| Sensing type |
Convergent reflective type |
| Sensing distance |
10 to 30mm |
| Sensing target |
Opaque, Translucent material |
| Response time |
Operation: Max. 3ms, Return: Max. 100ms |
| Light source |
Infrared LED |
| Timer function |
Timer Function |
| Operation mode |
Light ON |
| Weight |
Approx. 75g(approx. 38g) |
| Power voltage |
12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption |
Max. 35mA |
| Control output |
NPN open collector |
| Environment_Ambient illumination |
Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature |
-20 to 65℃, storage: -25 to 70℃ |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Protection structure |
IP50 |
| Connection type |
Cable type(Ø3.5, 2m) |
| Material |
Case: PC, sensing part: PC, bracket: SPCC, bolt: SCM, nut: SCM, sleeve: Brass, Ni-plate |
