Description
TSUBAKI RS50-1A32TQ — RS50 Sprocket Type 1A, genuine TSUBAKI product.
Overview
This Tsubaki RS50 Type 1A sprocket is a hubless plate sprocket for ANSI No. 50 roller chain. Type 1A plates are intended to be machined, welded or bolted to a user-made hub, giving flexibility in custom drives and conveyors. Models with hardened teeth are available for better wear resistance in higher-speed or heavily loaded service.
Key Features
- Flat plate sprocket without hub
- Suitable for welding or bolting to custom hubs
- Tooth form for RS50 single-strand chain
- Hardened-tooth variants extend wear life
Specifications
| Part No. |
Tooth Width (mm) |
Outer Diameter (Do) (Ømm) |
Chain Pitch (mm) |
Approx. Mass (kg) |
Tooth Profile |
No. of Teeth (T) |
Bore Type |
No. of Strands |
Pilot Bore Diameter d (Ømm) |
Type |
Type |
Material |
| RS50-1A32TQ |
8.9 |
171 |
15.875 |
1.3 |
Type A |
32 |
Pilot bore type |
1 |
18 |
Strong product |
Sprocket |
Carbon steel for machine structural use |
How to Order
Check the number of teeth, chain size, plate bore and whether hardened teeth are required. Please confirm the full part number and options against the TSUBAKI catalog; contact us if you need help identifying the right model.
Product image is representative of the TSUBAKI series; appearance varies by size and model.
About TSUBAKI
Tsubakimoto Chain Co. (TSUBAKI) is a Japanese manufacturer and one of the world's leading makers of power transmission products, including roller and conveyor chains, sprockets, timing belts and pulleys, Power-Lock keyless locking devices, couplings, cam clutches, reducers and cable carriers.
