies by model; please inquire for exact delivery
- Import duties and taxes are payable by the recipient
- Bulk and trade pricing available on request
